Samsung SyncMaster 400TSn Manual de usuario

SyncMaster 400TSn/460TSn

LCD Monitor

User Manual

Safety Instructions

Notational

Note

These safety instructions must be followed to ensure your safety and prevent property damage.

Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Failure to follow directions noted by this symbol could result in bodily harm

or damage to the equipment.

Notational Conventions

Prohibited Important to read and under-

stand at all times

Do not disassemble Disconnect the plug from the

outlet

Do not touch Ground to prevent an electric

shock

Power

When not used for extended period of time, set your computer to DPM.

If using screen saver, set it to active screen mode.

The images here are for reference only, and are not applicable in all cases (or

countries).

Shortcut to Anti-Afterimage Instructions

Donotuseadamagedpowercordorplugoradamagedorloosepower

outlet.

• Otherwise, this may result in electric shock or fire.

Do not touch the power plug with wet hands when removing or plug-

ging the plug into the outlet.

• Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power outlet.

• Otherwise, it may result in electric shock or personal injury.

Ensure that the power plug is plugged into the power outlet firmly and

correctly.

• Otherwise, this may result in fire.

Do not forcefully bend or pull the power plug and do not place any

heavy material on it.

• Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

• Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the product.

•Otherwise, this may result in damage to the product due to electric

shock.

To disconnect the apparatus from the mains, the plug must be pulled

out from the mains socket, therefore the mains plug shall be readily op-

erable.

• This may cause electric shock or fire.

Use only the power cord provided by our company. Do not use the

provided power cord of another product.

• Otherwise, this may result in fire or electric shock.

Installation

Be sure to contact an authorized Service Center when installing your monitor in

alocationwithheavydust,high or lowtemperatures,high humidity, andexposed

to chemical substances and where it operates for 24 hours such as at airports,

train stations etc.

Failure to do so may cause serious damage to your monitor.

Ensure that at least two persons lift and move the product.

•Otherwise, it may be dropped and cause personal injury, and/or dam-

age the product.

When installing the product in a cabinet or rack, make sure that the

front end of the bottom of the product does not project out.

• Otherwise, it may fall or cause personal injury.

• Use a cabinet or rack of a size appropriate to the product.

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIGA-

RETTES AND ANY HEATING APPLIANCES NEAR THE PROD-

UCT.

• Otherwise, this may result in fire.

Keep heating appliances as far away from the power cord or the prod-

uct as possible.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

Do not install it in a badly ventilated location such as a bookcase or

closet.

•Otherwise, this may result in fire due to an increase in the internal

temperature.

When putting the product down, make sure to put it down softly.

• Otherwise, this may result in damage to the screen display.

Do not place the front of the product on the floor.

• Otherwise, this may result in damage to the screen display.

Ensure thatan authorizedinstallationcompanyinstallsthe wallmount.

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that there is

a clearance of more than 10 cm from the wall.

•Otherwise, it may result in fire due to an increase in the internal tem-

perature.

Ensure that the packaging vinyl is kept away from children.

•Otherwise, it may result in serious harm (suffocation) if children play

with it.

If the height of your monitor is adjustable, do not place any object or

part of your body on the stand when lowering it.

• This may cause damage to the product or the person carrying it.

Clean

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe

with a slightly moistened, soft fabric.

Do not spray cleaner directly onto the surface of the product.

•Otherwise, this may result in the discoloration and distortion of the

structure and the screen surface may peel off.

Clean the product using a soft cloth with a monitor cleaner only. If

you must use a cleaner other than the monitor cleaner, dilute it with water

at a ratio of 1:10.

When cleaning the power plug pins or dusting the power outlet, clean

it with a dry cloth.

• Otherwise, it may result in fire.

Safety Instructions

When cleaning the product, make sure to disconnect the power cord.

• Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and clean it

softly with a dry cloth.

• (Do not use chemicals such as wax, benzene, alcohol, thinner, mos-

quito repellant, lubricant, or cleaner.) These may change the appear-

ance of the product surface and peel off the indication labels on the

product.

