Samsung S22E395H PLUS Manual de usuario

User manual

S22E360H

S22E390H

S22E391H

S22E393H

S22E395H PLUS

S24E360HL

S24E390HL

S24E391HL

S24E393HL

S24E395H PLUS

S27E360F

S27E360H

S27E390H

S27E391H

S27E393H

S27E395H PLUS

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00444A-11

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

7 Copyright

7 Icons used in this manual

8 Cleaning

9 Securing the Installation Space

9 Precautions for storage

10 Safety Precautions

10 Symbols

11 Electricity and Safety

12 Installation and Safety

14 Operation and Safety

18 Correct posture to use the product

PREPARATIONS 19 Checking the Contents

19 Checking the Components

20 Parts

20 Control Panel

21 Direct Key guide

22 Function Key Guide

24 Reverse Side

25 Installation

25 Attaching the Stand

26 Removing the Stand

27 Adjusting the Product Tilt

27 Installing a Wall-mount Kit or Desktop Stand

(S27E360F)

28 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

29 Before Connecting

29 Pre-connection Checkpoints

Table Of Contents

Table Of Contents 3

29 Connecting and Using a PC

29 Connecting to a PC

32 Connecting the Power

34 Driver Installation

35 Setting Optimum Resolution

SCREEN SETUP 36 Brightness

36 Configuring Brightness

37 Contrast

37 Configuring Contrast

38 Sharpness

38 Configuring Sharpness

39 Eye Saver Mode

39 Configuring Eye Saver Mode

40 Game Mode

40 Configuring Game Mode

41 SAMSUNG MAGIC Bright

41 Configuring SAMSUNG MAGIC Bright

43 SAMSUNG MAGIC Upscale

43 Configuring SAMSUNG MAGIC Upscale

44 Image Size

44 Changing the Image Size

46 HDMI Black Level

46 Configuring the HDMI Black Level Settings

47 Response Time

47 Configuring the Response Time

48 H-Position & V-Position

48 Configuring H-Position & V-Position

49 Coarse

49 Adjusting Coarse

Table Of Contents

Table Of Contents 4

50 Fine

50 Adjusting Fine

CONFIGURING TINT 51 Red

51 Configuring Red

52 Green

52 Configuring Green

53 Blue

53 Configuring Blue

54 Color Tone

54 Configuring the Color Tone Settings

55 Gamma

55 Configuring Gamma

COORDINATING OSD 56 Language

56 Configuring Language

57 Menu H-Position & Menu V-Position

57 Configuring Menu H-Position & Menu V-

Position

58 Display Time

58 Configuring Display Time

59 Transparency

59 Changing Transparency

SETUP AND RESET 60 Reset All

60 Initializing Settings (Reset All)

61 Eco Saving Plus

61 Configuring Eco Saving Plus

62 Off Timer

62 Configuring Off Timer

63 Configuring Turn Off After

Table Of Contents

Table Of Contents 5

64 PC/AV Mode

64 Configuring PC/AV Mode

65 Key Repeat Time

65 Configuring Key Repeat Time

66 Source Detection

66 Configuring Source Detection

67 Power LED On

67 Configuring Power LED On

INFORMATION MENU AND

OTHERS

68 INFORMATION

68 Displaying INFORMATION

69 Configuring Brightness, Contrast and

Sharpness from the Initial Screen

70 Configuring Volume in the Initial Screen

70 Volume

INSTALLING THE

SOFTWARE

71 Easy Setting Box

71 Installing the Software

72 Removing the Software

TROUBLESHOOTING

GUIDE

73 Requirements Before Contacting

Samsung Customer Service Center

73 Testing the Product

73 Checking the Resolution and Frequency

73 Check the following.

76 Q & A

SPECIFICATIONS 78 General (S22E360H / S22E390H /

S22E391H / S22E393H / S22E395H

PLUS)

79 General (S24E360HL / S24E390HL /

S24E391HL / S24E393HL / S24E395H

PLUS)

Table Of Contents

Table Of Contents 6

80 General (S27E360F / S27E360H /

S27E390H / S27E391H / S27E393H /

S27E395H PLUS)

82 PowerSaver

83 Standard Signal Mode Table

APPENDIX 85 Contact SAMSUNG WORLD WIDE

94 Responsibility for the Pay Service (Cost

to Customers)

94 Not a product defect

94 A Product damage caused by customer's fault

94 Others

95 Correct Disposal

95 Correct Disposal of This Product (Waste

Electrical & Electronic Equipment)

96 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair center and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cord from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cord to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 85) if the inside of the monitor needs

cleaning. (A service fee will be charged.)

10 cm

(3.93

inches)

10 cm

(3.93

inches)

10 cm(3.93 inches)

10 cm

(3.93 inches)

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.
