Russell Hobbs 20810 Manual de usuario

I www.russellhobbs.com

20810

Visit www.russellhobbs.co.uk/productregister/ You must register within 28 days of purchase

H B

Read the instructions, keep them safe, pass them on if you pass the appliance on. Remove all packaging

before use.

IMPORTANT SAFEGUARDS

Follow basic safety precautions, including:

This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been supervised/instructed and

understand the hazards involved. Children must not play with the

appliance. Cleaning and user maintenance must not be done by children

unless they are older than 8 and supervised. Keep the appliance and cable

out of reach of children under 8 years.

Don’t connect the appliance via a timer or remote control system.

Don’t use the appliance near or below combustible materials (e.g. curtains).

¬ The surfaces of the appliance will get hot.

If the cable is damaged, return the product, to avoid hazard.

b Do not use this appliance near bathtubs, showers, basins or other vessels containing water

• Don’t use accessories or attachments other than those we supply.

• Don’t use the appliance for any purpose other than those described in these instructions.

• Don’t operate the appliance if it’s damaged or malfunctions.

• Don’t use anything metal or sharp, you’ll damage the non-stick surfaces.

• Keep clear of the vent at the rear of the appliance – hot air will come from it.

HOUSEHOLD USE ONLY

PARTS

1. Timer

2. Power light

3. Thermostat light

4. Temperature control

5. Body

6. Basket holder

7. Handle

8. Cover

9. Lock

`Dishwasher safe

BEFORE USING FOR THE FIRST TIME

1. Handwash the removable parts, rinse, and dry.

2. The new element may smoke a bit till it has cured, but it’s nothing to worry about . The ﬁrst couple of

times you use it, ensure the room is well ventilated.

HOW IT WORKS

• A fan forces hot air round the basket, inside the basket holder, and, at the same time, the element

radiates heat, to brown the food.

• Oil is added to the food as a coating.

• By ﬁtting the partition to the slots inside the basket, you may cook diﬀerent foods together, e.g.

scampi and chips (both frozen) – cook the chips for 5 minutes, add the scampi, and cook for another

15 minutes.

HANDLE

The handle attaches to the basket holder and the basket.

To remove the basket holder from the body:

1. Steady the body with one hand

2. Grip the handle with the other hand and pull the basket holder out of the body

3. Rest the basket holder on an insulated mat.

To remove the basket from the basket holder:

1. Slide the cover away from the handle, to expose most of the lock

2. Press the lock down to unlock the handle from the basket holder

3. Lift the handle and basket up and out of the basket holder.

USING

• Sit the appliance on a heat-resistant surface.

• Put the plug into a power socket (switch the socket on, if it’s switchable).

1. Set the temperature control to the temperature you need.

2. Set the timer for 3-5 minutes, to preheat the appliance.

3. When you turn the timer from 0, the power light will come on. It’ll go out then the timer returns to 0.

4. The thermostat light will come on, then cycle on and oﬀ as the thermostat maintains the temperature.

5. When the power light goes out, remove the basket holder. Fit the partition, if required.

6. Put the food into the basket – don’t overﬁll.

7. Leave enough space between pieces of food to allow the hot air to circulate.

8. Slide the basket holder back into the body.

9. Set the timer to the time you need.

10. About half way through cooking, remove the basket holder, give it a shake, and/or turn the food over,

then replace the basket holder in the body.

11. The element will switch oﬀ when you remove the basket holder, then switch on again when you

replace it. The timer will continue to count down.

12. When the timer returns to 0, and the bell sounds, unplug the appliance.

13. To switch oﬀ manually, turn the timer to 0.

Once cooking is ﬁnished:

1. Remove the basket holder.

2. Check the food is cooked. If you’re in any doubt, cook it a bit more.

3. Set the basket holder on an insulated mat.

4. Press the lock down to unlock the handle from the basket holder

5. Lift the handle and basket up and out of the basket holder.

CARE AND MAINTENANCE

1. Unplug the appliance.

2. Leave everything to cool down.

3. Wipe the inner and outer surfaces of the appliance with a damp cloth.

4. Handwash the removable parts, rinse, and dry.

` You may wash these parts in a dishwasher.

If you use a dishwasher, the harsh environment inside the dishwasher will aﬀect the surface ﬁnishes. The

damage should be cosmetic only, and should not aﬀect the operation of the appliance.

COOKING TIMES AND FOOD SAFETY

• Use these times purely as a guide.

• Check food is cooked through before serving. If in doubt, cook it a bit more.

• Cook meat, poultry, and any derivatives (mince, burgers, etc.) till the juices run clear.

