Rollei DPF-100 Manual de usuario

English

Cautions

Precautions and maintenance

For indoor use only.

To avoid risk of fire or electric shock, do not expose the unit to moisture or

condensation.

To avoid overheating, do not block the ventilation holes on the back of the Digital Photo

Frame.

Keep the Digital Photo Frame out of direct sunlight.

Do not dismantle the Digital Photo Frame. There is a risk of electric shock and there are

no user-serviceable parts inside. Dismantling the Digital Photo Frame will void your

warranty.

Cleaning the LCD Screen

Treat the screen carefully. Because the screen of the Digital Photo Frame is made of

glass and it would easily be broken or scratched.

If fingerprints or dust accumulate on the LCD screen, we recommend using a soft,

non-abrasive cloth such as a camera lens cloth to clean the LCD screen.

Moisten the cleaning cloth with the cleaning solution and apply the cloth to the screen.

WARNING:

To reduce the risk of electric shock, do not expose the unit to rain or

excessive moisture.

This device is intended for private use and not suitable for commercial

use!

Introduction:

Thank you for the purchase of the Digital Photo Frame. It is designed to allow quick and easy

view of photos taken from your digital camera, mobile phone, or from a memory storage

card. Please read this User Manual carefully to learn the correct way to use the Digital Photo

Frame.

Features

：

1. Supported picture format: JPEG

2. Supported audio format: Mp3& WMA

3. Supported video format: MPEG-1, MPEG-2, MPEG-4（Divx4.0, Divx5.0）, Xvid, AVI, H.264

and M-JPEG

4. Supported memory card: SD/SDHC/MMC/MS

5. USB connection: Mini USB & USB 2.0

6. 2GB internal memory

7. Auto Slideshow when inserting Memory Card

8. Picture & Music: Slideshow with background music

9. Support viewing pictures in preview mode

10. The maximum Resolution is 1280*720 pixels for the video file. The maximum Frame

rate is 30fps and the maximum Bitrate is 11M bps.

11. Built-in Clock and calendar with slideshow Window, schedule auto on/off.

12. Image-display mode: slideshow, preview, zoom, rotate function.

13. Adjustable slideshow speed

14. Copying files to a USB memory stick and delete files from memory cards and internal

memory

15. Built-in stereo speaker (2x2W) and earphone Jack

16. OSD languages: German, English, French, Spanish, Portuguese, Italian, Greek, Czech,

Hungarian, Polish, Danish, Swedish ,Norwegian, Finnish ,Dutch

Packaging Check List:

1. 10 inch digital photo frame

2. AC/DC adaptor

3. Remote control

4. User manual

5. Warranty card

6. Facebook card

7. Bracket

8. Long USB Cable

1 piece

1piece

1 piece

CONTENTS

1. Product Diagram ············································································································· 3

1.1 Remote Control······································································································ 3

1.2 Back Side Buttons··································································································· 4

1.3 Left side of the frame····························································································· 4

2. Installing & Replacing the Battery··················································································· 4

3. Getting Started················································································································ 4

4. Operating Instruction······································································································ 5

4.1 Card and USB ········································································································· 5

4.2 Picture Mode ········································································································· 6

4.3 Music Mode ··········································································································· 6

4.4 Video Mode ··········································································································· 6

5. Calendar ·························································································································· 7

6. File（Copy and Delete）································································································ 7

7. Setup ······························································································································· 7

8. PC Connection（Optional）··························································································· 8

9. Stand Instruction…………………………………………………………………………………………………………. 8

10. Technical Specifications ································································································ 9

11 . Troubleshooting Guide··································································································· 9

1. Product Diagram

1.1 Remote Control

1) POWER ─ Switch On/Off

2) BGM ─ Press the button to play music during a slide show in the background

3) MUTE ─ Press Mute button to switch of the sound temporarily.

4) MENU ─ Open the main menu

5) ─Functional selection button from the bottom to the top cursor.

6) RETURN ─ Return to previous page.

7) ─ Functional selection button from right to left cursor

8) ─ Functional selection button from left to right cursor

9) ─ Functional selection button from the top to the bottom cursor.

10) SETUP ─ Accessing the settings menu

11) ─ Play/pause: In the playing mode, press this button, it will pause; repress this

button, it will play again.

12) OK ─ Press to confirm. Play/pause: In the playing mode, press this button, it will pause;

repress this button, it will play again.

13) ZOOM ─ In the pause state of single picture, press ZOOM to magnify picture display size.

14 /15) VOL +/-─ Turn up/down the volume.

16) Rotate ─ In single-frame mode, pause the image 90 ° counterclockwise.

