Samsung SCX-4729FW Manual de usuario

BASIC

User’s Guide

SCX-472x Series

SCX-470x Series

BASIC

User’s Guide

This guide provides information concerning installation, basic operation and

troubleshooting on windows.

ADVANCED

This guide provides information about installation, advanced configuration, operation and

troubleshooting on various OS environments.

Some features may not be available depending on models or countries.

BASIC

1. Introduction

Key benefits 5

Features by models 7

Useful to know 13

About this user’s guide 14

Safety information 15

Machine overview 20

Control panel overview 24

Turning on the machine 27

Installing the driver locally 28

Reinstalling the driver 29

2. Menu overview and basic setup

Menu overview 31

Changing the display language 40

Media and tray 41

Basic printing 55

Basic copying 61

Basic scanning 65

Basic faxing 66

3. Maintenance

Ordering supplies and accessories 71

Available supplies 72

Available maintenance parts 73

Redistributing toner 74

Replacing the toner cartridge 75

Monitoring the supplies life 77

Setting the toner low alert 78

Cleaning the machine 79

4. Troubleshooting

Tips for avoiding paper jams 86

Clearing original document jams 87

Clearing paper jams 91

Understanding the status LED 96

Understanding display messages 98

5. Appendix

Specifications 103

BASIC

Regulatory information 113

1. Introduction

This chapter provides information you need to know before using the machine.

•Keybenefits 5

• Features by models 7

• Useful to know 13

• About this user’s guide 14

• Safety information 15

• Machine overview 20

• Control panel overview 24

• Turning on the machine 27

• Installing the driver locally 28

• Reinstalling the driver 29

Key benefits

Environmentally friendly

• To save toner and paper, this machine supports Eco feature.

• To save paper, you can print multiple pages on one single sheet of paper

(see "Using advanced print features" on page 216).

• To save paper, you can print on both sides of the paper (double-sided

printing) (see "Using advanced print features" on page 216).

• To save electricity, this machine automatically conserves electricity by

substantially reducing power consumption when not in use.

Fast high resolution printing

• You can print with a resolution of up to 1,200 x 1,200 dpi effective output.

• Fast, on-demand printing.

SCX-472x Series, SCX-470x Series:

- For single-side printing, 28 ppm (A4) or 29 ppm (Letter).

- For duplex printing, 14 ppm (A4) or 15 ppm (Letter).

Convenience

• Easy Capture Manager allows you to easily edit and print whatever you

captured using the Print Screen key on the keyboard (see "Easy Capture

Manager" on page 255).

• Printing Status (or Smart Panel) is a program that monitors and informs you

of the machine’s status and allows you to customize the machine’s settings

(see "Using advanced print features" on page 216).

• AnyWeb Print helps you screen-capture, preview, scrap, and print the

screen of Windows Internet Explorer more easily, than when you use the

ordinary program (see "Samsung AnyWeb Print" on page 256).

• Smart Update allows you to check for the latest software and install the

latest version during the printer driver installation process. This is available

only for Windows.

Key benefits

Wide range of functionality and application support

• Supports various paper sizes (see "Print media specifications" on page 105).

• Print watermark: You can customize your documents with words, such as

“Confidential” (see "Using advanced print features" on page 216).

• Print posters: The text and pictures of each page of your document are

magnified and printed across the multiple sheets of paper and can then be

taped together to form a poster (see "Using advanced print features" on

page 216).

• You can print in various operating systems (see "System requirements" on

page 108).

• Your machine is equipped with a USB interface and/or a network interface.

Features by models

Some features and optional goods may not be available depending on model or country.

Operating System

(●: Included, Blank: Not available)

Software

Operating System

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470x ND Series

Windows ● ● ●

Macintosh ● ● ●

Linux ● ● ●

Unix ● ● ●

Software

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470x ND Series

PCL / SPL printer drivera● ● ●

PS printer driver

XPS printer driver

Direct Printing Utility

Features by models

Samsung Easy

Printer Manager

Scan to PC settings ● ● ●

Fax to PC settings ● ●

Device settings ● ● ●

Samsung Printer Status ● ● ●

Smart Panel ● ● ●

AnyWeb Print ● ● ●

SyncThru™ Web Service ● ● ●

SyncThru Admin Web Service ● ● ●

Easy Eco Driver ● ● ●

Fax Samsung Network PC

Fax

● ●

Scan Twain scan driver ● ● ●

WIA scan driver ● ● ●

Samsung Scan Assistant ● ● ●

SmarThru 4

SmarThru Office ● ● ●

a. Depending on the operating system you use, the installed print driver may differ.

Software

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470x ND Series

Features by models

(●: Included, Blank: Not available)

Features by models

Variety feature

Features

SCX-472xFD Series

SCX-472xHD Series

SCX-472xHN Series

SCX-472xFW Series

SCX-472xHW Series SCX-470xND Series

Hi-Speed USB 2.0 ●●●

Network Interface Ethernet 10/100 Base TX

wired LAN

●●●

Network Interface 802.11b/g/n wireless LAN ●

Eco printing ●●●

Duplex (2-sided) printing ●●●

USB memory interface

Touch screen

Duplex Automatic Document Feeder (DADF)

Automatic Document Feeder (ADF) ●●●

Handset ●

(SCX-472xHD Series, SCX-472xHN

Series only)

●

(SCX-472xHW Series only)
