Samsung GT-S5260 Manual de usuario

GSM TELEPHONE

GT-S5260

1. Safety Precautions

2. Specification

3. Product Function

4. Exploded View and Parts list

5. MAIN Electrical Parts List

6. Level 1Repair

7. Level 2Repair

8. Level 3Repair

9. Reference data

Notice :

All functionality, features, specifications and other

product information provided in this document inclu

ding, but not limited to, the benefits, design, pricing,

components, performance, availability, and capabiliti

-es of the product are subject to change without

notice or obligation. Samsung reserves the right to

make changes to this document and the product

described herein, at anytime, without obligation on

Samsung to provide notification of such change.

GSM TELEPHONE CONTENTS

This Service Manual is aproperty of Samsung Electronics Co.,Ltd.

Any unauthorized use of Manual can be punished under applicable

International and/or domestic law.

Samsung Electronics Co.,Ltd.

2011. 01. Rev.1.0

ⓒ

SAMSUNG Proprietary-Contents may change without notice

2. Specification

This Document can not be used without Samsung's authorization

2-1

2-1. GSM General Specification

EGSM 900 DCS1800

Freq. Band[MHz]

Uplink/Downlink

880~915

925~960

1710~1785

1805~1880

ARFCN range 0~124 &

975~1023 512~885

Tx/Rx spacing 45MHz 95MHz

Mod. Bit rate/

Bit Period

270.833kbps

3.692us

270.833kbps

3.692us

Time Slot

Period/Frame

Period

576.9us

4.615ms

576.9us

4.615ms

Modulation 0.3GMSK 0.3GMSK

MS Power 33dBm~5dBm 30dBm~0dBm

Power Class 4

(max +33dBm)

(max +30dBm)

Sensitivity -102dBm -100dBm

TDMA Mux 8 8

Cell Radius 35Km 2Km

SAMSUNG Proprietary-Contents may change without notice

Specification

2-2

This Document can not be used without Samsung's authorization

2-2. GSM Tx Power Class

TX Power

control level GSM900

5 32.5±2 dBm

631±2

dBm

729±2

dBm

827±2

dBm

925±2

dBm

10 23±2 dBm

11 21±2 dBm

12 19±2 dBm

13 17±2 dBm

14 15±2 dBm

15 13±2 dBm

16 11±3 dBm

17 9±3 dBm

18 7±3 dBm

19 5±3 dBm

TX Power

control level DCS1800

0 29.5±3 dBm

128±3

dBm

226±3

dBm

324±3

dBm

422±3

dBm

520±3

dBm

618±3

dBm

716±3

dBm

814±3

dBm

912±4

dBm

10 10±4 dBm

11 8±4 dBm

12 6±4 dBm

13 4±4 dBm

14 2±5 dBm

15 0±5 dBm

SAMSUNG Proprietary-Contents may change without notice

3. Operation Instruction and Installation

3-1

This Document can not be used without Samsung's authorization

Main Function

•Android OS: Eclair

•HSDPA 7.2Mbps /HSUPA 5.76Mbps

•5

MP AF w/o LED Flash

•4.0"

WVGA Super AMOLED Full Touch (C-Type)

•A-GPS /BT v3.0 /USB v2.0 /WiFi (802.11 b/g/n)

•HD Recording (720p) /Full HD Playback (1080p), DLNA

•Sensors: Accelerometer, Compass, Proximity, Light

•TouchWiz 3.0 for Android, Multistage, Augmented Reality, Integrated phonebook with

SNS, IM, E-mail, Face Recognition, etc.

SAMSUNG Proprietary-Contents may change without notice

6. Level 1Repair

6-1

This Document can not be used without Samsung's authorization

6-1. S/W Download

6-1-1. Pre-requsite for S/W Downloading

•Downloader Program(MultiLoader_V5.65.exe)

•GT-S5260 Mobile Phone

•Data Cable

•JIG BOX (GH99-36900A)

•RF Test Cable (GH39-00985A)

•JIG Cable (GH39-01290A)

•Adapter (GH99-38251A)

•Binary files

（Settings

Connect to ANYWAY JIG BOX

&JIG CABLE (Phone to JIG)

SAMSUNG Proprietary-Contents may change without notice

Level 1Repair

6-2

This Document can not be used without Samsung's authorization

6-1-2. S/W Downloader Program

｝Load the binary download program by executing the

"MultiLoader_V5.65.exe "enter this file.

1.Check the "Full Download BOX" and open binary folder.

SAMSUNG Proprietary-Contents may change without notice

Level 1Repair

6-3

This Document can not be used without Samsung's authorization

2.Select the each items in the Downloader V5.65 and Choose the files.

Downloader V5.65 file name

Boot BOOTFILES (folder)

Apps apps_compressed.bin

Rsrc1 Rsrc_S5260_Open_Europe_Common.rc1

Rsrc2 Rsrc2_S5260(Low).rc2

Factory FS FactoryFs_S5260_Open_Europe_Common.ffs

CSC CSC_S5260_Open_Europe_Common_OXA.csc

SHP APP ShpApp.app

SAMSUNG Proprietary-Contents may change without notice

Level 1Repair

6-4

This Document can not be used without Samsung's authorization

3.Connect the handset, select Download.

(For enter "Download mode", press hold key+Vol. up key+send key.)

(downloading screen)

SAMSUNG Proprietary-Contents may change without notice

Level 1Repair

6-5

This Document can not be used without Samsung's authorization

4.When downloading is complete, confirm the this message.

"All files complete"

5.Confirm the downloaded version name and etc. :

*#1234#

Full Reset :

*2767*3855#
