Samsung 151MP - SyncMaster 151 MP Manual de usuario

SyncMaster 151MP / 171MP

English > Main > Index

Main Page

Safety Instructions

Notational

Power

Installation

Cleaning

Other

Introduction

Unpacking

Front

Rear

Remote Control

Setup

Connecting Your Monitor

Connecting to a Computer

Connecting to Other Devices

Installing the Monitor Driver

Automatic

Manual

Installing a VESA Base

Folding or removing the base

Installing a VESA Base

Adjusting Your LCD Monitor

User Controls

User control buttons

Direct-Access Features

On-Screen Display

OSD Functions

Screen Adjustment Animation Clips

Troubleshooting

Check before Calling for Service

Problems and Solutions

Q & A

Specifications

General Specifications

PowerSaver

Preset Timing Modes

Information

Service Center

Terms

Regulatory

Natural Color

Authority

English > Main > Safety Instructions > Notational

Notational

Power

Installation

Cleaning

Other

Failure to follow directions noted by this symbol could result in bodily harm or damage to equipment.

Prohibited Important to read and understand at all times

Do not disassemble Disconnect the plug from the outlet

Do not touch Grounding to prevent an electric shock

English > Main > Safety Instructions > Power

Notational

Power

Installation

Cleaning

Other

When not used for extended periods of time, set your PC to DPMS. If using a screen

saver, set it to the active screen mode.

Do not use a damaged or loose plug.

zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.

zThis may cause an electric shock or fire.

Use only a properly grounded plug and receptacle.

zAn improper ground may cause electric shock or equipment damage.

Do not excessively bend the plug and wire nor place heavy objects upon them,

which could cause damage.

zThis may cause an electric shock or fire.

Disconnect the plug from the outlet during storms or lightening or if it is not

used for a long period of time.

zFailure to do so may cause an electric shock or fire.

Do not connect too many extension cords or plugs to an outlet.

zThis may cause a fire.

English > Main > Safety Instructions > Installation

Notational

Power

Installation

Cleaning

Other

Do not cover the vents on the monitor cabinet.

zBad ventilation may cause a breakdown or fire.

Put your monitor in a location with low humidity and a minimum of dust.

zAn electric shock or fire could result inside the monitor.

Do not drop the monitor when moving it.

zThis may cause damage to the product or human body.

Place the monitor on a flat and stable surface.

zThe monitor can cause injury by falling.

Set down the monitor carefully.

zIt could be damaged or broken.

Do not place the monitor face down.

zThe TFT-LCD surface may be damaged.

English > Main > Safety Instructions > Cleaning

Notational

Power

Installation

Cleaning

Other

When cleaning the monitor case or the surface of the TFT-LCD, wipe with a slightly

moistened, soft fabric.

Do not spray detergent directly on the monitor.

Use the recommended detergent with a smooth cloth.

If the connector between the plug and the pin is dusty or dirty, clean it properly

with a dry cloth.

zA dirty connector can cause an electric shock or fire.

Do not set a glass of water, chemicals or any small metal objects on the monitor.

zThis may cause damage, electric shock or a fire.

zIf a foreign substance gets into the monitor, disconnect the plug and then

contact a service center.

English > Main > Safety Instructions > Ohter

Notational

Power

Installation

Cleaning

Other

Do not remove cover(or back). No user serviceable parts inside.

zThis may cause an electric shock or a fire.

zRefer servicing to qualified service personnel.

If your monitor does not operate normally - in particular, if there are any unusual

sounds or smells coming from it - unplug it immediately and contact an

authorized dealer or service.

zThis may cause an electric shock or fire.

Do not place any heavy objects on the monitor.

zThis may cause an electric shock or a fire.

For each hour of looking at the monitor, you should let your eyes rest for 5

minutes.

zThis will reduce eye fatigue.

Do not use or store inflammable substances near the monitor.

zThis may cause an explosion or fire.

Do not try to move the monitor by pulling on the wire or the signal cable.

zThis may cause a breakdown, electric shock or a fire due to damage to the

cable.

Do not move the monitor right or left by pulling only the wire or the signal cable.

zThis may cause a breakdown, electric shock or a fire due to damage to the

cable.

Never insert anything metallic into the monitor openings.

zThis may cause an electric shock, fire or injury.

English > Main > Introduction > Unpacking

Unpacking

Front

Rear

Remote Control

Please make sure the following items are included with your monitor. If any items are missing, contact

your dealer.

User's Guide and Natural Color/

Driver Installation CD Power Cord Signal Cable(15 pin D-Sub)

Monitor

Quick Setup Guide DC Adapter

Warranty Card

(Not available in all locations) TV Tuner Box (Option)

Batteries (AAA X 2) Audio Cable

Remote Control Scart Jack

English > Main > Introduction > Front

Unpacking

Front

Rear

Remote Control

For detail information concerning the monitor functions, refer to User Controls under Adjusting Your Monitor.

The monitor's front configuration may vary slightly depending on the monitor model.

1 PC mode button 6 Up-Down button / Channel

button

2 PIP mode button 7 Left-Right button / Volume

button

3 Video mode button 8 Menu button

4 Audio mode button 9 Exit button

5 Power button / Power indicator 10 Auto button

PIP(Picture in Picture)?

Feature allowing one program to be viewed on the entire screen while

one or more programs play in small windows superimposed over the

base program. PIP is also referred to as Split Windows.

English > Main > Introduction > Rear

Unpacking

Front

Rear

Remote Control

For detailed information concerning cable connections, refer to Connecting Cables under Setup.

The monitor's rear configuration may vary slightly depending on the monitor model.

A PC Connection Terminal

1 Power Connection Terminal (12V DC)

2 Computer Connection Terminal (15 Pin D-SUB)

3 Audio Connection Terminal (Audio (ST))

B AV Connection Terminal

1 AV right audio connection terminal (R)

2 AV left audio connection terminal (L)

3 AV video connection terminal

4 S-Video connection terminal

C Antenna Connection Terminal

(When TV is connected)

D Headphone connection terminal
