Samsung LS22E390 Manual de usuario

User manual

S22E360H

S22E390H

S24E360HL

S24E390HL

S27E360H

S27E390H

The color and the appearance may differ depending on

the product, and the specifications are subject to

change without prior notice to improve the performance.

BN46-00384A-00

S27E360F

Table Of Contents 2

Table Of Contents

BEFORE USING THE

PRODUCT

6 Copyright

6 Icons used in this manual

7 Cleaning

8 Securing the Installation Space

8 Precautions for storage

9 Safety Precautions

9Symbols

10 Electricity and Safety

11 Installation and Safety

13 Operation and Safety

17 Correct posture to use the product

PREPARATIONS 18 Checking the Contents

18 Checking the Components

19 Parts

19 Frontal Buttons

21 Reverse Side

22 Installation

22 Attaching the Stand

23 Removing the Stand

24 Adjusting the Product Tilt

25 Anti-theft Lock

CONNECTING AND USING

A SOURCE DEVICE

26 Before Connecting

26 Pre-connection Checkpoints

26 Connecting and Using a PC

26 Connecting to a PC

28 Connecting the Power

29 Driver Installation

30 Setting Optimum Resolution

SCREEN SETUP 31 Brightness

31 Configuring Brightness

Table Of Contents

Table Of Contents 3

32 Contrast

32 Configuring Contrast

33 Sharpness

33 Configuring Sharpness

34 Game Mode

34 Configuring Game Mode

35 SAMSUNG MAGIC Bright

35 Configuring SAMSUNG MAGIC Bright

37 SAMSUNG MAGIC Angle

(S22E360H / S22E391H)

37 Configuring SAMSUNG MAGIC Angle

39 SAMSUNG MAGIC Upscale

39 Configuring SAMSUNG MAGIC Upscale

40 Image Size

40 Changing the Image Size

42 HDMI Black Level

42 Configuring the HDMI Black Level Settings

43 Response Time (S24E360HL /

S24E391HL / S27E 360H / S27E391H)

43 Configuring the Response Time

44 H-Position & V-Position

44 Configuring H-Position & V-Position

46 Coarse

46 Adjusting Coarse

47 Fine

47 Adjusting Fine

CONFIGURING TINT 48 Red

48 Configuring Red

49 Green

49 Configuring Green

Table Of Contents

Table Of Contents 4

50 Blue

50 Configuring Blue

51 Color Tone

51 Configuring the Color Tone Settings

52 Gamma

52 Configuring Gamma

COORDINATING OSD 53 Language

53 Configuring Language

54 Menu H-Position & Menu V-Position

54 Configuring Menu H-Position &

Menu V-Position

55 Display Time

55 Configuring Display Time

56 Transparency

56 Changing Transparency

SETUP AND RESET 57 Reset All

57 Initializing Settings (Reset All)

58 Eco Saving

58 Configuring Eco Saving

59 Off Timer

59 Configuring Off Timer

60 Configuring Turn Off After

61 PC/AV Mode

61 Configuring PC/AV Mode

62 Key Repeat Time

62 Configuring Key Repeat Time

63 Source Detection

63 Configuring Source Detection

Table Of Contents

Table Of Contents 5

INFORMATION MENU AND

OTHERS

64 INFORMATION

64 Displaying INFORMATION

65 Configuring Brightness and Contrast in

the Initial Screen

INSTALLING THE

SOFTWARE

66 Easy Setting Box

66 Installing the Software

67 Removing the Software

TROUBLESHOOTING

GUIDE

68 Requirements Before Contacting

Samsung Customer Service Center

68 Testing the Product

68 Checking the Resolution and Frequency

68 Check the following.

71 Q & A

SPECIFICATIONS 73 General

75 PowerSaver

76 Standard Signal Mode Table

APPENDIX 78 Contact SAMSUNG WORLD WIDE

84 Responsibility for the Pay Service

(Cost to Customers)

84 Not a product defect

84 A Product damage caused by customer's fault

84 Others

86 Correct Disposal

86 Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

87 Terminology

INDEX

Before Using the Product

The contents of this manual are subject to change without notice to improve quality.

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is

prohibited.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.

Icons used in this manual

An administration fee may be charged if either

(a) an engineer is called out at your request and there is no defect in the product

(i.e. where you have failed to read this user manual).

(b) you bring the unit to a repair centre and there is no defect in the product

(i.e. where you have failed to read this user manual).

The amount of such administration charge will be advised to you before any work or home visit is

carried out.

The following images are for reference only. Real-life situations may

differ from what is shown in the images.

Before Using the Product

Cleaning

Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

Take the following steps when cleaning.

1. Power off the monitor and computer.

2. Disconnect the power cable from the monitor.

Hold the power cable by the plug and do not touch the cable with wet

hands. Otherwise, an electric shock may result.

3. Wipe the monitor screen using a clean, soft and dry cloth.

Do not apply a cleaning agent that contains alcohol,

solvent, or surfactant to the monitor.

Do not spray water or detergent directly on the product.

4. Wet a soft and dry cloth in water and wring thoroughly to clean the

exterior of the monitor.

5. Connect the power cable to the product after cleaning the product.

6. Power on the monitor and computer.

Before Using the Product

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire

and damage the product. Be sure to allow the amount of space as shown below or greater when

installing the product.

The exterior may differ depending on the product.

Precautions for storage

Be sure to contact Samsung Customer Service Center (page 78) if the inside of the monitor needs

cleaning. (A service fee will be charged.)

(10 cm)3.93inches

(10 cm)

3.93

inches

(10 cm)

3.93

inches

3.93inches

(10 cm)

3.93

inches

Before Using the Product

Safety Precautions

Symbols

Caution

RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR

BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO

QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside. It is dangerous to

make any kind of contact with any internal part of this product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Warning A serious or fatal injury may result if instructions are not followed.

Caution

Personal injury or damage to properties may result if instructions are

not followed.

Activities marked by this symbol are prohibited.

Instructions marked by this symbol must be followed.

Before Using the Product

Electricity and Safety

The following images are for reference only. Real-life situations may differ from what is shown in the

images.

Warning

Do not use a damaged power cable or plug, or a loose power socket.

An electric shock or fire may result.

Do not plug many products into the same power socket.

Otherwise, the socket may overheat and cause a fire.

Do not touch the power plug with wet hands.

Otherwise, an electric shock may result.

Insert the power plug all the way in so it is not loose.

An unstable connection may cause a fire.

Ensure you connect the power plug to a grounded power socket

(type 1 insulated devices only).

An electric shock or injury may result.

Do not bend or pull the power cable with force. Do not weigh the power cable

down with a heavy object.

A damaged power cable may cause an electric shock or fire.

Do not place the power cable or product near heat sources.

An electric shock or fire may result.

Remove foreign substances such as dust around the plug pins and power socket

with a dry cloth.

Otherwise, a fire may result.
