Unpacking your Monitor

Please make sure the following items are included with

your computer monitor:

Monitor and Stand

Power Cable

This Manual

Warranty Card

(Not available in all

areas)

Signal Cable

CS9839-E 10/8/98 10:51 AM Page ii

Table of Contents

Preface: Safety Information . . . . . . . . . .2

Chapter One: Overview of Your

Monitor . . . . . . . . . . . . . . . . . . . . . . . . .3

Front Panel.....................................................................................3

Rear Panel......................................................................................4

Chapter Two: Installation . . . . . . . . . . . . .5

Connecting Your Monitor to a Computer ..................................5

Chapter Three: Adjusting Your Monitor . .6

Overview........................................................................................6

Brightness......................................................................................6

Contrast..........................................................................................6

Direct Access Features...............................................................7

Position....................................................................................7

Size...........................................................................................7

Pincushion/Trapezoid............................................................7

Parallel/Rotation....................................................................8

Menu Features..............................................................................8

Color temperature .................................................................8

Color Control...........................................................................9

Degauss...................................................................................9

Recall.......................................................................................9

Menu Position......................................................................10

Menu Duration.....................................................................10

D-SUB / BNC ........................................................................11

Pinbalance............................................................................11

Clear Moire...........................................................................11

Language ..............................................................................12

Display Timing ......................................................................12

Video Input Level.................................................................12

Sync. Input Type...................................................................13

Exit..........................................................................................13

PowerSaver.................................................................................14

Troubleshooting..........................................................................15

Appendix . . . . . . . . . . . . . . . . . . . . . . . . .16

Specifications..............................................................................16

Pin Assignments.........................................................................17

Display Modes Timing Chart.....................................................18

CS9839-E 10/8/98 10:52 AM Page 1

Preface: Safety Information

Please read and follow these instruc-

tions when connecting and using your

computer monitor.

1Before connecting the AC power

cord to an outlet, make sure the

voltage designation on your moni-

tor corresponds to the local elec-

trical supply.

2Never insert anything metallic into

the monitor openings. Doing so

may create the danger of electric

shock.

3To avoid electric shock, never

touch the inside of the monitor.

Only a qualified technician should

open the monitor’s case.

4Never use your monitor if the

power cord has been damaged.

Do not allow anything to rest on

the power cord, and keep the cord

away from where people could

trip over it.

5Be sure to hold the plug, not the

cord, when disconnecting the

monitor from an electric socket.

6Openings in the monitor cabinet

are provided for ventilation. To

prevent overheating, these open-

ings should not be blocked or cov-

ered. Also, avoid using the monitor

on a bed, sofa, rug, or other soft

surface. Doing so may block the

ventilation openings in the bottom

of the cabinet. If you put the moni-

tor in a bookcase or some other

enclosed space, be sure to pro-

vide adequate ventilation.

7Put your monitor in a location with

low humidity and a minimum of

dust. Avoid places like damp

basements or dusty hallways.

8Do not expose the monitor to rain

or use it near water (in kitchens,

next to swimming pools, etc.). If

the monitor accidentally gets wet,

unplug it and contact an autho-

rized dealer immediately. You can

clean the monitor with a damp

cloth when necessary, but be sure

to unplug the monitor first.

9Place the monitor on a solid sur-

face and treat it carefully. The

screen is made of glass and can

be damaged if dropped or sharply

hit.

10Locate your monitor near an easily

accessible AC outlet.

11If your monitor does not operate

normally – in particular, if there

are any unusual sounds or smells

coming from it – unplug it immedi-

ately and contact an authorized

dealer or service center.

12High temperatures can cause

problems. Don’t use your monitor

in direct sunlight, and keep it away

from heaters, stoves, fireplaces,

and other sources of heat.

13Unplug the monitor when it is

going to be left unused for an

extended period of time.

14Unplug your monitor from the AC

outlet before any service.

CS9839-E 10/8/98 10:52 AM Page 2

Chapter One: Overview of Your Monitor

Front Panel

1,button

Use this button to adjust the position or size.

2, button

Use this button to adjust the pincushion/trapezoid

or parallel/rotation.

3▲,▼,$, % buttons

Use these buttons to choose or adjust items in the

on-screen display.

4, MENU button

Use this button to activate the on-screen display, to

enter a selection in the on-screen display, or to exit

the on-screen displays.

5Power indicator

This light glows green during normal operation, and

blinks amber once as your adjustments are saved.

6Power button

Use this button to turn the monitor on and off.

1 2 3 4

5 6

CS9839-E 10/8/98 10:52 AM Page 3

Chapter One: Overview of Your Monitor

Rear Panel

1Power port

Connect the power cable here.

2Signal port

Connect your signal cable here.

3BNC signal port

Connect a BNC signal cable here. (BNC signal

cable not included)

CS9839-E 10/8/98 10:52 AM Page 4

Chapter Two: Installation

Connecting Your Monitor

to a Computer

1Turn off your computer and unplug

its power cord.

2Connect the signal cable to the

D-SUB or BNC signal port on the

back of your monitor.

3If you are using a Macintosh com-

puter, connect the other end of the

signal cable to a Macintosh

adapter. (The adapter is not includ-

ed with your monitor. Contact your

dealer for more information.) If you

are using an IBM-compatible com-

puter, skip to step 5.

4Follow the instructions included

with your adapter to set the pins

on your adapter, if necessary.

5Connect the signal cable (with the

adapter if necessary) to the video

port on the back of your computer.

