Rosen R6400V Manual de usuario
Video Entertainment System
VCP
SYSTEM
BY
R6400V
i
Information in this document is subject to change without notice.
Rosen Products LLC may have patents, patent applications, trademarks, copyrights or other
intellectual property rights covering subject matter in this document. The furnishing of this document
does not grant the use license to these patents, trademarks, copyrights, or other intellectual property.
© Copyright Rosen Products LLC 2000
All Rights Reserved
1-1
The Auto VideoEntertainment System is
designed for rear passengers only. The driver
cannot safely view the FPD (flat panel
display) while driving and should not attempt
to do so. Many states have laws that restrict
using a device in the vehicle that receives a
television broadcast.
In most states it is unlawful for the FPD
screen to be visible to the driver, while other
states have yet to address this issue. The
screen can not be located at any point
forward of the back of the driver's seat in:
AL, AZ, CA, CO, LA, MA, MD, MN, NH,
NC, OR, PA, SC, WA and WI.
The following guidelines will help you
operate your video entertainment system
safely and legally:
Never try to drive and view the screen.
Keep the back of the driver's seat forward of
the screen.
If you have a question, please call the Rosen
Tech Center at 1-888-883-2790.
What You Should Know About Having and Using the Auto Video
Entertainment System
in Your Vehicle
SAFE OPERATION
Before You Drive
1-2
The push button on the overhead console releases
the Auto Video™ screen just far enough so that it
can easily be position for optimal viewing. This
action sends power automatically to all the system
components. The screen will display the last video
signal chosen. (see 2-6 configuring your system)
Your system may have a pull latch located on the
bottom of the case. Pull latch down to deploy, the
Auto Video™ screen automatically sends power to
all the system components.
Depending on your type of vehicle, and the
particular Auto Video™ System installed,
the Auto Video™ screen will deploy and
stow in one of the following ways:
DEPLOYMENT AND STOWING
1-3
PUSH BUTTON PULL LATCH
By depressing any of these buttons once, the OSM
displays the button’s function. Press again and the
function is carried out.
The buttons located on the side
of the screen perform many of
the same functions as the
system remote.
MANUAL CONTROLS
1-4
CHANNEL UP
SPEAKERS
VIDEO SOURCE
CHANNEL DOWN
CHANNEL UP/DOWN
Scrolls up and down preset TV channels or
scrolls up and down TV channels (see
configuration settings).
VIDEO SOURCE
Selects video source
TV
VCP
AUX
SPEAKERS
Selects audio on or off to the speakers of the
vehicle sound system. Also, pressing and
holding this button for 5 seconds will turn
off the system.
The status indicator light is located on the right
side face of the viewing panel just under the word
"POWER". This indicator will display green when
the vehicle’s key is turned on. This indicates that
the system is ready for operation. The video
entertainment system includes a temperature
sensor. This sensor prevents the system from
operating when the temperature inside the vehicle
is too cold or too hot. The status LED will flash
green under this condition. This is a normal
feature of the system. As the interior of the vehicle
warms up or cools down the LED will return to a
constant green light and the system will be ready
for operation.
Status Indi ator Light
1-5
Status LED
2-2 System Remote Control
2-4 OSM (on-screen menus)
REMOTE CONTROL AND OSM
2-1
