Samsung SM-G920FD Manual de usuario

www.samsung.com

User Manual

English (EU). 01/2015. Rev.1.0

Draft Manual: The Manual is preliminary and some features discussed may not be applicable or complete and are

not final. (i.e. Model Names and Items such as battery, SIM Card, Softkey discussion .etc)

SM-G920F/

SM-G920FD

DRAFT, Not FINAL

Table of Contents

Basics

4 Read me first

5 Package contents

6 Device layout

8 SIM or USIM card

11 Battery

15 Turning the device on and off

16 Touchscreen

19 Home screen

25 Lock screen

27 Notification panel

30 Entering text

33 Screen capture

33 Opening apps

34 Multi window

38 Device and data management

44 Connecting to a TV

46 Emergency mode

Settings

47 Introduction

47 Wi-Fi

49 Bluetooth

51 Tethering and Mobile hotspot

52 Flight mode

52 Data usage

53 Mobile networks

53 More

58 Sound and notification

58 Display

59 Motions & gestures

59 Applications

60 Wallpaper

60 Themes

60 Lock screen & security

65 Privacy & safety

68 Easy mode

68 Accessibility

69 Accounts

70 Backup and reset

70 Language and input

71 Battery

71 Storage

72 Date and time

72 User manual

72 About device

Applications

73 Installing or uninstalling apps

74 Phone

77 Contacts

79 Messages

80 Internet

81 Email

DRAFT, Not FINAL

Table of Contents

82 Camera

98 Gallery

99 Smart Manager

100 S Planner

102 S Health

105 S Voice

106 Music

107 Video

107 Voice Recorder

110 My Files

110 Memo

111 Clock

112 Calculator

113 Google apps

115 Microsoft apps

Appendix

116 Accessibility

131 Troubleshooting

136 Removing the battery (non-removable

type)

DRAFT, Not FINAL

Basics

Read me first

Please read this manual before using the device to ensure safe and proper use.

•

Descriptions are based on the device’s default settings.

•

Some content may differ from your device depending on the region, service provider,

model specifications, or device’s software.

•

Content (high quality content) that requires high CPU and RAM usage will affect the

overall performance of the device. Apps related to the content may not work properly

depending on the device’s specifications and the environment that it is used in.

•

Samsung is not liable for performance issues caused by apps supplied by providers other

than Samsung.

•

Samsung is not liable for performance issues or incompatibilities caused by edited

registry settings or modified operating system software. Attempting to customise the

operating system may cause the device or apps to work improperly.

•

Software, sound sources, wallpapers, images, and other media provided with this device

are licensed for limited use. Extracting and using these materials for commercial or other

purposes is an infringement of copyright laws. Users are entirely responsible for illegal

use of media.

•

You may incur additional charges for data services, such as messaging, uploading and

downloading, auto-syncing, or using location services depending on your data plan. For

large data transfers, it is recommended to use the Wi-Fi feature.

•

Default apps that come with the device are subject to updates and may no longer be

supported without prior notice. If you have questions about an app provided with

the device, contact a Samsung Service Centre. For user-installed apps, contact service

providers.

•

Modifying the device’s operating system or installing softwares from unofficial sources

may result in device malfunctions and data corruption or loss. These actions are violations

of your Samsung licence agreement and will void your warranty.

DRAFT, Not FINAL

Basics

•

Depending on the region or model, some devices are required to receive approval from

the Federal Communications Commission (FCC). If your device is approved by the FCC,

you can view the FCC ID of the device. To view the FCC ID, tap

Apps

→

Settings

→

About device

Instructional icons

Warning: situations that could cause injury to yourself or others

Caution: situations that could cause damage to your device or other equipment

Notice: notes, usage tips, or additional information

Package contents

Check the product box for the following items:

•

Device

•

Quick start guide

•

The items supplied with the device and any available accessories may vary

depending on the region or service provider.

•

The supplied items are designed only for this device and may not be compatible

with other devices.

•

Appearances and specifications are subject to change without prior notice.

•

You can purchase additional accessories from your local Samsung retailer. Make

sure they are compatible with the device before purchase.

•

Use only Samsung-approved accessories. Using unapproved accessories may cause

the performance problems and malfunctions that are not covered by the warranty.

•

Availability of all accessories is subject to change depending entirely on

manufacturing companies. For more information about available accessories, refer

to the Samsung website.

DRAFT, Not FINAL

Basics

Device layout

Microphone

Microphone Loud speaker

Back key

Multipurpose jack

Front camera

Speaker

Power key

Touchscreen

Recents key

Headset jack

Home key (Fingerprint

recognition sensor)

LED indicator

Proximity/Light sensor

SIM card tray

Main antenna

Infrared port

Flash

Volume key

NFC antenna/Wireless

charging coil

Rear camera

Microphone

GPS antenna

DRAFT, Not FINAL

Basics

•

Do not cover the antenna area with your hands or other objects. This may cause

connectivity problems or drain the battery.

•

Using a Samsung-approved screen protector is recommended. Unapproved screen

protectors may cause the sensors to malfunction.

•

Do not allow water to contact the touchscreen. The touchscreen may malfunction

in humid conditions or when exposed to water.

Keys

Key Function

Power

•

Press and hold to turn the device on or off.

•

Press to turn on or lock the screen.

Recents

•

Tap to open the list of recent apps.

•

Tap and hold to launch the split screen view.

Home

•

Press to turn on the screen while the screen is locked.

•

Press to return to the Home screen.

•

Press and hold to launch

Google

Back

•

Tap to return to the previous screen.

Volume

•

Press to adjust the device volume.

DRAFT, Not FINAL

Basics

SIM or USIM card

Installing the SIM or USIM card

Insert the SIM or USIM card provided by the mobile telephone service provider.

•

Only nano-SIM cards work with the device.

•

Some LTE services may not be available depending on the service provider. For

more information about service availability, contact your service provider.

1 Insert the ejection pin into the hole on the SIM card tray to loosen the tray.

Ensure that the ejection pin is perpendicular to the hole. Otherwise, the device may

be damaged.

2 Pull out the SIM card tray gently from the SIM card tray slot.

DRAFT, Not FINAL

Basics

3 Place the SIM or USIM card on the SIM card tray with the gold-coloured contacts facing

downwards.

Use caution not to lose or let others use the SIM or USIM card. Samsung is not

responsible for any damages or inconveniences caused by lost or stolen cards.

4 Insert the SIM card tray back into the SIM card tray slot.

DRAFT, Not FINAL

Basics

Removing the SIM or USIM card

1 Insert the ejection pin into the hole on the SIM card tray to loosen the tray.

2 Pull out the SIM card tray gently from the SIM card tray slot.

3 Remove the SIM or USIM card.

4 Insert the SIM card tray back into the SIM card tray slot.

DRAFT, Not FINAL
