Samsung C27F591FDU Manual de usuario

User Manual

The colour and the appearance may differ depending on the product, and the specifications are subject to change without prior notice

to improve the performance.

The contents of this manual are subject to change without notice to improve quality.

ⓒSamsung Electronics

Samsung Electronics owns the copyright for this manual.

Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.

Trademarks other than that of Samsung Electronics are owned by their respective owners.

C27F591FD

Table of contents

Before Using the Product

Securing the Installation Space 4

Precautions for storage 4

Safety Precautions 4

Symbols 4

Cleaning 5

Electricity and Safety 5

Installation 6

Operation 7

Preparations

Parts 9

Control Panel 9

Direct Key guide 10

Function Key Guide 11

Changing Brightness, Contrast and Sharpness

settings 13

Changing the Volume setting 13

Reverse Side 14

Adjusting the Product Tilt 14

Anti-theft Lock 15

Precautions for moving the monitor 15

Installation 16

Attaching the Stand 16

Removing the Stand 17

Connecting and Using a Source Device

Pre-connection Checkpoints 18

Connecting and Using a PC 18

Connection Using the D-SUB Cable (Analogue Type) 18

Connection Using the HDMI Cable 19

Connection Using an HDMI-DVI Cable 19

Connection Using an DP Cable 19

Connecting to Headphones 19

Connecting the Power 20

Correct posture to use the product 20

Driver Installation 21

Setting Optimum Resolution 21

Screen Setup

SAMSUNG MAGIC Bright 22

Brightness 23

Contrast 23

Sharpness 23

Color 23

SAMSUNG MAGIC Upscale 24

HDMI Black Level 24

Eye Saver Mode 24

Game Mode 24

Response Time 24

Picture Size 25

Screen Adjustment 25

Adjusting OSD (On Screen Display)

settings

Transparency 26

Position 26

Language 26

Display Time 26

Table of contents

Setup and Reset

Sound 27

Volume 27

Sound Mode 27

Select Sound 27

FreeSync 28

Eco Saving Plus 29

Off Timer 29

PC/AV Mode 30

Source Detection 30

Key Repeat Time 30

Power LED On 30

Reset All 30

Information 30

Installing the Software

Easy Setting Box 31

Restrictions and Problems with the Installation 31

System Requirements 31

Troubleshooting Guide

Requirements Before Contacting Samsung

Customer Service Centre 32

Testing the Product 32

Checking the Resolution and Frequency 32

Check the following. 32

Q & A 34

Specifications

General 35

Standard Signal Mode Table 36

Appendix

Responsibility for the Pay Service

(Cost to Customers) 38

Not a product defect 38

A Product damage caused by customer's fault 38

Others 38

Securing the Installation Space

Ensure some space around the product for ventilation. An internal temperature rise may cause fire and damage the

product. Be sure to allow the amount of space as shown below or greater when installing the product.

―The exterior may differ depending on the product.

10 cm

10 cm 10 cm

10 cm

Precautions for storage

High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used nearby.

―Contact your nearest Samsung Customer Service Centre if you want to clean the inside of the product (Service fee will be

charged.)

Do not press the monitor screen with hands or other objects. There is a risk of damaging the screen.

Safety Precautions

Caution RISK OF ELECTRIC SHOCK DO NOT OPEN

Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER.

(OR BACK)

THERE ARE NO USER SERVICEABLE PARTS INSIDE.

REFER ALL SERVICING TO QUALIFIED PERSONNEL.

This symbol indicates that high voltage is present inside.

It is dangerous to make any kind of contact with any internal part of this

product.

This symbol alerts you that important literature concerning operation and

maintenance has been included with this product.

Symbols

Warning A serious or fatal injury may result if instructions are not followed.

Caution Personal injury or damage to properties may result if instructions are not

followed.

Before Using the Product

Chapter 01

Cleaning

―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.

―Take the following steps when cleaning.

Power off the product and computer.

Disconnect the power cord from the product.

―Hold the power cable by the plug and do not touch the cable with wet hands. Otherwise, an electric shock may result.

Wipe the monitor with a clean, soft and dry cloth.

-Do not apply a cleaning agent that contains alcohol, solvent, or surfactant to the monitor.

-Do not spray water or detergent directly on the product.

Wet a soft and dry cloth in water and wring thoroughly to clean the exterior of the product.

Connect the power cord to the product when cleaning is finished.

Power on the product and computer.

Electricity and Safety

Warning

•Do not use a damaged power cord or plug, or a loose power socket.

•Do not use multiple products with a single power socket.

•Do not touch the power plug with wet hands.

•Insert the power plug all the way in so it is not loose.

•Connect the power plug to a grounded power socket (type 1 insulated devices only).

•Do not bend or pull the power cord with force. Be careful not to leave the power cord under a heavy object.

•Do not place the power cord or product near heat sources.

•Clean any dust around the pins of the power plug or the power socket with a dry cloth.

Caution

•Do not disconnect the power cord while the product is being used.

