INSTALLATION
The installation scenariodescribed in thismanual
assumes that youhave a typicalcar.
If your specific car requires any adjustments or
modifications , consult your nearest DELOScar
audio dealer.
PRECAUTIONS
This unit is designed for negative- ground,
12-V DC operationonly.
Before starting installation, make sure the
ignition switch isset to OFFand disconnect the
ground terminal ofthe car batteryto avoid short-
circuiting.
Install the unitwhere it willnot injure theopera-
tion of thevehicle.
Install the unitwhere it willnot injure thepassen-
ger if whereis a suddenstop, like anemergency
stop.
Avoid installing theunit where itwould be subject
to high temperaturescaused by directsunlight
or hot airfrom the heater, or where it would be
subject to dust,dirt or excessivevibration
Use only thesupplied mounding hardwarefor a
safe and secureinstallation.
REINSTALLATIONS
FRONT PANEL INSTALLATION
BASIC INSTALLATION
If there is installation hardware for another
receiver already in the dashboard, it must be
removed. Before installing the unit inthe dash-
board, Remove thetrim plate fromthe unit. Then,
please remove thescrews( )on thetop of unit.
Store the detachable in its protective case for
safe keeping. To drop /take away /install and
recover front panel,see the picture.
Mounting-angle adjustment
The mounting angleshould be 30degrees or
less from horizontal.
Caution on installationwithout using thesleeve
Be sure touse the screws( )attach the mounting
brackets. (Not supplied).
Note that theinstallation show isa typical
example.
For some cartypes you mayneed to make
adjustments or modificationto make adjustments
or modification toinstall the unit.F your caris of
such type, consultyou nearest DELOS car audio
dealer.
4
a3
12
A
B
BC
12
A
4
3
a
C
DETACHABLE
FACEPLATE
INSTALL BRACKET
CONSOLE
B
Page27
b
b
a
a
c
c
F
F
F
E
E
A
A
B
B
B
C
C
C
D
D
d
d
++++
++++
--
--
--
--
--
Grey
White
Grey/black
White/black
GROUND
(ACC)
(AUTO ANT)
(BACK UP B )
Black
Red
Blue
POWER ANTENNA
IGNITION
Pink (POWER AMP)
CONTROL
RELAY
BATTERY
1A
15A
Yellow
Violet/Black
Green/Black
Violet
Green
++
++
LL
RR
++++
++++
--
--
----
----
++
++
LL
RR
++
++
--
--
--
--
++
++
LL
RR
++
++
--
--
--
--
++
++
LL
RR
++
++
--
--
--
--
CONNECTIONS
PRECAUTIONS
PRECAUTION ON MAKINGCONNECTIONS
Before connecting, make surethat the ignition switch
is set toOFF.And removethe ground terminalof the
battery to protectthe unit andyour car fromdamage.
Caution
make the connectioncorrectly, asillustrated in the
connection diagram. Do notconnect the negative
cord of each speakerwire to a commonpoint.
When replacing thefuse. Be sureto use afuse of the
same rated amperage.
Use of afuse of ahigher rating maycause serious
damage to the unit.
One or moreof the connectors , and may
not exist onthe model yourchased. Make the
appropriate connection orconnections according
to the configuration ofyour unit.
See the section“SPECIFICATIONS” of the
separate Operating Instructions.
From the car antenna
VIDEO OUT
To theout per jackof the optionalpower
amplifier (Line out)Colors ofleads
Aux in
To thewiring of the vehiclecolors of leads
Note
lies speakers with animpedance of 4 to8 ohms and
with adequate power handingcapacities. Otherwise,
the speakers may bedamaged.
Do not connect thespeakers in parallel.
Do not connect theterminal of the speakersystem to
the car chassis.
4-SPEAKER CONNECTIONS
Black (ground lead tobe connected to
vehicle <metal> boby.)
Red (ACC lead tobe connected tothe terminal
from which poweris supplied whenthe ignition
switch is setto AC.)
Yellow(battery lead tobe connected tothe
backup terminal ofthe which poweris supplied.)
Blue (power antenna leadto be connectedto the
terminal of thecontrol
This lead isnot used fora vehicle witha manual
antenna or aswitch operated
power antenna. Ifyou will usethe optional power
amplifier with theunit, connect thislead to the
remote terminal of theamplifier.)
Pink (Power amp remotecontrol)
CONNECTION DIAGRAM
+
