ring RPP70 Manual de usuario
12v
only
<40°c
Compact
PowerPack
RPP70 - 12v, 7Ah Compact PowerPack
www.ringautomotive.co.uk
Instructions
The ultimate automotive essential...
The ideal leisure accessory
Fully charge this product before use - Charge time 30 hours
Powering 7Ah PowerPack Instructions.indd 1 30/04/2010 13:39
1
2
3
Contents
Safety
Caution
RPP70 PowerPack Instructions
AC Mains Charger
Input: 220/240v
Output: 13.5v 500mA
Replacement part number: RPT50
Reverse Polarity Protection
Ensure no power is transfered if
the booster cables are connected
incorrectly.
To maintain optimum performance and long term life this PowerPack must
be fully recharged:
• Every 3 months if not used
• Before each use
• After each use
• From complete discharge the PowerPack will take 30 hours to fully charge
Anti-Arc Protection
The battery clips will not spark if
touched together.
Circuit Protection
Prevents too much power draw from
the DC outlet, prevents surging.
12v
only
<40°c
12v
only
Powering 7Ah PowerPack Instructions.indd 2 30/04/2010 13:39
4Features
12v DC
socket
12v DC
socket
1x Battery status
indicators
Charge status
indicator
Connection
Indicator
LED work lightOn/Off switch Reverse polarity
protection
Selection
switch
USB
applications
0% 25% 75% 100%
Powering 7Ah PowerPack Instructions.indd 3 30/04/2010 13:39
5
2
AC charging
3
Recharging the PowerPack
30 hours
Disconnect any 12v DC appliances
• Plug the 230v AC mains charger into the
charging socket on the PowerPack
• Plug the mains charger into 230v AC mains supply
• Turn on mains supply
• Charging is indicated by the red ‘Charging indicator’
LED illuminating
• Once charging is complete the ‘Charging / Charged’ LED will
change from red to green
• A full charge takes approximately 30 hours
NB: If the charge light changes to green before 30 hours on
the initial charge, continue charging for the remainder of
the 30 hours.
Powering 7Ah PowerPack Instructions.indd 4 30/04/2010 13:39
6
1
2
3
4
5
Vehicle jumpstarting
Ensure the ON/OFF switch is in the ‘OFF’ position
Disconnect any 12v DC appliances
Turn off the LED work light
Turn off the vehicle ignition
Position the PowerPack on a flat surface away from engine
moving parts.
Connect the booster cable
Red (+) clip to the red positive (+) battery terminal
Black (-) clip to the black (-) battery terminal
Check Connection
If the Reverse polarity indication LED illuminates the battery
clips are connected incorrectly. Check the connections and retry.
Rotate the ON/OFF switch to the ‘ON’ position.
Ensure cables are clear of moving parts before starting the engine.
Powering 7Ah PowerPack Instructions.indd 5 30/04/2010 13:39
6
7
Turn over the engine in 3 second bursts until the engine starts.
With the vehicle’s engine running, leave the PowerPack for 2-3mins
to fast charge the PowerPacks batteries before disconnecting.
DC appliances are connected and powered by connecting to the
PowerPacks DC power socket.
The LED work light is operated by sliding the selection switch the
LED position.
The USB charging socket allows the recharging of electronic
devices including moblie phones and MP3 players
The USB feature is selected by sliding the selection switch to the
USB position.
Disconnect booster cables
For optimum and long life performance ‘RECHARGE THE
POWERPACK’.
7
8
9
12v DC Power
LED Work Light
USB charging socket
12v DC
socket
15
A
Powering 7Ah PowerPack Instructions.indd 6 30/04/2010 13:39
10 Specifications
Internal battery Sealed Lead Acid
Internal battery capacity 7Ah
DC socket maximum
continuous load 12A
DC power socket circuit
breaker (auto reset) 12A
Integral work lamp LED
Jump start cables 0.5m
PowerPack
Dimensions
260mm (L)
x 100mm (W)
x 330mm (H)
Weight 2.8 kg
Spare Parts Part No.
AC mains charger RPT50
Caution:
No serviceable parts. Do not use if leads are damaged -
danger of shock
Powering 7Ah PowerPack Instructions.indd 7 30/04/2010 13:39
Distributed by: Ring Automotive Limited,
Gelderd Road, Leeds, England LS12 6NA
+44 (0)113 213 2000 +44 (0)113 231 0266
autosales@ringautomotive.co.uk www.ringautomotive.co.uk
Powering 7Ah PowerPack Instructions.indd 8 30/04/2010 13:39
