Samsung SCV-2081 Manual de usuario

High Resolution Vandal-Resistant

Dome Camera

User Manual

SCV-2081

High Resolution Vandal-Resistant Dome Camera

User Manual

Trademark

is the registered logo of Samsung Techwin Co., Ltd.

The name of this product is the registered trademark of Samsung Techwin Co., Ltd.

Other trademarks mentioned in this manual are the registered trademark of their respective company.

Restriction

Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document

shall be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.

Disclaimer

Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but

no formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on

the user’s own responsibility. Samsung Techwin reserves the right to change the contents of this document

without prior notice.

Warranty

If the product does not operate properly in normal conditions, please let us know. Samsung Techwin will resolve

the problem for free of charge. The warranty period is 3 years. However, the followings are excluded:

If the system behaves abnormally because you run a program irrelevant to the system operation.

Deteriorated performance or natural worn-out in process of time

•

■

Before operating the camera, confirm the camera model and correct input power voltage.

To help you understand this manual thoroughly, we’ll introduce our model description.

■ SCV-2081 SERIES

• NTSC MODEL • PAL MODEL

SCV-2081N SCV-2081P

■ MODEL DESCRIPTION

• SCV-2081X

• SIGNAL SYSTEM

N→NTSC MODEL

P→PAL MODEL

SIGNAL SYSTEMSIGNAL SYSTEM

4_ safety information

safety information

CAUTION

RISK OF ELECTRIC SHOCK.

DO NOT OPEN

CAUTION:

TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE

COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates that dangerous voltage consisting a risk of electric

shock is present within this unit.

This exclamation point symbol is intended to alert the user to the presence

of important operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

WARNING

To prevent damage which may result in ﬁre or electric shock hazard, do not expose this

appliance to rain or moisture.

To prevent injury, this apparatus must be securely attached to the ﬂoor/wall in accordance

with the installation instructions.

WARNING

Be sure to use only the standard adapter that is speciﬁed in the speciﬁcation sheet.

Using any other adapter could cause ﬁre, electrical shock, or damage to the product.

Incorrectly connecting the power supply or replacing battery may cause explosion, ﬁre,

electric shock, or damage to the product.

Do not connect multiple cameras to a single adapter. Exceeding the capacity may cause

abnormal heat generation or ﬁre.

Securely plug the power cord into the power receptacle. insecure connection may cause

ﬁre.

When installing the camera, fasten it securely and ﬁrmly. The fall of camera may cause

personal injury.

•

English_5

●SAFETY INFORMATION

Do not place conductive objects (e.g. screwdrivers, coins, metal parts, etc.) or containers

ﬁlled with water on top of the camera. doing so may cause personal injury due to ﬁre,

electric shock, or falling objects.

If any unusual smells or smoke come from the unit, stop using the product. in such case,

immediately disconnect the power source and contact the service center. continued use in

such a condition may cause ﬁre or electric shock.

If this product fails to operate normally, contact the nearest service center. never

disassemble or modify this product in any way. (samsung is not liable for problems caused

by unauthorized modiﬁcations or attempted repair.)

When cleaning, do not spray water directly onto parts of the product. doing so may cause

ﬁre or electric shock.

CAUTION

Do not drop objects on the product or apply strong shock to it. Keep away from a location

subject to excessive vibrationor magnetic interference.

Do not install in a location subject to high temperature (over 50°C), low temperature (below

-10°C), or high humidity. Doing so may cause ﬁre or electric shock.

If you want to relocate the already installed product, be sure to turn off the power and then

move or reinstall it.

Remove the power plug from the outlet when then there is a lightning. Neglecting to do so

may cause ﬁre or damage to the product.

Keep out of direct sunlight and heat radiation sources. It may cause ﬁre.

Install it in a place with good ventilation.

Avoid aiming the camera directly towards extremely bright objects such as sun, as this

may damage the CCD image sensor.

Apparatus shall not be exposed to dripping or splashing and no objects ﬁlled with liquids,

such as vases, shall be placed on the apparatus.

The Mains plug is used as a disconnect device and shall stay readily operable at any time.

Do not expose the camera to radioactivity. Radioactivity exposure may damage the CCD.

10.

safety information

6_ safety information

FCC STATEMENT

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions :

This device may not cause harmful interference, and

This device must accept any interference received including interference that may cause

undesired operation.

CAUTION

This equipment has been tested and found to comply with the limits for a Class A digital

device, pursuant to part 15 of FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment.

