Samsung SyncMaster 753 DFX Manual de usuario

SyncMaster 753DFX/ 755DFX / 753DF / 755DF

Index

User’s Manual

Main Page

Introduction

Power

Installation

Cleaning

Other

Unpacking

Front

Rear

Bottom

Setup

Connecting Your Monitor

Installing the Video Driver

Tilt/Swivel Base Installation

Safety Instructions

Windows 2000

Other Operating System

On-Screen Display

Troubleshooting

Check List

Q & A

Self-Test Feature Check

Specifications

General Specifications

Preset Display Modes

PowerSaver

Information

Service

Terms

Regulatory

Authority

Safety Instructions

User’s Manual

Warning / Caution

Notational Conventions

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited

Do not disassemble

Do not touch

Important to read and understand at all times

Disconnect the plug from the outlet

Grounding to prevent an electric shock

Safety Instructions

User’s Manual

● Do not use a damaged or loose plug.

◆ This may cause an electric shock or fire.

When not used for extended periods of time, set your PC to DPMS. If using a screen saver,

set it to the active screen mode.

If the size of your monitor is small, or if the same image is present for long periods of time,

you may see afterimages due to damage to the flourescent substance on the inside of the

CDT.

● Do not pull the plug out by the wire nor touch the plug with

wet hands.

◆ This may cause an electric shock or fire.

● Use only a properly grounded plug and recepticle.

◆ An improper ground may cause electric shock or equipment damage.

● Do not excessively bend the plug and wire nor place heavy

objects upon them, which could cause damage.

◆ Failure to do so may cause an electric shock or fire.

Power

Safety Instructions

User’s Manual

● Disconnect the plug from the outlet during storms or lightening or if it is

not used for a long period of time.

◆ Failure to do so may cause an electric shock or fire.

● Do not connect too many extension cords or plugs to an outlet.

◆ This may cause a fire.

Safety Instructions

User’s Manual

Put your monitor in a location with low humidity and a minimum of dust.

An electric shock or fire could result inside the monitor.

Do not drop the monitor when moving it.

This may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

The monitor can cause injury by falling.

Set down the monitor carefully.

It could be damaged or broken.

Do not place the monitor face down.

The CRT surface may be damaged.

Do not use the monitor without the monitor stand.

It could break down or cause a fire due to bad ventilation.

If the monitor must be used without the supplied stand, take steps to insure proper ventilation.

Do not cover the vents on the monitor cabinet.

Bad ventilation may cause a breakdown or fire.

Installation

Safety Instructions

User’s Manual

● Do not spray detergent directly on the monitor.

● Use the recommended detergent with a smooth cloth.

◆ You can prevent the coated CDT from being damaged or the monitor cabinet from

being dissolved, cracked or discolored.

◆ You can buy a recommended detergent at any Samsung Service Center.

● If the connector between the plug and the pin is dusty or dirty, clean it

properly with a dry cloth.

◆ A dirty connector can cause an electric shock or fire.

● Do not set a glass of water, chemicals or any small metal

objects on the monitor.

◆ This may cause damage, electric shock or a fire.

◆ If a foreign substance gets into the monitor, disconnect the plug

and then contact a service center.

When cleaning the monitor case or the surface of the CDT, wipe with a slightly

moistened, soft fabric.

Do not clean Flat monitor with water. Use a water-diluted mild detergent.

(Some detergents contain significant amounts of alcohol-based solvents, which can

damage (color change) or crack the monitor case. The antiglare/anti-static surface coating

on the CDT may also be affected.)

Dilute the detergent (1:10 ratio) with water before using.

Caution : Use a recommended detergent only, as other

surfactants containing large amounts of alcohol,

solvent or other strong substances, can discolor or

crack the monitor or damage the coated CDT

Cleaning

Safety Instructions

User’s Manual

● Do not remove cover(or back). No user serviceable parts inside.

◆ This may cause an electric shock or a fire.

◆ Refer servicing to qualified service personnel.

● If your monitor does not operate normally - in particular,if there are any

unusual sounds or smells coming from it - unplug it immediately and

contact an authorized dealer or service.

◆ This may cause an electric shock or a fire.

● Do not place any heavy objects on the monitor.

◆ This may cause an electric shock or a fire.

● For each hour of looking at the monitor, you should let

your eyes rest for 5 minutes.

◆ This will reduce eye fatigue.

● Do not use or store inflammable substances near the monitor.

◆ This may cause an explosion or fire.

● Do not try to move the monitor by pulling on the wire

or the signal cable.

◆ This may cause a breakdown, electric shock or a fire due to damage to the cable.

Other

Safety Instructions

User’s Manual

● Do not move the monitor right or left by pulling only the wire

or the signal cable.

◆ This may cause a breakdown, electric shock or a fire due to damage to the cable.

● Never insert anything metallic into the monitor openings.

◆ This may cause an electric shock, fire or injury.

● Keep the monitor away from any magnetic substances.

◆ This may cause discoloring or distortion of the image.

Introduction

User’s Manual

Monitor and Stand

Please make sure the following items are

included with your monitor.

If any items are missing, contact your dealer.

(Some models include a stand attached.)

Power Cord

Stand

Quick Setup Guide

Warranty card (Not available in all locations)

User's Guide and Driver Installation CD

USB Hub(Option)

Unpacking
