and call for qualified electrician!
Equipotential bonding wire (up to 10 sq.mm) shall be connected to screw
terminal marked with IEC 5021 sign.
It is necessary to check electric wires and ground connection of the machine
periodically. In case of faults found, an electrician must be called. It is allowed to
turn the machine on only after all the issues are resolved.
1.6. Ambient conditions
The equipment must be operated at the ambient temperature between +5° and
+40°C (+41°F to +104°F), relative humidity not more than 45% at 40°C/104°F).
Altitude above sea level should not exceed 1000 m.
1.7. Getting started
Unpack the unit carefully, check the delivery set. Remove protective film from
metal surfaces. Insert plastic container firmly into the cradle. Put coater onto
even surface; make sure that there are no items obstructions that may affect
machine operation. Lock all four swivel casters to avoid unexpected machine
roaming.
2. Intended use
2.1. Principle of operation
General appearance of the coater is shown on Fig.1. Coater is made of
stainless steel. Main parts of the machine are: stand (1) mounted on swivel
locking casters (2); electric motor (3) with cradle (4) fixed to motor’s shaft; main
motor switch (5); plastic container (6) for popcorn; covering lid (7); locking
handle (8); tabletop (9) with openings where two GN1/9 containers (not shown)
and an oil pump (not shown) can be accommodated
.
The principle of operation is the following. Popcorn and seasoning that put into
container are being mixed (i.e. popcorn is being coated with seasoning) due to
container rotation.
GN1/9 containers and oil pump are not included in the delivery set and can be ordered
separately, if required!
