Saey DUO Manual de usuario
Version 2017 Page 1
DUO
ENG –Installation and user’s guide
Art. number : 10.01.001.01.02
EN 13240
Version 2017 Page 2
Version 2017 Page 3
Index
1 Packaging and delivery content ........................................................................................................... 4
2 Technical information........................................................................................................................... 5
3 General information and security precautions .................................................................................... 6
3.1 Risks of fire .................................................................................................................................... 6
3.2 Risks by badly sealed door ............................................................................................................ 6
3.3 Risks of insufficient supply of air................................................................................................... 7
3.4 Risks of using inappropriate fuel................................................................................................... 7
3.5 Risks of shutting down the air supply............................................................................................ 7
3.6 Risks of bad chimney function....................................................................................................... 7
3.7 Things to do in case of chimney fire............................................................................................. 7
4 Installation guidelines........................................................................................................................... 8
5 User’s guide........................................................................................................................................ 12
5.1 Fuel .............................................................................................................................................. 12
5.2 First use ....................................................................................................................................... 13
5.3 General controls .......................................................................................................................... 14
5.4 Use of wood................................................................................................................................. 17
Making fire ........................................................................................................................................ 17
5.5 Use of Coal................................................................................................................................... 19
Making some fire............................................................................................................................... 19
6 Maintenance....................................................................................................................................... 22
7 Malfunctions: why they occur and how to solve them...................................................................... 25
8 Spare parts.......................................................................................................................................... 26
9 Warranty............................................................................................................................................. 27
10 Serial number ................................................................................................................................... 27
Version 2017 Page 4
Important user information
Congratulations! We sincerely thank you for choosing the Saey brand. With our Saey Duo
you have chosen for a technical extraordinary and also modern looking stove.
Apart from design, we greatly value an advanced burning technology and high quality. The
Saey Duo has been built with the most modern technology available and meets the
European DIN EN 13240.
On top of that Saey guarantees full service, even long after your purchase! An
undisputable efficiency and years of cosy heating times are the responsability of our
certified partners and Unifire.
By registering your stove, our customers can count on flawless after sales service and
warranty. On top of that we are able to inform you on extra news topics about your
device.
We’re convinced that many cosy days are ahead of you, and wish you the best of luck in
using your stove !
1 Packaging and delivery content
We have the utmost care of delivering your new stove in the best packaging possible, in
order to reduce any chance of damage. Thanks for checking your stove for damage and
complete content as soon you receive it. Please report any missing parts immediately to
your point of sale.
This delivery includes :
-Stove Saey Duo
-Ash carrier
-Coal tank
-Manual
-1 Control grip (1005-03932)
The packaging of your stove is harmless to the environment. The carton and wood will get
accepted at your local recycling park.
Version 2017 Page 5
2 Technical information
Stove Saey Duo
Carbon emission ( at 13% O2 )
%
Wood: ≤0.1
%
Coal: ≤0.8
Emission dust particles
Mg/m³n
Wood: ≤ 40
Mg/m³n
Coal: ≤150
Efficiency
%
Wood: ≥75
%
Coal: ≥65
Nominal thermal output
kW
7
Flue gas temperature
°C
Wood: 275
°C
Coal: 250
Draft at nominal consumption
g/s
Wood: 8.6
g/s
Coal: 9.4
Draft limits
Pa
Wood: 12 –20
Pa
Coal: 13 –21
Fresh air supply
m³/h
30
Fuel
Fuel
Wood, briquettes and coal
Max. capacity wood
Kg
2.3
Nominal consumption
Kg/h
2.5
Max. load wood briquettes
Kg
2.1
Nominal consumption
Kg/h
2.3
Max. capacity of coal
Kg
5 - 6
Nominal consumption
Kg/h
1.2
Dimensions
Max. length of logs
cm
40
Dimensions of coal
mm
20 –30
Weight of complete stove
Kg
160
Rear connection
Version 2017 Page 6
3 General information and security precautions
The following general safety prescriptions should be followed in any way possible :
-Please read the complete manual before first use
-By heating the stove certain parts, such as the doors, handles, window, exhaust
pipes,… can become very hot. Therefore it is prohibited to touch these parts without
proper protection ( heat-resistant gloves )
-Point out this danger to your children and make sure they keep a proper distance
when the stove is being used
-Objects that aren’t heat-resistant should be kept away from the stove
-Don’t put any kettles on top of your stove
-Clothing of any kind must be kept away on a safe distance
-While in use, keep all flammable or explosive materials out of range
-Only use the correct fuel for your stove. Not all material is suitable
-Any modification on the stove is prohibited
-Use original spare parts only coming from the manufacturing company
-This stove is not equipped to be connected with other ones on the same conduct
De Saey Duo was solely made to burn wood, briquettes and cool and only to work in a closed
environment.
3.1 Risks of fire
The main parts of the Saey Duo, especially the door, front, upperside and fume conducts can
become really hot. A heat-resistant glove should be used for controlling the stove. Pay
attention that all children keep a safe distance from the stove.
3.2 Risks by badly sealed door
Make sure to seal the door in a good way so no fumes or smoke can escape in the living
space.
Exhaust fumes and depression can form a reason so that smoke and other gas enters the
living room. Therefore pay attention never to open the front door before the wood has
burnt completely down.
Version 2017 Page 7
3.3 Risks of insufficient supply of air
Stoves need air to be able to burn, which they pull out of the living space. Therefore
sufficient fresh air should be supplied from outside. For the same reason, it is advised that
all ventilation systems work on minimum power, or even better, should be put off (
ventilation, kitchen hood… )
3.4 Risks of using inappropriate fuel
The Saey Duo was made solely to burn wood, briquettes or coal.