• Cook ﬁsh till the ﬂesh is opaque throughout.

• When cooking pre-packed foods, follow any guidelines on the package or label.

Food b°C Time

(min) Remarks

Frozen chips/potato

wedges 200 12-20

A single layer of chips – 12 minutes

Basket half full – 15 minutes

Basket full (loosely, not packed) – 20 minutes

Fresh chips 200 20 Rinse, towel dry, toss in salt, pepper, and 1 tsp oil

Fresh potato wedges 200 20 Rinse, towel dry, toss in salt, pepper, and 1 tsp oil

Jacket potatoes 180 30-40 For a crispy jacket, rub with oil

Roast potatoes 180 25-35 Rinse, towel dry, toss in salt, pepper, crushed rosemary

(optional) and 1 tsp oil

Frozen onion rings 180 15

Frozen ﬁshcakes large 180 20-25

Frozen ﬁshcakes small 180 15-20

Fresh ﬁshcakes large 180 15-20

Fresh ﬁshcakes small 180 10

Frozen scampi (in crumbs) 180 10-15

Fish goujons 180 10 Cut ﬁsh in strips, roll in egg, then in seasoned crumb

Frozen samosas 180 20

Fresh samosas 180 10-15

Frozen duck rolls 180 20

Fresh duck rolls 180 10-15

Boneless preformed

chicken products (frozen) 180 15

Fresh chicken goujons 180 10-15 Cut meat in strips, roll in egg, then in seasoned crumb

Schnitzel (chicken/veal/

pork) 180 15 Hammer meat ﬂat, coat in egg, then in seasoned crumb

Chicken thighs 180 25-30 Cooking time depends on size

Tortillas 200 5-10 For a crispy ﬁnish, rub with oil

Scotch eggs 170 15-20 Cooking time depends on size

Stir fry 180 25-30 Toss in salt, pepper, and 1 tsp oil, add a little sauce 5

minutes before the end (chilli, sweet chilli, garlic, etc)

Sausages 180 10 The fat drips into the bowl, away from the sausages

ONION RINGS

• white onion(s)

• milk

• seasoned ﬂour

• oil

Slice the onion(s), dip in milk, then seasoned ﬂour, drizzle with oil and cook at 180ºC for 12-15 minutes.

MINI SALMON FISHCAKES

• ½ onion

• 2 sprigs fresh parsley

• pinch of chilli

• 1 good sized salmon ﬁllet

• 5-6 tbsp breadcrumbs

• 1 egg, lightly beaten

• seasoned ﬂour

• salt and pepper

Preheat to 180ºC. Blend the onion and parsley for a few seconds, add the salmon, chilli, a generous pinch of

both salt and pepper, and blend for 5-10 seconds. Transfer to a bowl, and fold in 2 tbsp breadcrumbs.

Divide the mix into 10 portions (or 4 portions, if you want large ﬁshcakes).

Roll each portion into a ball, coat in seasoned ﬂour, then egg, then breadcrumbs, ﬂatten the balls and cook

for 10-15 minutes for small ﬁshcakes, or 15-20 minutes for large ﬁshcakes, turning them about half way

through cooking.

CHICKEN KIEV

• 2 skinned chicken breasts

• 2 cloves fresh garlic

• 50g salted butter

• 2 sprigs fresh parsley

• 1 egg, lightly beaten

• breadcrumbs (either packet or home-made)

• pepper to taste

Preheat to 180ºC. Blend the garlic, parsley and a generous pinch of pepper for 10-20 seconds, add the

butter and blend for 15 seconds.

Slice each chicken breast along the long edge (don’t cut completely in half) and open into a butterﬂy

shape. Cover with cling ﬁlm and hit with a rolling pin to ﬂatten slightly.

Put a good spoonful of the mixture in the middle of each breast, then roll the chicken over the mix so it

overlaps and leaves no exit for the mix to escape. You will now have a tight roll in the shape of a chicken

breast (a fat version of its original shape). Dip the chicken into the seasoned ﬂour, then into the egg and

ﬁnally roll in the breadcrumbs, coating the chicken completely. Repeat this for the second breast.

If you have time, leave the chicken on greaseproof paper in the fridge for an hour to rest.

Cook for 30-35 minutes. Turn after 15-20 minutes, to ensure a lovely golden colour all over.

VICTORIA SPONGE

• 100g self raising ﬂour

• 100g soft butter

• 100g caster sugar

• 2 eggs

Preheat to 170ºC. Combine everything with a mixer for 2 minutes. Put a large paper case in the basket.

