Hi!
Let’s get started.
What’s in the box
Roku player
Remote control with
in-ear headphone jack
2 x AA Alkaline
batteries
In-ear headphones Power adapter
D
Get to know your Roku
B
G
F
C
Front view
Back view
A
E
Ethernet port – Connects your Roku player to a wired network with an
Ethernet cable (not included).
HDMI port – Connects your Roku player to an HDTV with an HDMI cable
(not included).
Reset button – Resets your Roku player to its original factory settings
when pressed and held for 10 seconds (a feature you’ll rarely, if ever, use).
Status light – Flashes slowly when the Roku player starts up. Glows when
it’s on. Flashes once with each press of the remote control.
Storage expansion slot – Lets you increase your storage capacity for
Roku channels and games with a microSD card (optional, not included).
Power port – Connects your Roku player to a 120V AC power source with
the included power adapter.
USB port – Plays your home videos, movies, music and photos from
supported USB drives. For supported file types, visit roku.com/usb.
Did you notice? Your Roku player has no on/o switch. It’s simpler that way
and draws very little power—less than a nightlight! Keep it plugged in so that
it can download the latest software updates automatically.
What you need
Roku player
HDTV
High-speed Internet connection
(DSL or cable modem)
Router
HDMI cable
(sold separately)
Pssst! Your router can be wireless (any Wi-Fi) or wired. For wired networks,
you’ll also need an Ethernet cable (not included).
What to do Step 1
Ready for the step-by-step? We’ve only got four…
Connect your player
Use an HDMI cable (not included) to make the connection depicted in the
diagram below:
Did you know? Because HDMI outputs digital video and audio, you don’t
need a separate audio cable. HDMI also supports up to 7.1 surround sound
(where available). Got a receiver? You can also use HDMI to route video and
audio directly through your receiver if it supports HDMI video pass-through.
•Connect one end to the HDMI port on the back of your Roku player.
•Connect the other end to an open HDMI port on your TV.
What to do Step 2
Power up key components
In this step, we’ll make sure all systems are GO!
First, power your Roku remote by inserting the included batteries:
•Turn the remote control over and locate the rectangular battery door on the
rear of the unit.
•Press the latch at the top of the battery door down while simultaneously
removing the battery door.
•Insert each battery negative (-) side first, pushing it into the coil and then into
the compartment. Do NOT insert batteries positive (+) side first. Place the
battery door back over the compartment and press it gently down until the
latch snaps securely into place.
Power tip! Always replace dead batteries with two brand-new batteries from
the same manufacturer. Never use damaged batteries. If your remote gets
warm/hot during use, discontinue use and contact Roku Customer Support
immediately at support.roku.com
What to do Step 2 (continued)
Next, power on your Roku player by connecting it to a wall outlet using the
included power adapter, like this:
Finally, power on your TV and look for a Roku message to fill the screen.
Blank screen? If your TV does not display a Roku screen, make sure your TV
input matches the physical connection used to connect your Roku player. Press
the Input button (sometimes called Source) on your TV or TV remote to cycle
through the various video inputs available until you see a Roku screen.
What to do Step 3
Configure your network
Step 3 establishes your network connection and brings out your inner geek. You
can do it! Just choose either wireless or wired and read on for instructions:
Wireless: If you use a wireless network, you can grab that Roku remote and jump
right into Guided Setup. When prompted, select “Wireless” as your network
connection and have your network name and password ready. Then:
•Select your network from the list of available networks.
•Enter your network password, if you use one. Remember, network passwords
are case sensitive.
Dos and don’ts on where to place your Roku player:
•DO place your player within range of your wireless network.
•DON’T place your player in an enclosed cabinet; it may interfere with
the wireless signal.
•DON’T place your player beneath anything; it may cause the player to
overheat. Eeeeks.