This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this equipment in a residential area is

likely to cause harmful interference in which case the user will be required to correct the

interference at his own expense.

IC Compliance Notice

This Class A digital apparatus meets all requirements of the Canadian

Interference.-Causing Equipment Regulations of ICES-003.

Correct disposal of batteries in this product

(Applicable in the European Union and other European countries with separate battery return systems.)

This marking on the battery, manual or packaging indicates that the batteries in this product should not be

disposed of with other household waste at the end of their working life. Where marked, the chemical symbols

Hg, Cd or Pb indicate that the battery contains mercury, cadmium or lead above the reference levels in EC

Directive 2006/66. If batteries are not properly disposed of, these substances can cause harm to human health

or the environment.

To protect natural resources and to promote material reuse, please separate batteries from other types of waste

and recycle them through your local, free battery return system.

Correct Disposal of This Product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and other European countries with separate collection systems)

This marking on the product, accessories or literature indicates that the product and its electronic accessories

(e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their

working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal,

please separate these items from other types of waste and recycle them responsibly to promote the sustainable

reuse of material resources.

Household users should contact either the retailer where they purchased this product, or their local government

office, for details of where and how they can take these items for environmentally safe recycling.

Business users should contact their supplier and check the terms and conditions of the purchase contract.

This product and its electronic accessories should not be mixed with other commercial wastes for disposal.

English_7

●SAFETY INFORMATION

important safety instructions

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near water.

Clean only with dry cloth.

Do not block any ventilation openings. Install in accordance with the manufacturer’s

instructions.

Do not install near any heat sources such as radiators, heat registers, or other apparatus

(including ampliﬁers) that produce heat.

Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug

has two blades with one wider than the other. A grounding type plug has two blades and

a third grounding prong. The wide blade or the third prong is provided for your safety. If

the provided plug does not ﬁt into your outlet, consult an electrician for replacement of the

obsolete outlet.

Protect the power cord from being walked on or pinched particularly at plugs, convenience

receptacles, and the point where they exit from the apparatus.

Only use attachments/accessories speciﬁed by the manufacturer.

Use only with cart, stand, tripod, bracket, or table speciﬁed by the

manufacturer, or sold with the apparatus.

Unplug this apparatus when a card is used. Use caution when moving

the cart/ apparatus combination to avoid injury from tip-over.

Refer all servicing to qualiﬁed service personnel. Servicing is required when the apparatus

has been damaged in any way, such as powersupply cord or plug is damaged, liquid has

been spilled or objects have fallen into the apparatus, the apparatus has been exposed to

rain or moisture, does not operate normally, or has been dropped.

Apparatus shall not be exposed to dripping or splashing and no objects

ﬁlled with liquids, such as vases, shall be placed on the apparatus

10.

11.

12.

13.

14.

8_ contents

INTRODUCTION

9Features

10 What’s included

11 Component names and

Functions

INSTALLATION

12 Disassembling

12 Installing the camera on a ceiling

or wall

14 Adjust the panning and tilting

while watching the monitor

CONNECTION

15 Connecting to Monitor

15 Connecting to Power

16 Using Coaxial Communications

SETUP

17 Menu Conﬁgration

17 Menu Setup

contents

TROUBLESHOOTING

30 Troubleshooting

SPECIFICATIONS

31 Speciﬁcations

33 Dimension

English_9

●INTRODUCTION

FEATURES

IP66 Approved/Dust and Rain Resistant

With dust and rain resistant design, the camera can be installed outside under building

eaves or places that are exposed to the dust and rain.

Excellent Sensitivity

The built-in high sensitivity COLOR CCD produces a clear image.

- Color : 0.15Lux(50IRE, @F1.2), 0.0003LUX(SENS-UP, x512)

- B/W : 0.001Lux(50IRE, @F1.2), 0.000002LUX(SENS-UP, x512)

Ultra High Resolution

By adopting a diagonal 6mm(1/3") 410,000 (NTSC) pixels, 470,000(PAL) pixels SONY

CCD, the camera produces clear picture quality with a horizontal resolution of 600 TV

lines for color and 700 TV lines for BW.

SSNR3 (Samsung Super Noise Reduction) Function

The high-performance W-V DSP chip effectively removes low-light gain noise and

afterimage to provide clear images even in dark environments.

