Samsung TV
F/W Upgrade Guide
Samsung Electronics
PN50A530S2FXZA, PN50A530S2FXZCP530
PN50A510P3FXZA, PN50A510P3FXZAP510
Model CodeSeries (P5)
2
Notice: Please read completely prior to upgrade
¾There are two separate firmware packages required to
complete the upgrading process of the P510, P530 series:
Version 1004.2 or higher for the main processor
P510_P530 firmware 1004.2.exe
Version 1004.3 for the sub processor
P510_P530 firmware 1004.3.exe
¾First determine what the current firmware version is for the
main processor (see below). If the version is 1004.2 or higher
proceed to Step 2 and upgrade the sub processor with 1004.3.
¾How to check the firmware version
User Menu -> Setup -> SW Upgrade
When highlighted the “SW Upgrade”, press the “Info” button on Remote
TV F/W Version : XXXX
3
Step1. Upgrade the firmware version 1004.2
2. Connect the USB Memory Drive
to the USB port of your PC.
Copy the file into the USB Memory Drive.
3. Go to the USB Memory Drive and then double click the file
P510_P530 firmware 1004.2.exe.
1. Save the firmware file onto your computer.
File : P510_P530 firmware 1004.2.exe
4. Press “Unzip” button. 5. Unzipping is in progress.
6. After completing, press
“OK” and “Close” button.
7. The USB driver should contain one folder
named T-CNLAUSC
8. Safely disconnect the USB memory drive
by right clicking the green check mark
on the taskbar and then left click
“Safely Remove”.
4
9. Turn your TV on, and then insert
the USB Memory Drive containing
the firmware upgrade into the
WISELINK port.
NOTE: If you get the “WiseLink” on-
screen selection menu, select “NO”
※Important
If the firmware version you downloaded from the Samsung website
or received from Samsung is older than or has smaller version
number than the version on your TV, do not install it.
10. Press the Menu button on your
Remote Control.
11. Go to Setup.
On the Setup Menu,
select SW Upgrade, and then
press Enter or the arrow button
(▶) on your remote.
12. The TV will scan the USB Memory
Drive.
5
13. When the software upgrade is
complete; the TV will turn off and
then back on by itself.
Proceed with the ‘Plug & Play’
setup.
14. Once ‘Plug & Play’ is complete;
“Enjoy your watching.” is displayed.
Press the ‘Enter’ key and you are
done.
You can find more information in
User Manual.
※Do not pull the USB drive out and
unplug the power cable until
complete
※Important
If the firmware version you downloaded from the Samsung website
or received from Samsung is older than or has smaller version
number than the version on your TV, do not install it.
6
Step2. Upgrade the firmware version 1004.3
3. Connect the USB Memory Drive
to the USB port of your PC.
Copy the file into the USB Memory Drive.
4. Go to the USB Memory Drive and then double click the file
P510_P530 firmware 1004.3.exe.
2. Save the firmware file onto your computer.
File : P510_P530 firmware 1004.3.exe
5. Press “Unzip” button. 6. Unzipping is in progress.
7. After completing, press
“OK” and “Close” button.
8. The USB driver should contain one folder
named ‘T-CNLAUSC’
9. Safely disconnect the USB memory drive
by right clicking the green check mark
on the taskbar and then left click
“Safely Remove”.
1. If you completed Step 1 from above, remove the File and Folder (listed
below) on your USB drive.
File : P510_P530 firmware 1004.2.exe
Folder : T- CNLAUSC
7
10. Turn your TV on and insert
the USB Memory Drive containing
the firmware upgrade into the
WISELINK port.
NOTE: If you get the “WiseLink” on-
screen selection menu, select “NO”
※Important
If the firmware version you downloaded from the Samsung website
or received from Samsung is older than or has smaller version
number than the version on your TV, do not install it.
11. Press the Menu button on your
Remote Control.
12. Go to Setup.
On the Setup Menu,
select SW Upgrade, and then
press Enter or the arrow button
(▶) on your remote.
13. The TV will scan the USB Memory
Drive.
8
14. When the software upgrade is
complete the TV will turn off and
then back on by itself.
Proceed with the ‘Plug & Play’
setup
15. Once ‘Plug & Play’ is complete;
“Enjoy your watching.” is
displayed. Press the ‘Enter’ key
and you are done.
You can find more information in
User Manual.
※Do not pull the USB drive out and
unplug the power cable until
complete
※Important
If the firmware version you downloaded from the Samsung website
or received from Samsung is older than or has smaller version
number than the version on your TV, do not install it.