Spoon the mixture into the paper case. Smooth with a spoon or spatula, leaving a small dent in the centre,

to stop the cake from rising too much in the middle. Cook for 15-20 minutes. Don’t check till at least 10

minutes baking time has passed, or you’ll collapse the sponge.

SCOTCH EGGS

• 500g beef (for mincing), or 500g minced beef

• 1 onion

• 2 sprigs thyme

• 2 sprigs parsley

• pinch cayenne pepper

• salt and pepper

• 5 eggs (one for egg wash)

• breadcrumbs

• ﬂour for coating

• oil for cooking

If you’re using a mincer, mince the beef and onion together. If you’ve bought mince, chop or blend the

onion ﬁnely, and mix into the mince with the salt, pepper, cayenne pepper and chopped herbs.

Boil 4 eggs till soft boiled with slightly runny yolks. Carefully peel the shells from the eggs.

Coat the eggs in ﬂour then cover completely in the minced meat. Roll the ball in the egg, then the

breadcrumbs. Drizzle with oil. Cook at 170 for about 15 minutes, turning occasionally.

MUSTARD AND HONEY PORK LOIN WITH ROASTED VEGETABLES

• 1 piece pork loin, about the thickness of 4

chops

• 2 carrots, peeled and cut into chunks

• 2 parsnips, peeled and cut into chunks

• 2 red onions, quartered

• 6 large cherry tomatoes

• 2 courgettes, cut into chunks

• 2 tbsp grainy mustard

• 1 tbsp runny honey

• 1 tbsp oil

• salt and pepper

Preheat to 170ºC.

Stir the vegetables in a bowl with the oil, salt and pepper, ensuring all are well coated.

Mix the mustard and honey in a dish, then smear all over the loin.

Put the loin in the centre of the basket, and spoon the vegetables round it. Cook at 170 for 40 minutes to 1

hour, depending upon the size of the loin. Turn the loin after 15 minutes and stir the vegetables. Check

again at 30 minutes.

CHICKEN SCHNITZEL

• 2 large chicken breasts

• 1 large egg

• 2 tbsp seasoned ﬂour

• 75g breadcrumbs

• dried zest of ½ a lemon

• 15g parmesan, grated

• 1 heaped tbsp parsley, ﬁnely chopped

• 1 tbsp oil

• salt and freshly ground black pepper

Preheat to 180ºC.

Slice each chicken breast along the long edge (don’t cut completely in half) and open into a butterﬂy

shape. Cover with cling ﬁlm and hit with a rolling pin to ﬂatten slightly.

Beat the egg in a bowl. Sprinkle the seasoned ﬂour on a plate. Mix the breadcrumbs with the lemon zest,

parmesan and parsley. Coat each piece of chicken in ﬂour, then beaten egg, then the breadcrumb mixture.

Drizzle a little oil over the schnitzels and cook at 180 for 15-20 minutes.

VEAL/PORK SCHNITZEL

Follow the recipe for chicken schnitzel, but substitute 2 pieces of breast of veal or two pieces of pork,

bones and fat removed.

YORKSHIRE PUDDING BATTER

• 1 egg

• 85g plain ﬂour

• 25ml milk

• 1 tsp oil

• 1 tsp butter

• salt and pepper

Whisk the egg, then whisk in the ﬂour, oil, butter, salt and pepper to create a thick paste. Whisk in the milk

till it becomes a thin batter. Rest in the fridge for a couple of hours, or overnight if possible. This allows the

batter to thicken, however if it is too thick when it comes out of the fridge, you can add a drop of milk.

Preheat to 200ºC.

Pour a little oil into small metal cake containers or foil pastry cases and heat in the basket for 2 minutes.

Carefully pour the batter into the containers, till they are about a third full. Cook for 10-15 minutes,

depending upon the size and number in the fryer. Turn to 165 after 5 minutes. They should be golden

brown and double in size.

Top tip: Freeze the Yorkshire puddings and bring out when required. Just pop them in the fryer for a

couple of minutes to heat through.

T22-9001059

RECYCLING

To avoid environmental and health problems due to hazardous substances,

appliances and rechargeable and non-rechargeable batteries marked with

one of these symbols must not be disposed of with unsorted municipal

waste. Always dispose of electrical and electronic products and, where

applicable, rechargeable and non-rechargeable batteries, at an appropriate

official recycling/collection point.

SERVICE

If you ring Customer Service, please have the Model Number to hand, as we won’t be able to

help you without it. It’s on the rating plate (usually underneath the product).