17) ─ Move back to previous music or video file.

18) ─ Move forward to next music or video file.

1.2 Back side Buttons

1.3 Left side of the frame

2. Installing & Replacing the Battery

To open the battery compartment of the remote control, press the battery cover and pull the

drawer out, Insert a CR2025 lithium button battery with the "+" side facing up. Close the

drawer

3. Getting Started

3.1 Put the digital photo frame with installing bracket on a flat position steadily, then plug

one end of the AC adapter into a standard 110-240V AC electrical outlet and the other

end into the DC IN slot on the left side of the frame.

3.2 Slowly remove the protective film covering on the Screen.

3.3 Remove the plastic battery insulator from the battery compartment and make sure the

remote control has a battery inside. Please refer to “Installing & Replacing Battery” if

you need a new battery.

3.4 Press the Power Button on the Remote Control to Switch On/Off.

1. Power on/off

2. Up

3. Vol +/Right

4. Play/Pause/OK

5. Vol -/ Left

6. Down

7. Menu

1. SD/MMC/MS Card

2. Earphone Jack

3. USB

4. Mini USB

5. DC in

4. Operating Instruction

Note: Selection interface with 15 languages is "System Settings" reappears only after

selecting the "Setup" option in the menu.

4.1 Card and USB

The Frame supports SD/SDHC/MMC/MS Cards and USB 2.0. After inserting a card or USB

device, the frame plays automatically the file format you selected in the Auto-start Menu.

Press Return to access to Photo, Music, Video, Calendar, File and Setting. Press OK to

confirm.

Note:

1) Make sure there are supported Picture-, Music- or Video-files on the Card or USB device.

2) If there are supported picture and music files in the Card or USB Device, the frame will

start the playback automatically.

Power on the unit for the first time it will show

the startup logo first and a interface with a

16-languages selection appears on the screen.

Press to choose and press OK to select

the language. The unit will start an auto

slideshow from the internal Memory. It will

preferentially play the files from the inserted

storage device or the files selected in the Auto

start Mode.

You can set Auto start Mode in the

Setup-Menu.

4.2 Picture Mode

4.3 Music Mode

4.4 Video Mode

During Video playback press or for fast forward and fast backward. Press to

pause/Play

Press to start the playback of the previous or next video.

Press Return to select the Storage Device. Press

OK to open the main menu, select Photo and

press OK to start slideshow. Press Return to

open the Preview mode and use to

select the desired function. Press OK to confirm

your selection. To play back the slideshow with

background Music, the Music must be stored in

the same memory device! You can use Vol+/Vol-

to turn up /down the volume, you can also use

to go to the previous/next background

music.

Press Return (RETURN) to open the main menu

Select Music Icon and press OK to enter, press

to select the music in the playlist. Press

OK to Play/Pause. Press VOL+/- to turn up/

down the volume. With you can enter

the previous or next music playing directly.

Press

Return

to select the Storage Device. Press

OK to enter the main menu. Select the Movie

Icon and press OK to enter. Press Return to

select the video from the playlist, then press OK

to Play. Press VOL+/- to turn up/ down the

volume.

5. Calendar

6. File

Copy and Delete function

Use the Up and Down buttons to the desired file. Then press . The selection menu for copying

and deleting appears. Select the desired function and confirm your selection with OK. Confirm

the new query.

Note: Files can be copied to the internal memory.

7. Setting

Select Calendar in the Main Menu, press OK to

enter. The calendar will be shown on the right

side of the screen. On the left side a slideshow

will start. The supported Picture files must be

stored in the selected storage device.

Adjust date with .

Select File in the main menu and press OK to

enter. You can browse all files on your selected

storage device. Press or to choose the

file and press OK to open the file or folder.

Select

Setting

in the main menu. Press

enter the Setting interface and press to

highlight your selection. Press OK to enter the

sub-menu items. Press to set the Value.

In this menu basic settings can be set as

language or time, the playback quality or the

timer.

8. PC Connection

You can connect the unit to the external equipment by using USB Cable for file copy &delete or

edit Operation.

A. Please turn on the digital photo frame, then connect it with the USB cable to your PC. The

Frame supports Windows 2000/XP/Vista/7/8.

B. The unit will be automatically detected and it will display "PC Connecting" on the screen.

You can edit or delete files in the internal memory or an inserted in the picture frame

storage media copy from the computer. You need to restart the digital photo frame after

you finished the operation.

NOTE: Never disconnect the USB cable during any operational process. Doing so may

damage your DPF. Press Safely Remove Hardware Icon on the computer to disconnect the

PC-Connection.

