ROSE DISPLAYS ANOFRAME SQUARE WITH NO LOAD WITH MULTICLIPS Manual de usuario

Parts

35 Congress Street, Salem MA 01970

Tel# 1-800-631-9707 Fax# 1-800-560-2890

e-mail:signware@rosedisplays.com

AnoFrame

Step 1

Insert corner brackets into vertical

AnoFrame side rails. Fig. 1 & Fig.2

Note: Assembly brackets tension

tabs face towards outside of frames.

Step 2

Install MultiClip(s) in top frame rail.

Holding clip at slight angle, first insert

one round end, then press down on

other round end and push MultiClip

into rail. Fig 2

Step 3

Push top and bottom horizonral Ano

rails onto one side rail as shown in Fig.

Step 4

Insert poster through side opening.

Fig 4

Step 5

Push final side rail into place as shown

in Fig 5. Suspend poster.

Note: The AnoFrame shown here is

a square profile. It is available in

either round or square profile.

Instructions For Assembly

Incept-8.15.02

Figure 1

Figure 5

The AnoFrame is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss

or damage resulting from the use of these products.

Part #02INSANFRNoLoadSQ

Figure 3

Corner

Brackets

MultiClips

1UP-0100

AnoFrame Rails

12AF-100

Figure 2

Figure 4

Square Profile Instruction Sheet

top horizontal rail w/MultiClip(s)

horizontal rail

side rail

Parts

AnoFrame

Step 1

Insert corner brackets into vertical

AnoFrame side rails. Fig. 1 & Fig.2

Note: Assembly brackets tension

tabs face towards outside of frames.

Step 2

Install MultiClip(s) in top frame rail.

Holding clip at slight angle, first insert

one round end, then press down on

other round end and push MultiClip

into rail. Fig 2

Step 3

Push top and bottom horizonral Ano

rails onto one side rail as shown in Fig.

Step 4

Insert poster through side opening.

Fig 4

Step 5

Push final side rail into place as shown

in Fig 5. Suspend poster.

Note: The AnoFrame shown here is

a square profile. It is available in

either round or square profile.

Instructions For Assembly

Incept-8.15.02

Figure 1

Figure 5

The AnoFrame is a trademark of Rose Displays, Ltd. Neither the

manufacturer nor any sales agent may be held liable for injury, loss

or damage resulting from the use of these products.

Part #02INSANFRNoLoadSQ

Figure 3

Corner

Brackets

MultiClips

1UP-0100

AnoFrame Rails

12AF-100

Figure 2

Figure 4

Square Profile Instruction Sheet

top horizontal rail w/MultiClip(s)

horizontal rail

side rail