•Only use the power cord provided with your product by Samsung. Do not use the power cord with other

products.

•Keep the power socket where the power cord is connected unobstructed.

-The power cord must be disconnected to cut off power to the product when an issue occurs.

•Hold the plug when disconnecting the power cord from the power socket.

Warning

•DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF THE PRODUCT. DO NOT INSTALL THE

PRODUCT NEAR HEAT SOURCES.

•Do not install the product in poorly ventilated spaces such as a bookcase or closet.

•Install the product at least 10cm away from the wall to allow ventilation.

•Keep the plastic packaging out of the reach of children.

-Children may suffocate.

•Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.)

-The product may fall and become damaged and/or cause an injury.

-Using the product in an area with excess vibration may damage the product or cause a fire.

•Do not install the product in a vehicle or a place exposed to dust, moisture (water drips, etc.), oil, or smoke.

•Do not expose the product to direct sunlight, heat, or a hot object such as a stove.

-The product lifespan may be reduced or a fire may result.

•Do not install the product within the reach of young children.

-The product may fall and injure children.

•Edible oil, such as soybean oil, can damage or deform the product. Do not install the product in a kitchen or near

a kitchen counter.

Caution

•Do not drop the product while moving.

•Do not set down the product on its front.

•When installing the product on a cabinet or shelf, make sure that the bottom edge of the front of the product is

not protruding.

-The product may fall and become damaged and/or cause an injury.

-Install the product only on cabinets or shelves of the right size.

•Set down the product gently.

-Product failure or personal injury may result.

•Installing the product in an unusual place (a place exposed to a lot of fine dust, chemical substances, extreme

temperatures or a significant presence of moisture, or a place where the product will operate continuously for an

extended period of time) may seriously affect its performance.

-Be sure to consult Samsung Customer Service Centre if you want to install the product at such a place.

Installation

Warning

•There is a high voltage inside the product. Never disassemble, repair or modify the product yourself.

-Contact Samsung Customer Service Centre for repairs.

•To move the product, first disconnect all the cables from it, including the power cable.

•If the product generates abnormal sounds, a burning smell or smoke, disconnect the power cord immediately

and contact Samsung Customer Service Centre.

•Do not let children hang from the product or climb on top of it.

-Children may become injured or seriously harmed.

•If the product is dropped or the outer case is damaged, turn off the power and disconnect the power cord. Then

contact Samsung Customer Service Centre.

-Continued use can result in a fire or electric shock.

•Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the product.

-The product or heavy objects may fall as children try to reach for the toys or sweets resulting in a serious injury.

•During a lightning or thunderstorm, power off the product and remove the power cable.

•Do not drop objects on the product or apply impact.

•Do not move the product by pulling the power cord or any cable.

•If a gas leakage is found, do not touch the product or power plug. Also, ventilate the area immediately.

•Do not lift or move the product by pulling the power cord or any cable.

•Do not use or keep combustible spray or an inflammable substance near the product.

•Ensure the vents are not blocked by tablecloths or curtains.

-An increased internal temperature may cause a fire.

•Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn easily (paper, matches, etc)

into the product (via the vent or input/output ports, etc).

-Be sure to power off the product and disconnect the power cord when water or other foreign substances

have entered the product. Then contact Samsung Customer Service Centre.

•Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on top of the product.

-Be sure to power off the product and disconnect the power cord when water or other foreign substances

have entered the product. Then contact Samsung Customer Service Centre.

Operation

Caution

•Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or

defective pixels.

-Activate power-saving mode or a moving-picture screen saver if you will not be using the product for an

extended period of time.

•Disconnect the power cord from the power socket if you do not plan on using the product for an extended

period of time (vacation, etc).

-Dust accumulation combined with heat can cause a fire, electric shock or electric leakage.

•Use the product at the recommended resolution and frequency.

-Your eyesight may deteriorate.

•Do not put DC power adapters together.

•Remove the plastic bag from the DC power adapter before you use it.

•Do not let water enter the DC power device or get the device wet.

-An electric shock or fire may result.

-Avoid using the product outdoors where it can be exposed to rain or snow.

-Be careful not to get the DC power adapter wet when you wash the floor.

•Do not put the DC power adapter near to any heating apparatus.

-Otherwise, a fire may result.

•Keep the DC power adapter in a well-ventilated area.

•If you place the AC/DC power adapter so that it is hanging with the cord input facing upwards, water or other

foreign substances could enter the Adapter and cause the Adapter to malfunction.

Make sure to rest the AC/DC power adapter flat on a table or the floor.

•Do not hold the product upside-down or move it by holding the stand.

-The product may fall and become damaged or cause an injury.

•Looking at the screen too close for an extended period of time can deteriorate your eyesight.

•Do not use humidifiers or stoves around the product.

•Rest your eyes for more than 5 minutes for every 1 hour of product use.

•Do not touch the screen when the product has been turned on for an extended period of time as it will become

hot.

•Store small accessories out of the reach of children.

•Exercise caution when adjusting the product angle or stand height.

