Rosewill RSV-R26 Manual de usuario

Server RSV-R26

User Manual

Server RSV-R26 User Manual

A list of mounting parts

Slide rails x 2

Latches x 4

M5 x 8L

Screws x 18

M4 x 6L

Screws x 18

“L” Brackets x 4

Installation manual

Washers x 10

Round-capped

Phillips Screws x 10

M4 Screw

cap x 10

Step 1

Take the sliding rail apart by sliding out the center slide.

Outer slide rail

Center slide rail

Loc

ing clip

Attention:

You will see a locking clip at the middle point of the center slide. By pushing down the

locking clip, you will be able to remove the center slide out the sliding rail.

Server RSV-R26 User Manual

Step 2

Install the center slide to both sides of the chassis, then secure the center slides

with M4*6L screws.

The rackmount chassis

To pull it out of the cabinet

Bac

-end

Front-end

Center slide rail x 2

6L Screws

Attention:

1. Put the center slide right next to the chassis. Align the center slide holes to the

chassis＇mounting holes and install all 3 screws for each slide.

2. From all the way out of the cabinet, the rail has front and back sections. Please do

not mix that.

3. Please leave a 10-20mm space gap between the front point of the slide and the

handle of the chassis.

Step 3

Attach the 4 “L＂brackets on to the 2 outer slide rails. Please do not make it tight so

that it will be adjustable according to the size of the cabinet.

Back-end Front-end

To pull it out of the cabinet

M4 x 6 Screws and washers

Attention:

1. Please do not tighten it so that the brackets can slide and adjust to the width of the

cabinet.

2. While adjusting, please align the positions of “L＂brackets on both 2 slide rails.

Server RSV-R26 User Manual

Step 4 (type1)

Install the latches onto the front-side of the pillar of a rackmount cabinet.

Use M5 x 8L screws to

secure the L brackets onto

the latches (4 places).

Please align the screw

holes on the pillar with the

screw holes on the

brackets.

Attention:

1. Adjust the brackets according to the width of the cabinet.

2. Make sure to align the 2 slide rails on the rackmount and secure the brackets on to the

outer slide rails via screws.

3. Make sure that the 2 sliding rails are at the same height. ( The positions of the screw

holes must be identical as well.)

Step 4 (type2)

Install the latches onto the profile of the pillar of a rackmount cabinet.

Use M5

8L screws to secure the brackets

together with the latches to the cabinet

rackmount. The setup is similar to type 1

Server RSV-R26 User Manual

Step 5

Install the chassis with center slides to the cabinet by sliding into the outer slides.

1. Pull the outer slide all the way until it

reaches the limit.

2. Install the chassis with center slides to

the cabinet by sliding into the outer slides.

In order to successfully push in, please pull

up the locking clips.

Server RSV-R26 User Manual

3. Use M5 square locking nuts

that come with the cabinet and

M5 Round-capped Phillips

screws to secure the chassis to

the rackmount cabinet.(4 places)

Thank you for purchasing a quality Rosewill Product.

Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