9. Stand Instruction

Insert the bracket into the slot of the digital photo frame and rotate the bracket clockwise.

Please make sure the stand is locked before you put it on the table steadily .Please refer to

the illustration showing below.

10. Technical Specifications

Adapter: Input AC 100-240V 50/60HZ Output DC 5V/2A

Picture Format: JPEG

Audio Format: MP3& WMA

Video formats: MPEG-1 , MPEG-2, MPEG-4,M-JPEG and AVI&H.264

Memory Cards: SD/SDHC/MMC/MS

USB: USB Host, Mini USB

Screen Parameter:

Screen Size: 10 inch TFT

Resolution : 1024*768 pixels

Contrast: 300:1

Aspect Ratio: 4:3

Brightness: 200cd/m2

Response Time: 20ms

Viewing Angle: 60°(left/right/vertical), 40°(horizontal)

Working Temperature: 0°C ~40°C, Humidity: 10-85%

11.Troubleshooting Guide

If you come across when using the photo frame on problems, consult the suggested

solutions below, and the corresponding sections of this manual. If you need additional

assistance, please contact technical support.

No power:

Please check whether the AC-Adaptor is inserted correctly.

Remote control has no function:

Please check whether the battery has power (the battery can be used for half year in

normal conditions). Replace with a new battery if necessary.

Cannot read the Memory Card or USB-Device:

Please confirm there are supported files on your memory card or USB device.

Empty devices cannot be read.

Cannot play the file:

Please confirm if the file format is compatible with the player.

Display too bright or too dark:

Please adjust the brightness or contrast in the setup menu.

The color is light or no color:

Please adjust the color and contrast setup.

No sound:

Please check whether the volume is correct and the player is not in Mute mode.

Tabla de contenidos

Otros manuales de Marco de fotos digital de Rollei

Rollei

Rollei DPF102 Manual de usuario

Rollei

Rollei Designline 90 Manual de usuario

Rollei

Rollei DF-8 DVB-T Guía del usuario

Rollei

Rollei Camille Pissarro DPF-86 Manual de usuario

Rollei

Rollei Pictureline PL 6130 Manual de usuario

Rollei

Rollei Smart Frame WiFi 105 Manual de usuario

Rollei

Rollei Designline 150 Manual de usuario

Rollei

Rollei Smart Frame WiFi 102 Manual de usuario

Rollei

Rollei Pissarro DPF-82 Manual de usuario

Rollei

Rollei Pissarro DPF-960 Manual de usuario

Rollei

Rollei Pictureline PL 6150 Manual de usuario

Rollei

Rollei Pissarro DPF-80 Manual de usuario

Rollei

Rollei Smart Frame WiFi 150 Manual de usuario

Rollei

Rollei Pissarro DPF 170 Manual de usuario

Rollei

Rollei Degas DPF 150 Manual de usuario

Rollei

Rollei Pictureline PL 4200 Manual de usuario

Rollei

Rollei Designline 80 Manual de usuario

Rollei

Rollei Smart Frame WiFi 100 Manual de usuario

Rollei

Rollei Gauguin DPF-13.3 Manual de usuario

Rollei

Rollei DF-8 DVB-T Manual de usuario

Rollei

Rollei DF-80 Manual de usuario

Rollei

Rollei Pissarro DPF-880 Manual de usuario

Rollei

Rollei DPF150W31R Manual de usuario

Rollei

Rollei Smart Frame WiFi 101 Manual de usuario

Manuales populares de Marco de fotos digital de otras marcas

LENCO

LENCO DF-830 Manual de usuario

NIX

NIX Advance X10G Manual de usuario

Nextar

Nextar N7S-100 Manual de usuario

Sungale

Sungale TD350A Manual de usuario

texet

texet DPF-830 Instrucciones de montaje

Philips

Philips SPF2017 Manual de usuario

Philips

Philips SPF1327 Manual de usuario

Philips

Philips SPF7010/10 Manual de usuario

Digital Spectrum

Digital Spectrum MemoryVue MV-1500 Manual de usuario

ViewSonic

ViewSonic VFM1042-52 Manual de usuario

YURAKU

YURAKU YUR.PHOTO 7B4C Manual de usuario

Denver

Denver PFF-710WHITE MK2 Manual de usuario

Pandigital

Pandigital PAN8000DWPCF1 Manual de usuario

Rekam

Rekam Deja View HD-850 Manual de usuario

Majestic

Majestic DF 918HD MP3 Manual de usuario

ViewSonic

ViewSonic DPF8-CAM Manual de usuario

Philips

Philips SPF2527 Manual de usuario

Digital Foci

Digital Foci Image Moments IMT-063 Manual de usuario