-Your hand or finger may get stuck and injured.

-Tilting the product at an excessive angle may cause the product to fall and an injury may result.

•Do not place heavy objects on the product.

-Product failure or personal injury may result.

•When using headphones or earphones, do not turn the volume too high.

-Having the sound too loud may damage your hearing.

Preparations

Chapter 02

Parts

Control Panel

―The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to

improve quality.

LEFT

Return

JOG Button Function Key Guide

RIGHT

DOWN

PRESS(ENTER)

Power LED

Icons Description

JOG Button

Multi directional button that helps navigate.

―The JOG button is located on the rear left side of the product. The button can be

used to move up, down, left or right, or as Enter.

Power LED

This LED is power status indicator and works as

•Power On (Power button): Off

•Power saving mode: Blinking

•Power Off (Power button): On

―The power Indicator operation can be swapped by changing in the menu.

(System Power LED On) Actual models because of functional variation

maybe haven’t this function.

Function Key Guide

Press the JOG button when the screen is turned on. The Function Key Guide

will appear. To access the onscreen menu when the guide is displayed, press

the corresponding direction button again.

―Function Key Guide may vary depending on the function or product model.

Please refer to the actual product.

Analog mode

Brightness

Auto Adjustment

Volume

Features

Eye Saver Mode Off

―Analog mode option

•: Adjust Brightness, Contrast, Sharpness.

•: Auto Adjustment.

―Changing the resolution in Display Properties will activate the Auto Adjustment function.

―This function is only available in Analog mode.

•: Adjust Volume, Mute.

•: Display Function Key Guide.

HDMI,DisplayPort mode

Brightness

Volume

Features

Eye Saver Mode Off

―HDMI,DisplayPort mode option

•/: Adjust Brightness, Contrast, Sharpness.

•: Adjust Volume, Mute.

•: Display Function Key Guide.

Direct Key guide

―The shortcut button screen (OSD menu) shown below is displayed only when the monitor screen is turned on, the computer resolution changes, or the input source changes.

―The function buttons page shows if Eye Saver Mode is enabled.

: On

: Off

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Monitor de Samsung

Samsung

Samsung SyncMaster 761BF Manual de usuario

Samsung

Samsung SyncMaster 400UX-3 Manual de usuario

Samsung

Samsung S32R750QEN Manual de usuario

Samsung

Samsung SyncMaster 152 V Instrucciones de uso

Samsung

Samsung SyncMaster S24B750V Manual de usuario

Samsung

Samsung SyncMaster 957MB Manual de usuario

Samsung

Samsung SyncMaster S20B300B Guía del usuario

Samsung

Samsung OH46F Manual de usuario

Samsung

Samsung SyncMaster 721N Manual de usuario

Samsung

Samsung SyncMaster 181 T Manual de usuario

Samsung

Samsung 2433BW - SyncMaster - 24" LCD Monitor Manual de usuario

Samsung

Samsung 570DX - SyncMaster - 57" LCD Flat Panel... Manual de usuario

Samsung

Samsung SyncMaster NC220 Manual de usuario

Samsung

Samsung T220HD - SyncMaster - 22" LCD Monitor Manual de usuario

Samsung

Samsung 2233RZ - Syncmaster 22" 3D Gaming LCD Monito Manual de usuario

Samsung

Samsung NC191 Manual de usuario

Samsung

Samsung SyncMaster P2470LHD Manual de usuario

Samsung

Samsung HE40A Manual de usuario

Samsung

Samsung SyncMaster 245B, 245BW Manual de usuario

Samsung

Samsung SyncMaster 932NPLUS Manual de usuario

Samsung

Samsung SyncMaster CSH7839L Manual de usuario

Samsung

Samsung LB15VS Manual de usuario

Samsung

Samsung S34C65 V Series Manual de usuario

Samsung

Samsung SyncMaster 150T Manual de usuario

Manuales populares de Monitor de otras marcas

Linear Acoustic

Linear Acoustic LQ-1000 Manual de usuario

AOC

AOC I2579V Manual de usuario

Gateway

Gateway FPD1520 Manual de usuario

Furuno

Furuno Mu 120c Manual de usuario

Asus

Asus VB171D - 17" LCD Monitor Manual de usuario

Dell

Dell S2230MX Instrucciones de uso

Philips

Philips 107C64 Manual de usuario

Dell

Dell S2409WFP Manual de usuario

EverFocus

EverFocus EN-7517E Manual de usuario

Panasonic

Panasonic TH152UX1 - 152" PLASMA TV Manual de usuario

Dell

Dell Precision 7680 Manual de instrucciones

LG 50PM1M - - 50" Plasma Panel Manual de usuario

Bosch

Bosch DDU 9 Manual de usuario

Acer

Acer A231HL Manual de usuario

Philips

Philips 86BDL4152T Manual de usuario

NEC

NEC AccuSync LCD5V Manual de usuario

Emay

Emay SleepO2 Manual de usuario

IBM

IBM 6360 Instrucciones de instalación
