Rosen DS-TY10B0 Manual de usuario

Multi-Media Navigation System Installation Guide

Installation Guide

* JBL Audio equipped vehicles will require additional part # DP-TYJBL1 audio interface

NOTICE OF INTENDED INSTALLATION AND USE

THE ROSEN MULTI-MEDIA NAVIGATION SYSTEMS CONTAIN AN INTERNAL VIDEO PLAYER, WHICH IS

NOT INTENDED FOR VIEWING BY THE DRIVER. THE VIDEO PLAYER IS DISABLED WHEN THE

VEHICLE IS IN MOTION THROUGH A CONNECTION TO THE PARKING BRAKE.

THE INSTALLER OF THIS PRODUCT MUST INSURE THE VIDEO DISABLE CONNECTION IS

WORKING PROPERLY PRIOR TO DELIVERY OF THE VEHICLE.

IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR INTERFERE WITH SAFE OPERATION

OF THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND COULD ALSO

VIOLATE STATE AND/OR FEDERAL LAW.

ROSEN ENTERTAINMENT SYSTEMS DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR

PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED INSTALLATION

AND/OR USE.

STOP

Damage to the vehicle may occur

Do not proceed until process has been completed

CAUTION

Process must be carefully observed in order to reduce

the risk of damage to the accessory or vehicle

CRITICAL

Process must be carefully observed in order to ensure a

quality installation

TOOLS and EQUIPMENT

Specific tools and equipment recommended for this

process

SAFETY RISK

Observe safe practices, this process can be dangerous

and there is a risk of personal injury

TESTING and TROUBLESHOOTING

Content specific testing and troubleshooting points

DS-TY10B0 Toyota Sienna

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 2

PREPARING FOR THE INSTALLATION

Before you start, please read these critical steps below STEP

BEFORE YOU START THE

INSTALLATION,

READ THIS GUIDE!

VISIT

Rosen Dealer Central

For the latest Updates, Corrections and Technical Tips

about this product and installation

www.RosenDealerCentral.com

CHECK THE BATTERY

Test the battery voltage to make sure it’s fully charged to

a minimum of 12.8 VDC

This only takes seconds and can save hours of

troubleshooting later.

TURN THE VEHICLE

OFF

Keep the Vehicle Off during the installation to avoid

setting various Vehicle Fault sensors

Keep the Vehicle OFF during the

installation

Failure to follow this may cause the AIRBAG FAULT

SENSOR to become enabled. Dealer Service

Departments charge a significant fee to reset the Fault

Sensor.

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 3

REMOVE THE FACTORY RADIO

You will need to remove multiple interior trim components prior to removing the factory radio.

The following steps will help guide you through this process.

STEP

Remove Shift Knob

Carefully remove shift knob

Remove Lower Dash Trim

Carefully remove lower dash trim beneath climate

controls

Remove Shift Knob Bezel

Carefully remove shift knob bezel

Remove Climate Controls

Carefully remove climate controls

CAUTION

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 4

Remove OEM Radio Mounting Bolts

Carefully remove radio mounting bolts.

4 x 10mm bolts.

Radio and dash/vent trim will come out as a single piece.

Remove Dash/Vent Trim from OEM Radio

Carefully remove 4 x Phillips screws to release

dash/vent trim from OEM radio.

Remove Mounting Brackets

Carefully remove mounting brackets from OEM radio

and relocate onto Rosen unit.

Be sure to use ROSEN SUPPLIED screws.

Be sure to re-install dash/vent trim onto Rosen unit.

LOCATING REMOTE COMPONENTS

You will need to mount the GPS and Optional Satellite Radio Antennas on the exterior of the vehicle.

And mount the iPod Interface Connector in the vehicle. The following steps will help guide you

through this process.

STEP

Use Caution around SRS Components

It is the installer’s responsibility to ensure that the safety

equipment in the vehicle is NOT adversely affected by

installation of this system. Ensure that the routing of the

harnesses do NOT obstruct airbags, SRS or other safety

devices.

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 5

Mount the GPS and Sat Radio antenna in

a location on the exterior of the Vehicle

Route the GPS harness away from other power harnesses in

the vehicle.

This will help to ensure optimum performance of the GPS

system.

“OPTIONAL”

Install the iPod interface connector in a

location accessible to the end-user

Locate the iPod interface module in an area which can be

serviced in the future.

The iPod cable is intended to be a serviceable item, which

plugs into the iPod/Sat radio Interface Module.