This port might be directly

attached to your computer, or it

might be part of a video board,

video card, or graphics card.

6Connect the power cord for your

monitor to the power port on the

back of the monitor.

7Plug the power cords of your com-

puter and your monitor into a near-

by outlet.

8Turn on your computer and mon-

itor. If your monitor displays an

image, installation is complete.

Note: You can download the monitor

driver from the internet at

http://www.sec.samsung.co.kr (Enter)

Select Support => File download =>

Monitor => your Monitor name.

For directions on completing the monitor

configuration process, click on install.txt

(Windows 95 driver installation guide).

CS9839-E 10/8/98 10:52 AM Page 5

Overview

Your Samsung SyncMaster computer monitor allows you

to easily adjust the characteristics of the image being

displayed. All of these adjustments are made using the

control buttons on the front of the monitor. These buttons

operate the on-screen menu, which shows you the

monitor’s settings and allows you to change those set-

tings

1Brightness

This feature will adjust the overall brightness of the

display image. Rotate the rotary control to the right

to increase the level of brightness, or to the left to

decrease the brightness.

2Contrast

This feature will adjust the monitor’s contrast.

Rotate the rotary control to the right to increase the

contrast between dark colors and light colors, or

move it to the left to decrease the contrast.

Chapter Three: Adjusting Your Monitor

1 2

CS9839-E 10/8/98 10:52 AM Page 6

Chapter Three: Adjusting Your Monitor

Direct-Access Features

The features described on this page can be accessed

quickly, at the touch of one button. Once you have adjust-

ed one of these features, push the button once or twice

to turn off the display.

Position

Follow these instructions to change the position of the

monitor’s entire display.

1With the menu off, push the button. The posi-

tion display will appear.

2Use the ▲and ▼buttons to change the vertical

position of the monitor’s entire display; use the $

and %buttons to change the horizontal position of

the monitor’s entire display.

Size

Follow these instructions to change the size of the moni-

tor’s entire display.

1With the menu off, push the button twice. The

size display will appear.

2Push the ▲or ▼buttons to change the vertical size

of the monitor’s display; push the $or %buttons to

change the horizontal size of the monitor’s display.

Pincushion/Trapezoid

Adjust the pincushion setting when the sides of the dis-

play are bowed in or bowed out; adjust the trapezoid set-

ting when the top or bottom of the display is too large or

too small.

1With the menu off, push the button. The

Pincushion/Trapezoid display will appear.

2Use the $button or %button to adjust the pincush-

ion setting; use the ▲button or ▼button to adjust

the trapezoid setting.

CS9839-E 10/8/98 10:52 AM Page 7

Chapter Three: Adjusting Your Monitor

Parallel/Rotation

Adjust the parallelogram setting when the display is lean-

ing left or right; adjust the rotation setting when the entire

display is tilted left or right.

1With the menu off, push the button twice.

The parallelogram/rotation display will appear.

2Use the $button or %button to adjust the parallel

setting; use the ▲button or ▼button to adjust the

rotation setting.

Menu Features

The following features can all be accessed using your

monitor’s on-screen menu system. Follow the instructions

below to adjust the features.

Once you are finished making adjustments to a feature,

push the MENU button to return to the Main Menu, then

push MENU again to turn off the menu.

Color Temperature

Follow these steps to change the color temperature set-

ting. Color temperature is a measure of the “warmth” of

the image colors.

1With the menu off, push the MENU button. Push the

$button or %button until the “Color Temperature”

screen is displayed.

2Push the button. The color temperature

adjustment screen will appear.

3Use the $button or %button to adjust the color

temperature.

CS9839-E 10/8/98 10:52 AM Page 8

Tabla de contenidos

Otros manuales de Monitor de Samsung

Samsung

Samsung SyncMaster 152MP Manual de usuario

Samsung

Samsung SMC-211FN Manual de usuario

Samsung

Samsung HP-R4252C Manual de usuario

Samsung

Samsung SyncMaster C27A650X Manual de usuario

Samsung

Samsung SP-P4251 Manual de usuario

Samsung

Samsung LS27R650FDUXXU Manual de usuario

Samsung

Samsung 460FP-2 - SyncMaster - 46" LCD Flat Panel... Guía del usuario

Samsung

Samsung C27FG73FQU Manual de usuario

Samsung

Samsung 305T - SyncMaster - 30" LCD Monitor Manual de usuario

Samsung

Samsung SyncMaster 2043BW Manual de usuario

Samsung

Samsung 953BW - SyncMaster - 19" LCD Monitor Manual de usuario

Samsung

Samsung SyncMaster 320TSn-2 Manual de usuario

Samsung

Samsung SyncMaster P2450H Manual de usuario

Samsung

Samsung GY15MS series Manual de usuario

Samsung

Samsung SyncMaster 711ND Manual de usuario

Samsung

Samsung SyncMaster 150N Manual de instrucciones

Samsung

Samsung SyncMaster 957p Manual de usuario

Samsung

Samsung SyncMaster 2043BW Manual de usuario

Samsung

Samsung SyncMaster 550DX Manual de usuario

Samsung

Samsung C32F39MFU Series Manual de usuario

Samsung

Samsung Flip WM55H Manual de usuario

Samsung

Samsung SyncMaster ME40A Manual de usuario

Samsung

Samsung Odyssey Ark S55BG97 Series Manual de usuario

Samsung

Samsung S32BM50 Series Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
