Samsung SGH-A800 Manual de usuario

ELECTRONICS

SERVICE

DUAL BAND Mobile

Cellular Phone

SGH-A800

Manual

DUAL BAND MOBILE CELLULAR PHONE CONTENTS

1. Exploded Views and Parts List

2. PCB Diagrams

3. Electrical Parts List

4. Block Diagrams

5. Flow Chart of Troubleshooting and

Circuit Diagram

Samsung Electronics Co.,Ltd.

Printed in Korea

11/2002 Rev 1.0

GH68-03108A

ELECTRONICS

Exploded Views and Parts List 1-1

1. Exploded Views and Parts List

1-1 Main

1-2 Main Parts List

1-3 Travel Adapter

1-4 Travel Adapter Parts List

1-5 Ciger Light Adapter

1-6 Ciger Light Adapter Parts List

1-7 Test Jig

1-8 Wearable EAR Microphone

1-9 Data Kit

1-10 Battery Charger

2. PCB Diagrams

2-1 Main Top

2-2 Main Bottom

3. Electrical Parts List

3-1 Main Parts List Top

3-2 Main Parts List Bottom

4. Block Diagrams

4-1 Main Base Band

4-2 Main RF

4-2-1 RF Transmit Part

4-2-2 RF Receive Part

5. Flow chart of Troubleshooting and Circuit Diagram

5-1 Power ON

5-2 Initial

5-3 Charging Part

5-4 Sim Part

5-5 Microphone Part

5-6 Speaker Part

5-7 Key Data Input

5-8 Receiver Part

5-9 Ring Indicator

5-10 Back Light (for Main & Sub LCD)

5-11 Back Light (for Key)

5-12 GSM Receiver

5-13 GSM Transmit

5-14 DCS Receiver

5-15 DCS Transmit

1-2 Exploded Views and Parts List

1. Exploded Views and Parts List

1-1 Main

21 23

20 24

Exploded Views and Parts List 1-3

1-2 Main Parts List

DUAL WINDOW LCD

FOLDER DUMMY

FOLDER UPPER

LCD

MOTOR

SPEAKER

FOLDER LOWER

WINDOW LCD

SCREW

SCREW SHEET

FRONT COVER

KEYPAD

VOLKEY F-PCB

MAIN PBA

DOME SHEET

MIC

CONNECTOR COVER

RF COVER

ANTENNA

REAR COVER

SCREW CAP

VOLUME KEY

SCREW

BATTERY

Description SEC CODE Remark

Location

No.

GH72-04824A

GH75-02119A

GH75-02117A

GH07-00181A

3101-001328

3001-001319

GH75-02118A

GH72-04823A

6001-001285

GH74-02895A

GH75-02116A

GH75-02136A

GH59-00474A

GH92-01334A

GH59-00475A

GH59-00476A

GH73-01282A

GH73-01281A

GH42-00201A

GH75-02121A

GH73-01283A

GH75-02120A

6001-000464

GH43-00667A

1-4 Exploded Views and Parts List

SGH-A800 COLOR & CODE

FOLDER UPPER

FOLDER LOWER

FRONT COVER

REAR COVER

FOLDER DUMMY

GH75-02117A

GH75-02118A

GH75-02116A

GH75-02121A

GH75-02119A

GH75-02117B

GH75-02118B

GH75-02116B

GH75-02121B

GH75-02119B

GH75-02117C

GH75-02118C

GH75-02116C

GH75-02121C

GH75-02119C

ITEM

COLOR SILVER Dark Silver Dark Blue

GH75-02117D

GH75-02118D

GH75-02116D

GH75-02121D

GH75-02119D

Royal Blue

FOLDER UPPER

FOLDER LOWER

FRONT COVER

REAR COVER

FOLDER DUMMY

GH72-04819A

GH72-04822A

GH72-04825A

GH72-04827A

GH72-04821A

GH72-04819B

GH72-04822B

GH72-04825B

GH72-04827B

GH72-04821B

GH72-04819C

GH72-04822C

GH72-04825C

GH72-04827C

GH72-04821C

ITEM

COLOR SILVER Dark Silver Dark Blue

GH72-04819D

GH72-04822D

GH72-04825D

GH72-04827D

GH72-04821D

Royal Blue

MAIN LOCKER

EARPHONE COVER

DAMPER(L)

MIC HOLDER

SCREW CAP SHEET

GH72-04828A

GH72-05132A

GH73-01276A

GH73-01277A

GH74-02895A

GH72-04828B

GH72-05132B

GH73-01276B

GH73-01277B

GH74-02895B

GH72-04828C

GH72-05132C

GH73-01276C

GH73-01277C

GH74-02895C

ITEM

COLOR SILVER Dark Silver Dark Blue

GH72-04828D

GH72-05132D

GH73-01276D

GH73-01277D

GH74-02895D

Royal Blue

SCREW CAP

MOBILE CAP

I/F CONN COVER

SHEET REAR

GH73-01283A

GH73-01281A

GH73-01282A

GH74-03415A

GH73-01283B

GH73-01281B

GH73-01282B

GH74-03415B

GH73-01283C

GH73-01281C

GH73-01282C

GH74-03415C

ITEM

COLOR SILVER Dark Silver Dark Blue

GH73-01283D

GH73-01281D

GH73-01282D

GH74-03415D

Royal Blue

Exploded Views and Parts List 1-5

1-4 Travel Adapter Parts List

TYPE SEC CODE REMARK

A GH44-00171A CHINA

B GH44-00184A EUROPE

C GH44-00171C UNITED KINGDOM

D Gh44-00171E TAIWAN

1-3 Travel Adapter

1-6 Exploded Views and Parts List

1-5 Ciger Light Adapter

1-6 Ciger Light Adapter Parts List

DESCRIPTION SEC CODE REMARK

Ciger Light Adapter Code GH44-00170A BLACK

Exploded Views and Parts List 1-7

1-7 Test Jig

TEST JIG GH80-10508A

TEST JIG CABLE GH39-00079A

RF JIG CABLE GH39-00174A

1-8 Exploded Views and Parts List

1-7 Test Jig

8922 or 8960

WIRELESS COMMUNICATIONS

TEST SET

TEST JIG

POWER

SUPPLY

RF JIG CABLE

TEST JIG CABLE

232 CABLE