Since the product housing is easily scratched, make sure to use the

specified cloth only.

•Use the specified cloth adding only a little water. As the product may

be scratched if there is any foreign material on the cloth, make sure

to shake it thoroughly before using it.

When cleaning the product, do not spray water directly onto the main

body of the product.

• Ensure that water does not enter the product and that it is not wet.

• Otherwise, this may result in electric shock, fire or a malfunction.

Others

The product is a high voltage product. Ensure that users do not disas-

semble, repair or modify the product themselves.

•Otherwise, this may result in electric shock or fire. If the product

needs to be repaired, contact a Service Center.

If there is a strange smell or a strange sound or smoke is coming from

theproduct,disconnectthepowerplugimmediatelyandcontactaService

Center.

• Otherwise, this may result in electric shock or fire.

Do not place this product in a location exposed to moisture, dust,

smoke, water, or in a car.

• Otherwise, this may result in electric shock or fire.

When you drop the product or the case is broken, turn the power off

and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

If thunder or lightening is occurring, do not touch the power cord or

antenna cable.

• Otherwise, this may result in electric shock or fire.

Safety Instructions

Do not try to move the monitor by pulling only the wire or the signal

cable.

•Otherwise, it may fall and result in electric shock, damage to the

product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and left

while only holding the power cord or signal cables.

•Otherwise, it may fall and result in electric shock, damage to the

product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table or

curtain.

•Otherwise, it may result in fire due to an increase in the internal tem-

perature.

Do not place any containers containing water, vases, flowerpots, med-

icines as well as any metal on the product.

•Ifwater or aforeignmaterial enters theproduct, disconnect thepower

cord and contact a Service Center.

• This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material near the

product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and steels, or

inflammable objects, such as matches or paper, inside the product

(through the ventilating openings, input and output terminals, etc).

•If water or foreign material enters the product, disconnect the power

cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

When using a fixed screen for a long time, an afterimage or stain may

occur.

•If you are not using your product for a long period of time, put it into

sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

• Otherwise, your eyesight may be damaged.

Whenusingheadphonesorearphones,donotturnthevolumetoohigh.

• Having the sound too loud may damage your hearing.

If you continually move closer to the product screen, your eyesight

may be failing.

Safety Instructions

Take a rest for at least five (5) minutes after using the monitor for one

(1) hour.

This reduces the weariness of your eyes.

Do not install it in an unstable location such as an unstable rack or

uneven surface or a location exposed to vibrations.

•Otherwise, it may fall and cause personal injury and/or damage the

product.

•If you use the product in a location exposed to vibrations, it may

damage the product and result in fire.

Whenmovingthe product,turnthepoweroffanddisconnectthepower

plug, antenna cable, and all the cables connected to the product.

• Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up onto the

product.

• The product may fall and cause personal injury or death.

If you do not use the product for a long period of time, disconnect the

power cord from the power outlet.

•Otherwise, this may result in overheating or fire due to dust, and may

result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as cookies

etc. that may attract the attentions of children and to the product.

•Your children may hang onto the product causing it to fall and this

may result in personal injury or death.

Be careful that children do not place the battery in their mouths when

removed from the remote control. Place the battery in a location that

children or infants cannot reach.

• If children have had the battery in their mouths, consult your doctor

immediately.

When replacing the battery, insert it with right polarity (+, -).

•Otherwise, the battery may become damaged or it may cause fire,

personal injury or damage due to leakage of the internal liquid.

Use only the specified standardized batteries, and do not use a new

battery and a used battery at the same time.

•Otherwise, the batteries may be damaged or cause fire, personal in-

jury or damage due to a leakage of the internal liquid.

The batteries (and rechargeable batteries) are not ordinary refuse and

must be returned for recycling purposes. The customer is responsible for

returning the used or rechargeable batteries for recycling.