INSTALL THE ROSEN NAVIGATION SYSTEM

You will need to prepare the Rosen Navigation System for installation in the vehicle. STEP

Remove the DVD Transport Screws

There are 2 x Phillips Transport Screws which protect the

DVD Mechanism during transportation.

Transport Screws must be removed prior to installation.

Connect the Power and GPS Harnesses

The GPS Harness must be tightened with a WRENCH to

ensure it is properly seated.

Be sure to use white cable clamp to secure GPS antenna

cable

Failure to follow this step may result in poor GPS signal

Connect Optional Harnesses such as

iPod, Satellite Radio, Camera, Reverse

Sensors

These harnesses must be fully engaged prior to the system

installation.

See the Harness Diagrams for more information

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 6

Prepare the Vehicle side harnesses for

connection to the Rosen Harness

Use care not to pinch or damage cables as this will

cause performance issues/failures

CAUTION

Mount Rosen Navigation into Dash

Insert Rosen Navigation System Into Dash and re-install

radio mounting screws that were removed

Turn the vehicle ON and confirm the unit

is fully operational

With the connectors Fully Engaged, turn the vehicle on

and press the RESET for 5 seconds on the unit.

Insert a DVD to confirm the Video Disable

Circuit is properly Operating.

The Brake Wire must be connected to the Park Brake

Indicator Wire to complete a ground when the brake is

engaged.

RE-INSTALL THE TRIM COMPONENTS

You will need to reinstall all trim components

STEP

Re-Install Climate Controls

Re-install Climate Controls as well as lower climate

control trim piece that were removed in Step 2.

CAUTION

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 7

Re-Install Shift Knob

Re-install shift knob and shift knob bezel that were

removed in Step 2.

ENABLE INSTALLER SETTINGS

You will need to select certain Installer Setting based on any Optional Equipment that you may have

installed

STEP

Launch the Installer Setting Screen

From any screen with the Menu Button, follow these

steps to display the Installer Setting Screen, select:

1) From any Screen, select “Menu”

2) From the Menu Screen, select “Settings”

3) Press “Keypad,” Press “7253” and “Enter”

Select the individual Settings as needed

for the installed components

Selectable options vary by product and installation.

Select the options as applicable for the installed optional

components.

Perform Pre-Delivery Tests

You will need to perform several Pre-Delivery Tests to ensure customer satisfaction

Some optional equipment may not be applicable

STEP

Turn the vehicle ON and System ON

Confirm the unit starts up properly

Troubleshooting

1) Reset the System while the Vehicle is ON

2) Confirm all connectors are properly installed

3) Check the Vehicle and System Fuses

CAUTION

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 8

Select RADIO as the Source

Confirm that the AM and FM reception are as expected

Troubleshooting

1) Confirm Antenna is properly connected.

