LED Display

Installation Manual

Cabinet : LH008IWR (P0.84)

Media Box : SBB-MBOXR48

Ver. 2.0

Samsung Electronics

Revision History

Version Date (Y/M/D)

Description

2.0 2020/03/20

New

Release

Samsung Electronics

When humidity get into LED package because of high humidity, it is

possible to cause ‘Line defect’ by electrical short in side of LED

Package.

For keeping quality of products during installation, please refer below

cautions.

-If one of below case meet before installation, MUST do dehumidification process.

∙Case when vacuum packaging is broken before unpacking.

∙Case when environment condition is exceed Samsung recommended operation condition.

(Please refer Operation condition from User manual)

∙Case when period between unpacking and turning on the power of products is spent

more than 7days, even though it is under Samsung recommended storage condition.

∙Case when production date on the label is exceed more than 6 months, even though

vacuum packaging is no problem.

-When Volatile chemicals such as oil paint, solvent are used or operation condition

is exceed around of products installed place, MUST play video more than 2 hours

everyday.

-If it is not meet with upper cases, it is helpful to play video more than 2 hours

everyday for protection for humidity getting into LED Package.

Dehumidification guidance –during installation

Samsung Electronics

Electrical short in package is possible to happen during products are

working.

For keeping quality of products during installation, please refer below

cautions.

-If one of below case meet during operation, MUST do dehumidification process.

∙Case when environment condition is exceed operation condition.

∙Case when products are not working more than 1 month, even though environment

condition is under operation condition.

-When environment condition is exceed operation condition, products are out of

warranty. Please check environment condition.

-Even products are operating, if the installed place have extra construction such as

interior modification, MUST do dehumidification following installation condition.

-It is possible to happen dew condensation on surface of products, even though

working on operating condition. When happening dew condensation, MUST

operate after cleaning the dew condensation & dehumidification.

Dehumidification guidance –during operation

Samsung Electronics

Dew condensation due to overcooling

Even though meet with Samsung recommended operation

condition, dew condensation is possible to happen when

surface of products is colder than environment temperature or

hot & humid air blow to cooled surface of products.

(cf : Principle of happening dew on surface of glass which have ice)

Case when dew condensation is happen on products, it is

possible to be the root of defect. In this case, it is possible to

be out of warranty.

Samsung Electronics

When install products, please update latest firmware on online

-You can download latest firmware from SLM site.

∙URL of SLM Page : https://www.secslm.com

∙After login Help Download Center에서 Download

∙Before you download firmware, you MUST check same firmware of model (marked red

letter in below) & upper number of version (marked blue in below).

-You can update firmware through LSM.

∙ Please refer ‘7-1 PC control program’ for the way to update firmware.

Guidance of latest firmware

Cabinet : Main - L-xxxMWWAC-nnnn.n xxx = Pan name, nnnn.n = version

FPGA - aabbb_ddddd aa = pixel pitch, bbb = LED package type, ddddd= version

Example : IER P2.5 Cabinet : L-IERMWWAC-1003.1, FPGA : 25252-31046

S-box : TB-KTM2SBMDWWC_100x.x

Samsung Electronics

Table of Contents

1. Product information and precautions for installation

2. Check point about the radiant heat

3. Frame installation

4. Preparation for cabinet installation

5. Cabinet + Frame installation

6. Cabinet + Frame + Bezel installation

7. Disassembly & Front Service

8. Media Box installation and connection

9. LSM Setting & Instructions

10. How to use The Wall

Samsung Electronics

Product installation flow

Check product installation precautions (4~11page)

Check heat dissipation inspection (12~20page)

Installation frame (21~37page)

Installation cabinets and cables (48~83page)

Check cabinet operation (45~47page)

Installation bezel and sensors (84~102page)

Installation Media Box and LSM (125~166page)

Calibration cabinets (167~169page)

Product and peripheral devices operation (172~201page)

Samsung Electronics

1. Product information and precautions for installation

2. Check point about the radiant heat

3. Frame installation

4. Preparation for cabinet installation

5. Cabinet + Frame installation

6. Cabinet + Frame + Bezel installation

7. Disassembly & Front Service

8. Media Box installation and connection

9. LSM Setting & Instructions

10.How to use The Wall

Samsung Electronics

◇Cabinet Installation Components

1. Product Information and Precautions for Installation


Description

Product Certification

Standard guide

Cover

-PCB x1ea

Screw

-Machine (M3*L5)

x1ea

Holder

-Screw (M4*L5) x1ea

Holder

-Screw (M4*L6) x3ea

Cloth

-Clean x1ea


Description

Cabinet

LH008IWR

AC Extension Power

Cable (to Cabinet)

AC Power Cord

(to Wall Outlet)

※ Not included on LH008IWR**/XU

model.

AC Power Cable

(Cabinet to Cabinet)

OCM Cable