The product isn’t user-serviceable. If it’s not working, read the instructions, check the plug fuse

and main fuse/circuit breaker. If it’s still not working, consult your retailer.

If that doesn’t solve the problem – ring Customer Service – they may be able to oﬀer technical

advice.

If they advise you to return the product to us, pack it carefully, include a note with your name,

address, day phone number, and what’s wrong. If under guarantee, say where and when

purchased, and include proof of purchase (till receipt). Send it to:

Customer Service

Spectrum Brands (UK) Ltd

Fir Street, Failsworth, Manchester M35 0HS

email: support@russellhobbs.com

telephone: 0345 658 9700 (local rate number)

Please note: If you have purchased the product within the last 6 months, please contact the

retailer in the ﬁrst instance to deal with any matters relating to warranty.

GUARANTEE

Defects aﬀecting product functionality appearing within the guarantee period will be corrected

by replacement or repair at our option provided the product is used and maintained in

accordance with the instructions. Your statutory rights are not aﬀected.

Guarantee period = 2 years from ﬁrst retail purchase.

To claim an extra 1 year guarantee, register your product online within 28 days of purchase.

Consumables are guaranteed only for their recommended lifecycle. Replacement/Spare parts*

are excluded and are only covered by a 1 year warranty.

* Examples include ﬁlters, removable grill plates, drip trays/crumb trays etc.

JONLINE

www.russellhobbs.com for more products

IREGISTER ONLINE

Visit www.russellhobbs.co.uk/productregister/

*You must register within 28 days of purchase.

Otros manuales para 20810

Tabla de contenidos

Otros manuales de Freidora de Russell Hobbs

Russell Hobbs

Russell Hobbs RHDAF11 Especificaciones técnicas

Russell Hobbs

Russell Hobbs 22100-56 Manual de usuario

Russell Hobbs

Russell Hobbs 18238 Manual de usuario

Russell Hobbs

Russell Hobbs Brooklyn 5L Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs 27170AU Manual de usuario

Russell Hobbs

Russell Hobbs 21840-56 Manual de usuario

Russell Hobbs

Russell Hobbs RHGDF14 Classic Satin Manual de usuario

Russell Hobbs

Russell Hobbs 14559 Manual de usuario

Russell Hobbs

Russell Hobbs 17892 Manual de usuario

Russell Hobbs

Russell Hobbs 24580 Manual de usuario

Russell Hobbs

Russell Hobbs RHDF35D Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs 20810 Guía de instalación

Russell Hobbs

Russell Hobbs SATISFRY BROOKLYN Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs 20810-56 Manual de usuario

Russell Hobbs

Russell Hobbs 26500 Manual de usuario

Russell Hobbs

Russell Hobbs 19771 Manual de usuario

Russell Hobbs

Russell Hobbs 26500-56 Manual de usuario

Russell Hobbs

Russell Hobbs RHDF3000 Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs RDF300 Guía de instalación

Russell Hobbs

Russell Hobbs Cook@Home RHDF320 Manual de usuario

Russell Hobbs

Russell Hobbs PURIFRY RHAF3000 Manual de instrucciones de instalación

Russell Hobbs

Russell Hobbs 19773-56 Manual de usuario

Russell Hobbs

Russell Hobbs 27160AU Manual de usuario

Russell Hobbs

Russell Hobbs 27170-56 Manual de usuario

Manuales populares de Freidora de otras marcas

Innsky

Innsky 55SA1US Manual de usuario

Falcon

Falcon G350/11 Guía del usuario

GoWISE USA

GoWISE USA GW22612 Manual de usuario

Wolf

Wolf IF15/S Manual de usuario

Electrolux

Electrolux Thermetic 9CHG583284 Guía rápida

Gourmia

Gourmia GAF799 Manual de usuario

DeLonghi

DeLonghi D677UX Manual de usuario

SEVERIN

SEVERIN DEEP FRYER - Guía del usuario

Toastmaster

Toastmaster TMFG18-NAT Manual de usuario

Domo

Domo DO465FR Manual de usuario

Henny Penny

Henny Penny PFG-691 Manual de usuario

Farberware

Farberware FBW FT 43721 B Manual de usuario

GERMANICA

GERMANICA GEAF5L3LD Manual de usuario

Roller Grill

Roller Grill MF 120 R Manual de operación

Philips

Philips HD9211 Manual de usuario

Linea 2000

Linea 2000 Domo DO536FR Manual de usuario

Lakeland

Lakeland 31796 Manual de usuario

Dash

Dash Tasti-Crisp DFAF755 Manual de usuario