•The customer can return used or rechargeable batteries to a nearby

publicrecyclingcenterortoastoresellingthesametypeofthebattery

or rechargeable battery.

Safety Instructions

Do not place the product in a location exposed to direct sunlight or

near any heat such as a fire or heater.

• This may reduce the lifetime of the product, and may result in fire.

Do not drop any objects onto the product or cause any impact to the

product.

• Otherwise, this may result in electric shock or fire.

Do not use a humidifier or kitchen table near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power plug

but ventilate immediately.

• If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display panel

becomes hot. Do not touch it.

•Keep the small accessories in a location out of the reach of children.

Be careful when adjusting the angle of the product or the height of the

stand.

•This may result in personal injury as your hand or fingers may be-

come caught.

•Also, if you tilt the product too far, it may fall and cause personal

injury.

Do not install the product in a location low enough for children to

reach.

• Otherwise, it may fall and result in personal injury.

•Since the front part of the product is heavy, install the product on a

level and stable surface.

Do not put any heavy objects on the product.

• This may result in personal injury and/or damage to the product.

Safety Instructions

Introduction

Package Contents

Note

Please make sure the following items are included with your LCD Display.

If any items are missing, contact your dealer.

Contact a local dealer to buy optional items.

Note

This stand is not for the Floor Standing Type.

Unpacking

LCD Display

Manuals

Quick Setup Guide Warranty Card

(Not available in all loca-

tions)

User's Guide

Cables

D-Sub Cable Power Cord

Others

Remote Control Batteries (AAA X 2)

(Not available in all loca-

tions)

HDD Cover

Sold separately

DVI Cable Wall Mount KIT Semi Stand KIT

LAN Cable TV tuner box

Note

•You can purchase and connect a separate network box or TV tuner box. For information on how

to use these, refer to their respective user manuals.

• You can only connect one external box.

Your LCD Display

Front

MENU button [MENU]

Opensthe on-screenmenuand exitsfromthe menu.Alsouse toexitthe OSDmenu

or return to the previous menu.

Navigate buttons (Up-Down buttons)

Introduction

Otros manuales para SyncMaster 400TSn

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Samsung

Samsung

Samsung PPM63H3 Manual de usuario

Samsung

Samsung SyncMaster BX1950 Manual de usuario

Samsung

Samsung PS-42C62H Manual de usuario

Samsung

Samsung LH85WMRWLGCXEN Manual de usuario

Samsung

Samsung 400UXn - SyncMaster - 40" LCD Flat Panel... Manual de usuario

Samsung

Samsung 460Pn - SyncMaster - 46" LCD Monitor Manual de usuario

Samsung

Samsung S27D850T Manual de usuario

Samsung

Samsung 940UX - SyncMaster - 19" LCD Monitor Manual de usuario

Samsung

Samsung PM55H Manual de usuario

Samsung

Samsung S22B370B Manual de usuario

Samsung

Samsung F27T85 Series Manual de usuario

Samsung

Samsung SyncMaster 2032MW Manual de usuario

Samsung

Samsung 2032NW - SyncMaster - 20" LCD Monitor Manual de usuario

Samsung

Samsung 225BW - SyncMaster - 22" LCD Monitor Manual de usuario

Samsung

Samsung SyncMaster 2033SN Manual de usuario

Samsung

Samsung SyncMaster 225MS Manual de usuario

Samsung

Samsung SyncMaster 2063UW Manual de usuario

Samsung

Samsung SyncMaster 943BWT Guía del usuario

Samsung

Samsung CN17V Series Manual de usuario

Samsung

Samsung SyncMaster 460DMn Manual de usuario

Samsung

Samsung SyncMaster 460FP-3 Manual de instalación y operación

Samsung

Samsung LTN154X3-L01 - 15.4 WXGA Laptop LCD Screen Manual de usuario

Samsung

Samsung SyncMaster EX2220 Manual de usuario

Samsung

Samsung SyncMaster C27A750X Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
