Samsung SyncMaster 323T Manual de usuario

SyncMaster 323T,403T

INDEX

Main Page

Safety Instructions

Notational

Power

Installation

Cleaning

Other

Introduction

Unpacking

Front

Rear

Remote Control

Setup

Installing Stand Kit

Connecting Your Monitor

Multiple Display Control (MDC)

Adjusting Your LCD Monitor

User control buttons

OSD Functions

Troubleshooting

Check before Calling for Service

Problems and Solutions

Q & A

Specifications

General Specifications

PowerSaver

Preset Timing Modes

Information

Service Center

Terms

Regulatory

Natural Color

For Better Display

Authority

Mechanical Lay-out

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric shock

Notational

When not used for extended periods of time, set your PC to DPMS. If using a

screen saver, set it to the active screen mode.

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

zAn improper ground may cause electric shock or equipment damage.

Do not excessively bend the plug and wire nor place heavy objects

upon them, which could cause damage.

zThis may cause an electric shock or fire.

Disconnect the plug from the outlet during storms or lightening or if it

is not used for a long period of time.

zFailure to do so may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause a fire.

Power

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Put your monitor in a location with low humidity and a minimum of dust.

zAn electric shock or fire could result inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

zThe monitor can cause injury by falling.

Set down the monitor carefully.

zIt could be damaged or broken.

Do not place the monitor face down.

zThe TFT-LCD surface may be damaged.

Installation

When cleaning the monitor case or the surface of the TFT-LCD, wipe with a slightly

moistened, soft fabric.

Do not spray detergent directly on the monitor.

Use the recommended detergent with a smooth cloth.

If the connector between the plug and the pin is dusty or dirty, clean it

properly with a dry cloth.

zA dirty connector can cause an electric shock or fire.

Do not set a glass of water, chemicals or any small metal objects on the

monitor.

zThis may cause damage, electric shock or a fire.

zIf a foreign substance gets into the monitor, disconnect the plug and then

contact a service center.

Cleaning

Do not remove cover(or back). No user serviceable parts inside.

zThis may cause an electric shock or a fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are any

unusual sounds or smells coming from it - unplug it immediately and

contact an authorized dealer or service.

zThis may cause an electric shock or fire.

Do not place any heavy objects on the monitor.

zThis may cause an electric shock or a fire.

For each hour of looking at the monitor, you should let your eyes rest for

5 minutes.

zThis will reduce eye fatigue.

Do not use or store inflammable substances near the monitor.

zThis may cause an explosion or fire.

Do not try to move the monitor by pulling on the wire or the signal cable.

zThis may cause a breakdown, electric shock or a fire due to damage to

the cable.

Do not move the monitor right or left by pulling only the wire or the signal

cable.

zThis may cause a breakdown, electric shock or a fire due to damage to

the cable.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

Other

If you view a fixed screen for an extended period of time, residual

image or blurriness may appear.

zChange the mode to energy save or set a screensaver to moving

picture when you need to be away from the monitor for an extended

period of time.

Unpacking

Please make sure the following items are included with your monitor. If any items are missing, contact

your dealer.

Remote Control /

Batteries (AAA X 2)

Monitor RS232C CABLE

User's Guide CD

Warranty Card

(Not available in all locations) Temporary Stand

Sold separately

PIVOT Installation CD

Contact a local Samsung Electronics service center to buy optional items.

Wall Mount KIT

Speaker Set Stand Kit

Power Cord Cover-hole

Signal Cable

(15 pin D-Sub)

For detailed information concerning the monitor functions, refer to User Controls under Adjusting Your

Monitor. The monitor's front configuration may vary slightly depending on the monitor model.

1. Auto button 6.Menu button

2. Source button 7.Power button

3. Exit button 8.Power indicator

4. Navigate button (Up-Down Button) 9. Remote Control Sensor

5. Adjust button (Left-Right Button)

Front

/ Volume button

Rear

For detailed information concerning cable connections, refer to Connecting Cables under Setup.

The monitor's rear configuration may vary slightly depending on the monitor model.

1. Power On/Off Switch

2. Power port

3. EXTERNAL CONTROL (RS232C Serial PORT) : MDC(Multiple Device Control) Program Port

4. PC Video Connection Terminal

: Using D-Sub Cable (15 pin D-Sub) - RGB 1 mode (Analog PC)

5. PC Video Connection Terminal

: Using DVI Cable (DVI-D to DVI-D) - RGB 2 mode (Digital PC)