More information on using the right fuel can be find in chapter 5
3.5 Risks of shutting down the air supply
As long as the flames look yellow / orange the fresh air supply may never be disconnected.
3.6 Risks of bad chimney function
Good functioning of your stove requires an adequate air transit in your chimney. Especially
in spring and autumn or in case of bad weather conditions ( strong winds, storm, fog, …) this
may occur very frequently. Please keep this in mind as a very important topic.
In case of long inactivity of your stove, make sure to check chimney and other conducts for
clogging. Check this frequently
The law prescribes to clean the fume conducts on annual basis.
3.7 Things to do in case of chimney fire
We advise you to take the following steps in case of chimney fire:
-Seal off the air supply
-Call the fire brigade
-When cleaning entrances are foreseen, make sure they are well accessible ( e.g.
basement, attic, … )
-Remove all inflammable objects from the chimney
Version 2017 Page 8
-Before taking your stove in use again ask an expert to check your stove and chimney
first
-This expert must also examine the cause for the chimney fire and solve the problem
HINT! A stove makes that tar residues remain behind in your chimney after having burnt.
When you heat up your stove 10 minutes each day at maximal power, these residues will be
burnt, which will result in minimizing the risk for chimney fire. Also the window will be kept
cleaner for a much longer time.
4 Installation guidelines
All local directives, including the directives on national and european areas, must be taken
in to account when installing your stove.
Only a device, placed by an installer guarantees the correct follow-up of all directives
regarding architecture and fire prevention. This is an absolute must for a correct and safe
function of your stove.
The life expectancy of your stove depends on a correct installation, correct use and correct
maintenance.
Installation
The stove may only be installed on a floor capable of holding the correct weight. ( see
technical details ). If this is not the case, necessary measures must be taken in order to
increase the carrying capacity.
In order to level out the stove, it is equipped with adjustable legs ( adjusting screws ). Adjust
these if necessary so that the stove is levelled out as much as possible. Adjustments can be
made with a whrench.
The chimney
Before connecting the stove to a chimney, please check the dimensions and quality so that
they correspond to local directives. If necessary the dimensions must be calculated.
The stove can be connected on the chimney in a direct way. The diameter of the exhaust
pipe must correspond with the outlet of the stove.
A proper functioning of the stove can be guaranteed with a chimney draft between 12 and
20 Pa. When the chimney draft is too high, a draft valve must be built within.
Never reduce in diameter smaller than the diameter of the stove exit diameter.
Version 2017 Page 9
Consider the next steps in case of insufficient chimney draft :
-Make the chimney longer
-Improve the isolation of the chimney. ( avoids cooling of the fumes )
-Improve the supply of fresh air
-Improve the density of the chimney
Connecting the stove on the chimney
The Saey Duo has a rear connection and can be mounted immediately on the chimney. It is
important that all of these parts are sealed air tight.
The diameter of the exhaust pipes must correspond to the 150 mm exit diameter of the
stove. Regarding this diameter should also consider :
-That it may never diminish and that it fits the chimney in a perfect manner.
-When the chimney draft is too big, a draft valve must be installed.
-The exhaust pipe diameter may never be bigger than the one of the chimney,
otherwise the upwards pressure off the fumes will be hindered.
-Your chimney may not have the possibility to draw air from “false” openings. Make
sure to close all openings present… e.g. in the basement or the roof.
-Respect all safety distances around inflammable objects.
Combustion air supply
In order to have a perfect combustion, sufficient fresh air must be supplied. The required
oxygen arrives from the back and in best ways out of the premises.
HINT : Bear in mind that the presence of other stoves or venting installations in the same
room(s) will have disruptive effect on the functioning of your stove.
If there are still fumes coming back from the chimney due to bad weather conditions ( fog,
storm, … ) and within 15 minutes after detonating you should stop trying to light up the fire,
until better weather conditions have arrived.
ATTENTION ! In no way whatsoever, fresh air may never be supplied from rooms where
inflammable or volatile materials are present.
Classical system
Version 2017 Page 10
When the air supply comes from the same room as of the stove, make sure the room is
vented sufficiently. If not the case, it may result in incomplete combustion and exhaust
fumes combing back from the chimney. Extra air can always be supplied by installing next to
the stove an air vent going to the outside ( min. 100 cm² )
External air supply system
In some cases it is advised to introduce the air from the outside. In order to realise this a
conduct ( flexible or tubes ) with Ø 80 is connected directly on the backside of the stove.
This conduct should be protected from moisture by isolating it in these places where it is still
subject to hot air. The isolation used must of course be repulsive to fluids or at least a
protective screen must be present.
Otros manuales para DUO
1
Tabla de contenidos
Otros manuales de Cocina de Saey
Saey
Saey 94 MF Manual de usuario
Saey
Saey SORDO 80 Flatline Manual de usuario
Saey
Saey 94 Manual de usuario
Saey
Saey QURVE Manual de usuario
Saey
Saey PEAK GAS S.C. Manual de usuario
Saey
Saey KF 101-ARTE Manual de usuario
Saey
Saey DUO Manual de usuario
Saey
Saey CROSS Manual de usuario
Saey
Saey 92 TR Guía del usuario
Saey
Saey GUSTAV Manual de usuario
Manuales populares de Cocina de otras marcas
Vermont Castings
Vermont Castings Intrepid 2 Manual de usuario
Italiana Camini
Italiana Camini CLASSICA Guía de inicio rápido
Avalon
Avalon Vashon Avanti DVS FS Manual de usuario
Spartherm
Spartherm ambiente a1 Manual de usuario
Dimplex
Dimplex MCFSTV12AU Manual de usuario
Warmlite
Warmlite WL46040 Manual de usuario
