Samsung SyncMaster MB1763 Manual de usuario

SyncMaster MB1763 / MB1765

Index

Main Page

Notational

Power

Installation

Clean

Other

Introduction

Unpacking

Front

Rear

Setup

Troubleshooting

Check List

Q & A

Self-Test Feature Check

Specifications

General

PowerSaver

Preset Timing Modes

Information

Service

Terms

Regulatory

Natural Color

Authority

Safety Instructions

Connecting Your Monitor

Installing the Monitor Driver

Bottom

Base Installation

Notational

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric shock

Power

When not used for extended periods of time, set your PC to DPMS. If using

a screen saver, set it to the active screen mode.

?If the size of your monitor is small, or if the same image is present for

long periods of time, you may see afterimages due to damage to the

fluorescent substance on the inside of the CDT.

Do not use a damaged or loose plug.

?This may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

?This may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

?An improper ground may cause electric shock or equipment

damage.

Do not excessively bend the plug and wire nor place heavy objects

upon them, which could cause damage.

?Failure to do so may cause an electric shock or fire.

Disconnect the plug from the outlet during storms or lightening or if it

is not used for a long period of time.

?Failure to do so may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

?This may cause a fire.

Installation

Do not cover the vents on the monitor cabinet.

?Bad ventilation may cause a breakdown or fire.

Put your monitor in a location with low humidity and a minimum of

dust.

?An electric shock or fire could result inside the monitor.

Do not drop the monitor when moving it.

?This may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

?The monitor can cause injury by falling.

Set down the monitor carefully.

?It could be damaged or broken.

Do not place the monitor face down.

?The CDT surface may be damaged.

Do not use the monitor without the monitor stand.

?It could break down or cause a fire due to bad ventilation.

If the monitor must be used without the supplied stand, take steps

to insure proper ventilation.

Clean

When cleaning the monitor case or the surface of the CDT, wipe with a

slightly moistened, soft fabric.

Do not clean Flat monitor with water. Use a water-diluted mild detergent.

(Some detergents contain significant amounts of alcohol-based solvents,

which can damage (color change) or crack the monitor case. The

antiglare/anti-static surface coating on the CDT may also be affected.)

Dilute the detergent (1:10 ratio) with water before using.

Do not spray detergent directly on the monitor.

Use the recommended detergent with a smooth cloth.

?You can prevent the coated CDT from being damaged or the

monitor cabinet from being dissolved, cracked or discolored.

?You can buy a recommended detergent at any Samsung Service

Center.

If the connector between the plug and the pin is dusty or dirty, clean it

properly with a dry cloth.

?A dirty connector can cause an electric shock or fire.

Do not set a glass of water, chemicals or any small metal objects on

the monitor.

?This may cause damage, electric shock or a fire.

?If a foreign substance gets into the monitor, disconnect the plug.

Other

Do not remove cover(or back). No user serviceable parts inside.

?This may cause an electric shock or a fire.

?Refer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are

any unusual sounds or smells coming from it - unplug it immediately

and contact an authorized dealer.

?This may cause an electric shock or a fire.

Do not place any heavy objects on the monitor.

?This may cause an electric shock or a fire.

For each hour of looking at the monitor, you should let your eyes rest

for 5 minutes.

?This will reduce eye fatigue.

Do not use or store inflammable substances near the monitor.

?This may cause an explosion or fire.

Do not try to move the monitor by pulling on the wire or the signal

cable.

?This may cause a breakdown, electric shock or a fire due to

damage to the cable.

Do not move the monitor right or left by pulling only the wire or the

signal cable.

?This may cause a breakdown, electric shock or a fire due to

damage to the cable.

Other

Never insert anything metallic into the monitor openings.

?This may cause an electric shock, fire or injury.

Keep the monitor away from any magnetic substances.

?This may cause discoloring or distortion of the image.

Unpacking

Monitor and Stand

(Some models include a stand attached. )

Please make sure the following items are

included with your monitor.

Power Cord

Stand

Quick Setup Guide

Warranty Card

(Not available in all locations)

User's Guide and

Driver Installation CD

Front

SyncMaster MB1763

1. MagicBright button Use this button to control the MagicBright.

2. Exit button Use this button to Exit the active menu or the OSD.

3. Adjust buttons These buttons allow you to highlight and adjust items in the menu.

4. Menu button Use this button to open the OSD and activate a highlighted menu item.

5. Power indicator This light glows green during normal operation, and blinks green once

as the monitor saves your adjustments.

6. Power button Use this button to turn the monitor on and off.

Note: See PowerSaver described in the manual for further information regarding power saving

functions. For energy conservation, turn your monitor OFF when it is not needed, or when

leaving it unattended for long periods.
