Safety 1st WILLOW Manual de usuario

20KG0m+

4 WHEEL STROLLER

WILLOW

Suitable for newborn to 20kg (approximately 5 years)

Illustration and designs may vary.

4017327 - Willow 4 Wheel Stroller - 11A/16

Components List

A. Folding Lock

B. Handle

C. Tether Strap

D. Storage Latch

E. Rear Brake

F. Rear Wheels (x2)

G. Shopping Basket

H. Canopy Window

I. Canopy

J. Seat Back

K. Harness Straps

L. Bumper Bar

M.Safety Buckle

N. Anti-Bacterial Seat Pad

(Double-Sided)

O. Adjustable Footrest

P. Front Swivel Locks (x2)

Q. Front Swivel Wheels (x2)

017327 - Willow 4 Wheel Stroller - 11A/16

Assembling Stroller

STEP 1: OPENING STROLLER

• If the stroller has a security tie, please

remove it.

• Release the storage latch (Figure 1a).

• Simultaneously lift handle while

pulling on the frame until the locking

mechanism engages (Figure 1b).

• Push down on the handle to check

that locks have fully engaged.

6017327 - Willow 4 Wheel Stroller - 11A/16

Assembling Stroller

STEP 2: REAR WHEEL ASSEMBLY

• Slide rear wheels onto the frame

of the stroller (Figure 2a).

• Push the wheels in until you hear

them lock into place.

• Listen for ‘click’.

• To remove the rear wheel assembly,

pull and hold the metal tab while

removing rear wheel from the axle

(Figure 2b). Repeat on the other side.

STEP 3: FRONT WHEEL ASSEMBLY

• Align the shaft on the wheel with

the hole in the front leg and push in

(Figure 3a). Listen for a ‘click’.

• Repeat on the other side.

• To remove the front wheel assembly,

press the metal tab inwards while

pulling the wheel off (Figure 3b).

017327 - Willow 4 Wheel Stroller - 11A/16

Assembling Stroller

STEP 6: ATTACHING CANOPY

• Align both canopy ends with the

plastic sliders on the frame then slide

the ends of the canopy down until

they are fully engaged (Figure 4a).

• Attach the velcro tabs to secure

canopy to stroller back (Figure 4b).

STEP 5: ATTACH BUMPER BAR

• Align bumper bar with the plastic

sliders on the frame then slide the

ends of the bumper bar down until

it is secure in place (Figure 5a).

• Listen for the ‘click’, then repeat

on the other side.

• To remove bumper bar, press

the grey buttons on each side

of the bumper bar (Figure 5b),

and remove.

8017327 - Willow 4 Wheel Stroller - 11A/16

Using Stroller

OPERATING FRONT SWIVEL

WHEELS

• Position the front wheel

as per Figure 6a.

• To lock, align the swivel lock

button with the frame and

push downwards (Figure 6b).

• To unlock, push the swivel

lock button upwards (Figure

6c).

LIFT TO

UNLOCK

PUSH TO

LOCK

OPERATING BRAKES

• To apply the brake, press down

firmly on the brake pedal using

the ball of your foot (Figure 7a).

• To release the brake, lift the brake

pedal until the brakes have fully

disengaged (Figure 7b).

Apply all brakes whenever

you park the stroller.

WARNING

017327 - Willow 4 Wheel Stroller - 11A/16

Using Stroller

USING CANOPY

• To use the canopy, pull the front edge

forward to open (Figure 9a, 9b).

• To extend canopy, flip the visor

outwards into position (Figure 9c).

• To further extend canopy, unzip and

pull the front edge forward to reveal

the breathable mesh extension

(Figure 9c).

• When not using, ensure the extension

is zipped, and then simply push the

canopy back until it is fully collapsed.

9a 9b 9c

ADJUSTING THE BACKREST

• To set backrest upright, pull both

straps outwards until tight (Figure 8a).

• To lower backrest, squeeze clip on

both sides to loosen straps (Figure 8b)

and pull seat downwards (Figure 8c).

PULL

STRAPS

10 017327 - Willow 4 Wheel Stroller - 11A/16

Using Stroller

TO FIT THE RAINCOVER

• Spread the raincover over the

stroller and pull over the seat

(Figure 11).

• Use elastic straps to secure to

stroller.

ADJUSTING FOOTREST

• Press both adjustment buttons

simultaneously and adjust to the

desired position (Figure 11). Listen

for ‘click’ to lock in place.
