Ronix 2703 Manual de usuario
ROTARY HAMMER
2703
ROTARY HAMMER
2
SPECIFICATIONS
WARNING!
The electric hammer chisel power tool noise output may exceed
85dB(A) at the workplace. In this instance, wear ear protection.
Wear safety-hearing protection
Wear Dust mask
Wear safety goggles
Wear safety shoes
Wear hard hat
SDS-Plus Chuck Plus tting
Chuck 32mm
Voltage 230V 50Hz
Reversible No
Input power 1500w(approx.)
Impact hammer action 860r/minapprox.)
Weight 5.2 kgs(approx.)
USER MANUAL 3
KNOW YOUR ELECTRIC HAMMER
POWER TOOL SAFETY
.GENERAL SAFETY RULES
WARNING!
Read all instructions Failure to follow all instructions listed below
may result in electric shock, re and/or serious injury. The term
“power tool” in all of the warnings listed below refers to your
mains operated (corded) power tool or battery operated (cordless)
power tool.
SAVE THESE INSTRUCTIONS
.WORK AREA
Keep work area clean and well lit. Cluttered and dark areas
invite accidents.
Do not operate power tools in explosive atmospheres, such as
in the presence of ammable liquids, gases or dust. Power tools
create sparks, which may ignite the dust or fumes.
Keep children and bystanders away while operating a power
tool. Distractions can cause you to lose control.
ROTARY HAMMER
4
.ELECTRICAL SAFETY
Power tool plugs must match the outlet. Never modify the plug in
any way. Do not use any adapter plugs with earthed (grounded)
power tools. Unmodied plugs and matching outlets will reduce
risk of electric shock.
Avoid body contact with earthed or grounded surfaces such as
pipes, radiators, ranges and refrigerators. There is an increased
risk of electric shock if your body is earthed or grounded.
Do not expose power tools to rain or wet conditions. Water
entering the power tool will increase the risk of electric shock.
Do not abuse the cord. Never use the cord for carrying, pulling or
unplugging the power tool. Keep cord away from heat, oil, sharp
edges or moving parts. Damaged or entangled cords increase
the risk of electric .
When operating a power tool outdoors, use an extension cord
suitable for outdoor use. Use of a cord suitable for outdoor use
reduces the risk of electric shock
.PERSONAL SAFETY
Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use a power tool while you
are tired or under the inuence of drugs, alcohol or medication.
A moment of inattention while operating power tools may result
in serious personal injury.
Use safety equipment. Always wear eye protection. Safety
equipment such as dust mask, non-skid safety shoes, hardhat,
or hearing protection used for appropriate conditions will reduce
personal injury.
USER MANUAL 5
Avoid accidental starting. Ensure the switch is in the OFF position
before plugging in. Carrying power tools with your nger on the
switch or plugging in power tools that have the switch ON invites
accidents.
Remove any adjusting key or wrench before turning the power
tool on. A wrench or key left attached to a rotating part of the
power tool may result in personal injury.
Do not overreach. Keep proper footing and balance at all times.
This enables better control of the power tool in unexpected sit-
uations.
Dress properly. Do not wear loose clothing or jewellery. Keep
your hair, clothing and gloves away from moving parts. Loose
clothes, jewellery or long hair can be caught in moving parts.
If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly
used. Use of these devices can reduce dust related hazards.
.POWER TOOL USE AND CARE
Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and
safer at the rate for which it was designed.
Do not use the tool if the switch does not turn it ON or OFF. Any
power tool that cannot be controlled with the switch is dangerous
and must be repaired.
Disconnect the plug from the power source before making any
adjustments, changing accessories or storing power tools. Such
preventive safety measures reduce the risk of starting the power
tool accidentally.
Store idle power tools out of the reach of children and do not
allow persons unfamiliar with the power tool or these instructions
ROTARY HAMMER
6
to operate the power tool. Power tools are dangerous in the
hands of untrained users.
Maintain power tools. Check for misalignment or binding of
moving parts, breakage of parts and any other condition that may
affect the power tools operation. If damaged, have the power
tool repaired before use. Many accidents are caused by poorly
maintained power tools.
Keep cutting tools sharp and clean. Properly maintained cutting
tools with sharp cutting edges are less likely to bind and are
easier to control.
