Rosen AV8900H Manual de usuario
Dual Multimedia
Headrest Replacement
Entertainment System
Quick Start Guide
NOTICE OF INTENDED USE
Rosen Electronics are designed to enable viewing of video
ONLY for rear-seat occupants, and are not intended for
viewing by the driver when the vehicle is in motion. Such
use might distract the driver or interfere with the driver’s
safe operation of the vehicle, and thus result in serious
injury or death. Such use might also violate state or local
laws.
Rosen Electronics disclaims any liability for any bodily
injury or property damage that might result from any
improper or unintended use.
About the Registered Marks
This item incorporates copy protection technology that is protected by U.S. patents
and other intellectual property rights of Rovi Corporation. Reverse engineering and
disassembly are prohibited.
without notice
Manufactured under license from Dolby Laboratories.“Dolby” and the double-D
symbol are trademarks of Dolby Laboratories.
iPod®and iPhone®are registered trademarks of Apple, Inc.
NOTICES
For complete Owner’s Manual, please visit
Rosen Electronics online at
www.RosenElectronics.com
1
Turning On The System
A) Turn vehicle ignition to ON or ACC
B) Press POWER on the front display or wireless remote on each system
Front Panel Controls
HOME/BACK
SPEAKER
UP
LEFT/PREVIOUS
POWER/ENTER
RIGHT/NEXT
DOWN
PLAY/PAUSE
EJECT
A) Turn on by pressing the OFF/ON button located on the ear piece. The power
LED on the ear piece should illuminate. If not, check that the batteries are
inserted properly and have a charge.
B) The headphones each have a two-position slide switch labeled “Ch.A/
Ch.B”. They must have a clear line of sight to the headrest monitor and must be
switched to the designated A/B Channel to operate properly.
C) To adjust the volume, use the knob on the ear piece.
2
Using The Headphones
Remote Control
Home
Eject
Enter
Return
3
Playing A Disc
A) Use the LEFT or RIGHT button to navigate to DVD mode.
B) Press the ENTER button to select DVD source.
C) With the label facing away, insert a disc into the disc slot. Do not force disc
into slot. If a DVD/CD menu appears on the screen, press PLAY or ENTER as
instructed on the screen. Most disc will load and play automatically.
D) To obtain best viewing angle, adjust the screen display as needed by pressing
the bottom corners of the screen housing.
!"#$$
technology from time to time which may create compatibility issues. This is not a problem
with the unit and is not covered by warranty.
Please check with the Owner’s Manual for more detailed information.
A) Press the HOME button on the front panel of the remote controller.
B) Use the LEFT or RIGHT button and navigate to the source desired.
C) Press ENTER to select the source.
Note: Some of the sources can be accessed directly through the remote controller.
Changing The Video Source
4
The USB/MicroSD sources can be used for media playback, such as video,
audio and photos.
Use the LEFT or RIGHT arrows to the next page.
Use the UP or DOWN arrows to navigate the folder.
Use The HOME to return to the main menu.
Digital Media Player
External Sources
HDMI: The system supports up to 2 external HDMI devices,
such as Smart Phone,Tablet, Gaming Console or any device
with HDMI output.
AUX: A composite 3.5mm AV input at the AV box.
AV IN: A composite 3.5mm AV input on the TFT screen.
A) Press SPEAKER button on the front control panel.
“SPEAKER SOUND ON FM__ PRESS LEFT OR RIGHT TO
ADJUST” will appear on the screen.
B) Turn the vehicle’s radio on and tune to the FM frequency dis-
played on the screen.
C) If radio interference is heard, try another frequency.
Listening Over the Vehicle Speakers
RETURN to go back previous screen.
5
Adjusting The Display
From the Home page, navigate to Settings and press Enter.
Press the UP arrow button to brighten the screen or press the DOWN arrow
button to dim the screen. Once you are done, press the BACK or HOME
button to exit the SETTINGS.
The system can be set to turn on automatically whenever the ACC is on. To set
the system to turn on automatically, within the SETTINGS menu press the LEFT
arrow button to select Auto On Display. Press either the UP or DOWN arrow
button to change settings.
Auto On Displays
FCC Statement
This device complies with Part 15 of the FCC rules. Operation is subject to the
f
ollowing two
conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference that
may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device,pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection againstharmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, thereis no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
1) Reorient or relocate the receiving antenna.
2)Increase the separation between the equipment and receiver.
3)Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
4)Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions:
1) this device may not cause harmful interference, and
2) this device must accept any interference received, including interference
that may cause undesired operation.
Copyright © 2015 Rosen Electronics, All rights reserved.
PN: QSG1002 Rev A
