Samsung SyncMaster 510 MP Manual de usuario

SyncMaster 510MP / 710MP

INDEX

Main Page

Safety Instructions

Notational

Power

Installation

Cleaning

Other

Introduction

Unpacking

Front

Rear

Remote Control

Setup

Connecting Your Monitor

Installing the Monitor Driver

Installing a VESA Base

Adjusting Your LCD Monitor

User Controls

On-Screen Display

Troubleshooting

Check before Calling for Service

Problems and Solutions

Q & A

Specifications

General Specifications

PowerSaver

Preset Timing Modes

Information

Service Center

Terms

Regulatory

Natural Color

For Better Display

Authority

Notational

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric shock

Power

When not used for extended periods of time, set your PC to DPMS. If using a

screen saver, set it to the active screen mode.

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

zAn improper ground may cause electric shock or equipment damage.

Do not excessively bend the plug and wire nor place heavy objects upon

them, which could cause damage.

zThis may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause a fire.

Installation

Put your monitor in a location with low humidity and a minimum of dust.

zAn electric shock or fire could result inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

zThe monitor can cause injury by falling.

Set down the monitor carefully.

zIt could be damaged or broken.

Do not place the monitor face down.

zThe TFT-LCD surface may be damaged.

Installing a wall bracket must be done by a qualified professional.

zInstallation by unqualified personnel may result in injury.

zAlways use the mounting device specified in the owner's manual.

Cleaning

When cleaning the monitor case or the surface of the TFT-LCD, wipe with a slightly

moistened, soft fabric.

Do not spray water or detergent directly on the monitor.

zThis may cause damage, electric shock or a fire.

Use the recommended detergent with a smooth cloth.

If the connector between the plug and the pin is dusty or dirty, clean it

properly with a dry cloth.

zA dirty connector can cause an electric shock or fire.

타Ohther

Do not remove cover(or back). No user serviceable parts inside.

zThis may cause an electric shock or a fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are any

unusual sounds or smells coming from it - unplug it immediately and

contact an authorized dealer or service.

zThis may cause an electric shock or fire.

Be careful not to let water drip into the monitor or expose the monitor to

moisture.

zThis may cause malfunction, an electric shock or a fire.

zEspecially avoid operating the monitor near water or outdoors where it

could be exposed to snow or rain.

If the monitor is dropped or the casing is damaged, turn the monitor off

and unplug the power cord.

zThe monitor may malfunction, causing an electric shock or a fire.

zThen contact the Service Center.

Keep the power off when there is thunder and lightening outside, or let the

monitor remain unused for an extended period of time.

zThe monitor may malfunction, causing an electric shock or a fire.

Do not try to move the monitor by pulling on the wire or the signal cable.

zThis may cause a breakdown, electric shock or a fire due to damage to

the cable.

Do not move the monitor right or left by pulling only the wire or the signal

cable.

zThis may cause a breakdown, electric shock or a fire due to damage to

the cable.

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Do not place water containers, chemical products or small metal objects

on the monitor.

zThis may cause malfunction, an electric shock or a fire.

zIf a foreign substance enters the monitor, unplug the power cord and

contact the Service Center.

Ohther

Do not use or store inflammable substances near the monitor.

zThis may cause an explosion or fire.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

Do not insert metal objects such as utensils, wire or drill bits, or things

that catch fire easily, such as pieces of paper or matches, into the vents or

the headphone or A/V ports on the monitor.

zThis may cause malfunction, an electric shock or a fire.

zAlways contact the Service Center if foreign substances/objects enter into

the monitor.

If you view a fixed screen for an extended period of time, residual image

or blurriness may appear.

zChange the mode to energy save or set a screensaver to moving picture

when you need to be away from the monitor for an extended period of

time.

Be careful when adjusting the stand angle.

zApplying too much force may cause the monitor topple over or fall,

resulting in injury.

zYour hand or finger(s) may get caught between the monitor and the

stand, causing injury.

Keep the volume at a proper level when you use the headphones.

zExcessively loud volume levels may damage hearing.

Keep a proper distance between your eyes and the monitor screen.

zSitting too close to the monitor on a continuous basis may damage

eyesight.

Adjust the resolution and frequency to the levels appropriate for the

model.

zInappropriate levels of resolution and frequency may damage your

eyesight.

15" - 1024 x 768

17,18 and 19" -

1280 x 1024

17" Wide - 1280 X 768

21" - 1600 x 1200

24" - 1920 x 1200

Unpacking

Please make sure the following items are included with your monitor. If any items are missing, contact

your dealer.

User's Guide and Natural

Color/Driver Installation CD Power Cord Signal Cable(15 pin D-Sub)

Monitor

Remote Control /

Batteries (CR2025) Audio Cable

Quick Setup Guide Warranty Card

(Not available in all locations)

Front

For detailed information concerning the monitor functions, refer to User Controls under Adjusting Your

Monitor. The monitor's front configuration may vary slightly depending on the monitor model.

1. SOURCE button 5. Left-Right / Volume button

2. MagicBright™ button 6. MENU button

3. AUTO / EXIT button 7. Power button

4. Up-Down / Channel button 8. Power indicator