Day & Night

The camera identiﬁes whether it is day or night and automatically switches to the

appropriate mode, depending on its environment. By day, the camera switches to color

mode in order to maintain optimal color. At night, it switches to B/W mode so as to obtain

better picture deﬁnition.

DIS (Digital Image Stabilizer)

The DIS function compensates for any camera movement, to produce more stable

pictures.

SSDR(Samsung Super Dynamic Range)

For images with high contrast between bright and dark areas from difﬁcult lighting

conditions such as backlighting, this camera selectively illuminates darker areas while

retaining the same light level for brighter areas to even out the overall brightness.

OSD

The camera control is convenient by using 18 different foreign language O.S.D.

- NTSC : English, Japanese, Spanish, French, Portuguese, Korean, Taiwanese

- PAL : English, French, German, Spanish, Italian, Chinese, Russian, Polish, Czech,

Romanian, Serbian, Swedish, Danish, Turkish, Portuguese

Miscellaneous Functions

HLC(High Light Compensation), SENS-UP, FLIP (H/V-REV), D-ZOOM, SHARPNESS,

Motion Dection and PRIVACY functions are provided.

introduction

10_ introduction

introduction

WHAT’S INCLUDED

Check if the following items are included in the product package.

SCV-2081 User Manual Quick Set-up Guide

M4 Tapping Screw 3EA Video Output Cable

Template

Wrench

High Resolution Vandal-Resistant

Dome Camera

User Manual

SCV-2081

High Resolution Vandal-Resistant

Dome Camera

Quick Set-up Guide

SCV-2081

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Cámara IP de Samsung

Samsung

Samsung SMARTCAM SNH-1011N Manual de usuario

Samsung

Samsung SDC-9443BC Manual de usuario

Samsung

Samsung SCP-2370 Manual de usuario

Samsung

Samsung SIR-4150 Series Manual de usuario

Samsung

Samsung SCB-9060 Series Manual de usuario

Samsung

Samsung SCC-B9373 Manual de usuario

Samsung

Samsung SCO-3080R Series Manual de usuario

Samsung

Samsung GV-CLRIRH - GV-CLRIRH Day/Night Bullet IR... Instrucciones de instalación

Samsung

Samsung SCO-3080R Series Manual de usuario

Samsung

Samsung SNB-6010 Manual de usuario

Samsung

Samsung SCO-1020R Manual de usuario

Samsung

Samsung SCB-2005 Manual de usuario

Samsung

Samsung SCO-2081RN Manual de usuario

Samsung

Samsung SCO-6083R Guía de instalación

Samsung

Samsung SCC-B9373 Manual de usuario

Samsung

Samsung SmartDome SCC-C6403P Manual de usuario

Samsung

Samsung SCD-2021R Manual de usuario

Samsung

Samsung SDC-9441BC Manual de usuario

Samsung

Samsung SCZ-2373 Guía de instalación

Samsung

Samsung SCX-DO300 Manual de usuario

Samsung

Samsung SMARTCAM D1 Manual de usuario

Samsung

Samsung SNB-3002 Manual de usuario

Samsung

Samsung SDC-9443BC Manual de usuario

Samsung

Samsung SID-460 Manual de usuario

Manuales populares de Cámara IP de otras marcas

FLIR

FLIR Exx series Manual de usuario

Avigilon

Avigilon H4A-BO1-IR Manual de usuario

Digital Watchdog

Digital Watchdog DWCA-C128-64 Manual de usuario

ShareTech

ShareTech AV1 Manual de usuario

Ezviz

Ezviz C6C Manual de usuario

Melchioni

Melchioni UCAM 2015 Manual de usuario

Geutebruck

Geutebruck G-Cam/ESD-4630 Manual de usuario

Arecont Vision

Arecont Vision MegaBall AV3146DN-3310-D-LG Manual de usuario

Mitel

Mitel 6800i Series Manual de servicio

Vitek

Vitek VTC-IR403-212NP Manual de usuario

THOMSON

THOMSON DSC - 323W Manual de usuario

AVer

AVer FB2027 Manual de usuario

ENFORCER

ENFORCER EV-T5105-N2SQ Manual de usuario

Wansview

Wansview NC543 Manual de usuario

Eneo

Eneo MCB-64A0003M0A Manual de usuario

deView electronics

deView electronics CBDNI36F Manual de usuario

Swann

Swann SwannEye Manual de usuario

LevelOne

LevelOne IP CamSecure Manual de usuario