2) Reset the System

Select SATELLITE RADIO as the Source

Confirm Channel 001 is present after ~5 minutes

Troubleshooting

1) Confirm the SAT Radio is Turned ON in the Installer

Settings

2) Confirm the antenna has unobstructed view of the Sky

3) Confirm the antenna is located on the outside of the

vehicle

Select iPOD as the Source

Confirm iPod is communicating and playback is OK

Troubleshooting

1) Confirm iPod Version Compatibility – not all are

compatible

2) Confirm the harnesses are properly engaged

3) Reset the System

Select CD as the Source

Confirm CD audio playback is OK

Troubleshooting

1) Confirm the Disc is Store Bought and in good condition

2) Reset the system

Select DVD as the Source

Confirm DVD video playback is OK

Troubleshooting

1) Ensure the Park Brake is set to view video

2) Confirm the Disc is Store Bought and in good condition

3) Reset the system

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 9

Select MP3 as the Source

Confirm MP3 playback is OK – Select Favorites

Troubleshooting

1) Confirm that a Test Track exists in the Favorites Folder

2) Reset the system

Select Phone as the Source

Confirm Phone Pairing is successful

Troubleshooting

1) Confirm the Phone has BT and is in discoverable mode

2) Confirm the Phone is compatible with the system

3) Reset the system

Select NAV as the Source

Confirm the Navigation loads and signal strength is OK

Troubleshooting

1) Confirm the antenna has an unobstructed view of the sky

2) Confirm the antenna is located on the outside of the

vehicle

3) Confirm the antenna connection is properly tightened

Select Reverse Camera

Confirm the backup camera screen shows in reverse

Troubleshooting

1) Confirm the Camera is set to ON in the Installer Settings

2) Confirm the Reverse Trigger wire is attached properly

3) Confirm the Camera is receiving 12VDC as required

Installation Guide Toyota Sienna

Installation Guide DP-TY10B4 Rev A

Page 10

Service and Optional Parts List

Part Number Description Part Number Description

DP-TY10B1 Quick Reference Guide DP-TY10B2 Harness, Main Interconnect

DP-TY10B4 Installation Guide DP-TY10B3 Harness, Steering Wheel Cntls

DP-1047 GPS Antenna Windshield Mount DP-1001 Manual, Owner’s

DP-1008 Harness, AUX Out DP-1002 Manual, Primo Navigation

DP-1009*** Harness, AUX IN DP-1010* Harness, Sensors/Camera

DP-1023 Pin, Stylus DP-1011 Harness, Dolby 5.1/Amp

DP-1083-P11 Card, MicroSD w/ maps DP-1022 Antenna, GPS

DP-1013-1 Harness, iPod DP-1066** Camera, License Plate Black

DP-1007 Harness, USB Adaptor DP-1067** Camera, License Plate Chrome

DP-1051-1 Harness, Sirius Interface DP-1068** Camera, Universal Black

DP-TYJBL1 Harness, JBL Adaptor

* Included with DP-1066, DP-1067, and DP-1068

** DP-1010 Camera/Sensor harness included

*** OEM 3.5mm Aux input will NOT be retained when this harness is used

Main Harness Diagram

Tabla de contenidos

Otros manuales de Sistema de vídeo para coche de Rosen

Rosen

Rosen 10.2 Manual de usuario

Rosen

Rosen Rosen inVUE II Manual de usuario

Rosen

Rosen AV7500 Guía de referencia

Rosen

Rosen DS-TY0820-H11 Manual de usuario

Rosen

Rosen T10 Manual de usuario

Rosen

Rosen A9 Manual de usuario

Rosen

Rosen AV7500 Manual de usuario

Rosen

Rosen MAZDACX-7 DS-MZ0740 Manual de usuario

Rosen

Rosen PR-UN1670 Manual de usuario

Rosen

Rosen GM SERIES DS-GM0710 Manual de usuario

Rosen

Rosen T10 Manual de usuario

Rosen

Rosen AV7500 Manual de usuario

Rosen

Rosen AV7700 Manual de usuario

Rosen

Rosen R5505 Manual de programación

Rosen

Rosen ClearVue CV6825 Manual de usuario

Rosen

Rosen AV7500 Manual de usuario

Rosen

Rosen AV7700 DVD ENTERTAINMENT SYSTEM Manual de usuario

Rosen

Rosen T8 Guía de referencia

Rosen

Rosen AV7700B Guía del usuario

Rosen

Rosen GM SERIES DS-GM0710 Manual de usuario

Rosen

Rosen A8 Manual de usuario

Rosen

Rosen ClearVue Overhead Monitor Manual de usuario

Rosen

Rosen AV7700 Guía de referencia

Rosen

Rosen DS-TY0830-H11 Manual de usuario

Manuales populares de Sistema de vídeo para coche de otras marcas

Stinger

Stinger HEIGH10 RB10RAM13B Manual de usuario

Eonon

Eonon E1057 Manual de usuario

Milion

Milion D2223 Manual de usuario

Metra Electronics

Metra Electronics 99-8153 Manual de usuario

Voxx Electronics

Voxx Electronics HR8MA1 Manual de usuario

Axxera

Axxera AV604Bi Manual de usuario

Clarion

Clarion NX706E Manual de usuario

Pyle view

Pyle view PLDN74BTi Manual de usuario

Clarion

Clarion NX602 Manual de usuario

PowerAcoustik

PowerAcoustik PTID-5850N Manual de usuario

RCA

RCA DRC6296 - Twin 9" Mobile DVD System Guía del usuario

Lanzar

Lanzar SVDVD5 Manual de usuario

Kia

Kia MTXM100YPPE Manual de usuario

Eonon

Eonon E1060 Manual de usuario

Macrom

Macrom M-AN900 Manual de usuario

Hyundai

Hyundai BAPE-L3000N Manual de usuario

r.LiNK

r.LiNK RL2-UCON8-SM Manual de usuario

Blaupunkt

Blaupunkt DVP 01C Manual de usuario