Use the power tool, accessories and tool bits etc., in accordance
with these instructions and in the manner intended for the partic-
ular type of power tool, taking into account the working conditions
and the work to be performed. Use of the power tool for operations
different from intended could result in a hazardous situation.
.SERVICE
Tool service must be performed only by qualied personnel.
Service or maintenance performed by unqualied personnel
could result in risk of injury.
When servicing a tool, use only identical replacement parts.
Follow instructions in the Maintenance section of this manual.
Use of unauthorized parts or failure to follow Maintenance in-
structions may create a risk of electric shock or injury.
USER MANUAL 7
.SPECIFIC SAFETY RULES
WARNING!
For your safety, do not plug in your Power tool until you have
read and understood this Owner’s Manual.
- WEAR EYE PROTECTION. Use face or dust mask along with
safety goggles. Use hearing protection, particularly during ex-
tended periods of operation, wear safety shoes, wear hard hat.
- “Wear ear protectors with impact chisels. Exposure to noise
can cause hearing loss”
- DO NOT wear gloves, jewellery, neckties or loose clothing.
- DO NOT drill, cut or sand material too small to be securely held.
- ALWAYS keep hands out of the path of the drill bit and saw
blade. Avoid awkward hand positions where a sudden slip could
cause your hand to move into the path of the drill bit or saw
blade.
- SECURE WORKPIECE. Use clamps or a vice to hold the work
when practical. It is safer than using your hand and it frees both
hands to operate the tool.
- MAKE SURE there are no nails or foreign objects in the part of
the workpiece to be cut drilled or sanded.
.SPECIFIC SAFETY RULES – CONT’D
TO AVOID INJURY from accidental starting, always remove the
Plug from the electrical socket before installing or removing a
chisel bit.
ROTARY HAMMER
8
DRILL SAFETY
- When using electric hammer chisel only use bits that are
congured with the correct slots for this chuck.
- BEFORE STARTING the operation, jog the chisel switch to
make sure the chisel bit does not wobble or vibrate.
- DO NOT USE y cutters or multiple-part hole cutters, as they
can come apart or become unbalanced in use.
- MAKE SURE the spindle has come to a complete stop before
touching the chuck or attempting to change the chisel bit also
beware that the bit will be hot, let it cool down before changing
as it could burn and cause injury.
- ALWAYS MAKE SURE THE CHISEL OR CHISEL IS FIRMLY
SEATED IN THE Hex CHUCK before starting the job in hand.
SYMBOLS
Some of the following symbols may be used on your tool. Please
study them and learn their meaning. Proper interpretation of
these symbols will allow you to operate the tool better and safer.
V volts
A amperes
Hz hertz
W watt
Kw kilowatts
F farads
microfarads
l litres
Kg kilograms
bar bars
USER MANUAL 9
Pa pascals
h Hours
min minutes
s seconds
No load speed
./min or minˉ¹ Revolutions or reciprocations per minute
direct current
alternating current
² two-phase alternating current
2N two-phase alternating current with neutral
three-phase alternating current
3N three-phase alternating current with neutral
Rated current of the appropriate fuse-link in amperes
Time-lag miniature fuselink where X is the symbol for the
time/current characteristic, as given in EN 60127
protective earthing at earthing terminal, Class I tools
Diameter
0 Off position
Arrow
Warning symbol
alternating or direct current
splash proof construction
watertight construction
class II construction
IPXX IP symbol
ROTARY HAMMER
10
ACCESSORIES & CARTON CONTENTS
.AVAILABLE ACCESSORIES
WARNING!
Use only accessories recommended for this electric hammer
chisel. Follow instructions that accompany accessories. Use of
improper accessories may cause injury to the operator or damage
to the cordless drill.
Do not use any accessory unless you have completely read the
instructions or Owner’s Manual for that accessory.
-Various chisels
CARTON CONTENTS
WARNING!
If any part is missing or damaged, do not plug the chisel into
the power source until the missing or damaged part is replaced.
Carefully unpack the tools see “Components chart” at right hand
side of this page
NOTE:
See illustration of components on Page 10.
WARNING!
To avoid re or toxic reaction, never use gasoline, naphtha,
acetone, lacquer thinners or similar highly volatile solvents to
clean the tool.
