Samsung SyncMaster 210P PLUS Manual de usuario

SAMTRON 210P plus

Main > Index

Main Page On-Screen Display

Safety Instructions Troubleshooting

Notational Check List

Power Q & A

Installation Self-Test Feature Check

Cleaning

Other

Introduction Specifications

Unpacking General Specifications

Front Preset Timing Modes

Rear PowerSaver

Bottom

Setup Information

Connecting Your Monitor Service

Installing the Monitor Driver Terms

Automatic Regulatory

Manual

Base Installation

Authority

Main > Safety Instructions > Notational

Notational

Power

Installation

Clean

Other

Failure to follow directions noted by this symbol could result in bodily harm or damage to

equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric shock

Main > Safety Instructions > Power

Notational

Power

Installation

Clean

Other

When not used for extended periods of time, set your PC to DPMS. If using

a screen saver, set it to the active screen mode.

zIf the size of your monitor is small, or if the same image is present for long

periods of time, you may see afterimages due to damage to the

fluorescent substance on the inside of the CRT.

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet

hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and recepticle.

zAn improper ground may cause electric shock or equipment

damage.

Do not excessively bend the plug and wire nor place heavy objects

upon them, which could cause damage.

zFailure to do so may cause an electric shock or fire.

Disconnect the plug from the outlet during storms or lightening or

if it is not used for a long period of time.

zFailure to do so may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause a fire.

Main > Safety Instructions > Installation

Notational

Power

Installation

Clean

Other

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Put your monitor in a location with low humidity and a minimum of

dust.

zAn electric shock or fire could result inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

zThe monitor can cause injury by falling.

Set down the monitor carefully.

zIt could be damaged or broken.

Do not place the monitor face down.

zThe CRT surface may be damaged.

Do not use the monitor without the monitor stand.

zIt could break down or cause a fire due to bad ventilation.

zIf the monitor must be used without the supplied stand, take steps

to insure proper ventilation.

Main > Safety Instructions > Clean

Notational

Power

Installation

Clean

Other

When cleaning the monitor case or the surface of the CRT, wipe with a

slightly moistened, soft fabric.

Do not clean Flat monitor with water. Use a water-diluted mild

detergent.

(Some detergents contain significant amounts of alcohol-based solvents,

which can damage (color change) or crack the monitor case. The

antiglare/anti-static surface coating on the CRT may also be affected.)

Dilute the detergent (1:10 ratio) with water before using.

Do not spray detergent directly on the monitor.

Use the recommended detergent with a smooth cloth.

zYou can prevent the coated CRT from being damaged or the

monitor cabinet from being dissolved, cracked or discolored.

zYou can buy a recommended detergent at any Samsung Service

Center.

If the connector between the plug and the pin is dusty or dirty,

clean it properly with a dry cloth.

zA dirty connector can cause an electric shock or fire.

Do not set a glass of water, chemicals or any small metal objects

on the monitor.

zThis may cause damage, electric shock or a fire.

zIf a foreign substance gets into the monitor, disconnect the plug

and then contact a service center.

Main > Safety Instructions > Other

Notational

Power

Installation

Clean

Other

Do not remove cover(or back). No user serviceable parts inside.

zThis may cause an electric shock or a fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are

any unusual sounds or smells coming from it - unplug it

immediately and contact an authorized dealer or service.

zThis may cause an electric shock or a fire.

Do not place any heavy objects on the monitor.

zThis may cause an electric shock or a fire.

For each hour of looking at the monitor, you should let your eyes

rest for 5 minutes.

zThis will reduce eye fatigue.

Do not use or store inflammable substances near the monitor.

zThis may cause an explosion or fire.

Do not try to move the monitor by pulling on the wire or the signal

cable.

zThis may cause a breakdown, electric shock or a fire due to

damage to the cable.

Do not move the monitor right or left by pulling only the wire or the

signal cable.

zThis may cause a breakdown, electric shock or a fire due to

damage to the cable.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

Keep the monitor away from any magnetic substances.

zThis may cause discoloring or distortion of the image.

Main > Introduction > Unpacking

Unpacking

Front

Rear

Bottom

Monitor and Stand

(Some models include a stand attached. )

Please make sure the following items are

included with your monitor. If any items are

missing,

contact your dealer.

Power Cord

Stand

Signal Cable

Quick Setup Guide

Warranty Card

(Not available in all locations)

User's Guide and

Driver Installation CD

USB Hub (Option)

Main > Introduction > Front

Unpacking

Front

Rear

Bottom

1. Exit button Use this button to Exit the active menu or the OSD.

2,3. Adjust buttons These buttons allow you to highlight and adjust items in the menu.

4. Menu button Use this button to open the OSD and activate a highlighted menu item.

5. Power indicator This light glows green during normal operation, and blinks green once as

the monitor saves your adjustments.

6. Power button Use this button to turn the monitor on and off.

Note: See PowerSaver described in the manual for further information regarding power saving

functions. For energy conservation, turn your monitor OFF when it is not needed, or when

leaving it unattended for long periods.
