Rigol MSO8064 Manual de usuario

User Guide

MSO8000 Series Digital

Oscilloscope

Mar. 2021

RIGOL TECHNOLOGIES CO., LTD.

RIGOL

MSO8000 User Guide I

Guaranty and Declaration

Trademark Information

RIGOL®is the trademark of RIGOL TECHNOLOGIES CO., LTD.

Publication Number

UGA26104-1110

Software Version

00.01.02.00.00

Software upgrade might change or add product features. Please acquire the latest

version of the manual from RIGOL website or contact RIGOL to upgrade the

software.

Notices

⚫RIGOL products are covered by P.R.C. and foreign patents, issued and pending.

⚫RIGOL reserves the right to modify or change parts of or all the specifications

and pricing policies at the company’s sole decision.

⚫Information in this publication replaces all previously released materials.

⚫Information in this publication is subject to change without notice.

⚫RIGOL shall not be liable for either incidental or consequential losses in

connection with the furnishing, use, or performance of this manual, as well as

any information contained.

⚫Any part of this document is forbidden to be copied, photocopied, or rearranged

without prior written approval of RIGOL.

Product Certification

RIGOL guarantees that this product conforms to the national and industrial

standards in China as well as the ISO9001:2015 standard and the ISO14001:2015

standard. Other international standard conformance certifications are in progress.

If you have any problem or requirement when using our products or this manual,

please contact RIGOL.

E-mail: servi[email protected]

Website: www.rigol.com

RIGOL

II MSO8000 User Guide

Safety Requirement

General Safety Summary

Please review the following safety precautions carefully before putting the

instrument into operation so as to avoid any personal injury or damage to the

instrument and any product connected to it. To prevent potential hazards, please

follow the instructions specified in this manual to use the instrument properly.

Use Proper Power Cord.

Only the exclusive power cord designed for the instrument and authorized for use

within the local country could be used.

Ground the Instrument.

The instrument is grounded through the Protective Earth lead of the power cord. To

avoid electric shock, connect the earth terminal of the power cord to the Protective

Earth terminal before connecting any input or output terminals.

Connect the Probe Correctly.

If a probe is used, the probe ground lead must be connected to earth ground. Do not

connect the ground lead to high voltage. Improper way of connection could result in

dangerous voltages being present on the connectors, controls or other surfaces of

the oscilloscope and probes, which will cause potential hazards for operators.

Observe All Terminal Ratings.

To avoid fire or shock hazard, observe all ratings and markers on the instrument and

check your manual for more information about ratings before connecting the

instrument.

Use Proper Overvoltage Protection.

Ensure that no overvoltage (such as that caused by a bolt of lightning) can reach the

product. Otherwise, the operator might be exposed to the danger of an electric

shock.

Do Not Operate Without Covers.

Do not operate the instrument with covers or panels removed.

Do Not Insert Objects into the Air Outlet.

Do not insert anything into the holes of the fan to avoid damaging the instrument.

Use Proper Fuse.

Please use the specified fuses.

RIGOL

MSO8000 User Guide III

Avoid Circuit or Wire Exposure.

Do not touch exposed junctions and components when the unit is powered on.

Do Not Operate with Suspected Failures.

If you suspect that any damage may occur to the instrument, have it inspected by

RIGOL authorized personnel before further operations. Any maintenance,

adjustment or replacement especially to circuits or accessories must be performed

by RIGOL authorized personnel.

Provide Adequate Ventilation.

Inadequate ventilation may cause an increase of temperature in the instrument,

which would cause damage to the instrument. So please keep the instrument well

ventilated and inspect the air outlet and the fan regularly.

Do Not Operate in Wet Conditions.

To avoid short circuit inside the instrument or electric shock, never operate the

instrument in a humid environment.

Do Not Operate in an Explosive Atmosphere.

To avoid personal injuries or damage to the instrument, never operate the

instrument in an explosive atmosphere.

Keep Product Surfaces Clean and Dry.

To avoid dust or moisture from affecting the performance of the instrument, keep the

surfaces of the instrument clean and dry.

Prevent Electrostatic Impact.

Operate the instrument in an electrostatic discharge protective environment to avoid

damage induced by static discharges. Always ground both the internal and external

conductors of cables to release static before making connections.

Use the Battery Properly.

Do not expose the battery (if available) to high temperature or fire. Keep it out of the

reach of children. Improper change of a battery (lithium battery) may cause an

explosion. Use the RIGOL specified battery only.

Handle with Caution.

Please handle with care during transportation to avoid damage to keys, knobs,

interfaces, and other parts on the panels.

RIGOL

IV MSO8000 User Guide

Safety Notices and Symbols

Safety Notices in this Manual:

WARNING

Indicates a potentially hazardous situation or practice which, if not

avoided, will result in serious injury or death.

CAUTION

Indicates a potentially hazardous situation or practice which, if not

avoided, could result in damage to the product or loss of important data.

Safety Terms on the Product:

DANGER

It calls attention to an operation, if not correctly performed, could

result in injury or hazard immediately.

WARNING

It calls attention to an operation, if not correctly performed, could

result in potential injury or hazard.

CAUTION

It calls attention to an operation, if not correctly performed, could

result in damage to the product or other devices connected to the

product.

Safety Symbols on the Product:

Hazardous

Voltage

Safety Warning

Protective Earth

Terminal

Chassis Ground

Test Ground

RIGOL

MSO8000 User Guide V

Measurement Category

MSO8000 series digital oscilloscopes can make measurements in Measurement

Category I.

WARNING

This oscilloscope can only be used for measurements within its specified

measurement categories.

Measurement Category Definitions

Measurement category I is for measurements performed on circuits not directly

connected to MAINS. Examples are measurements on circuits not derived from

MAINS, and specially protected (internal) MAINS derived circuits. In the latter case,

transient stresses are variable. Thus, you must know the transient withstand

capability of the equipment.

Measurement category II is for measurements performed on circuits directly

connected to low voltage installation. Examples are measurements on household

appliances, portable tools and similar equipment.

Measurement category III is for measurements performed in the building installation.

Examples are measurements on distribution boards, circuit-breakers, wiring

(including cables, bus-bars, junction boxes, switches and socket-outlets) in the fixed

installation, and equipment for industrial use and some other equipment. For

example, stationary motors with permanent connection to a fixed installation.

Measurement category IV is for measurements performed at the source of a

low-voltage installation. Examples are electricity meters and measurements on

primary overcurrent protection devices and ripple control units.

Ventilation Requirement

This oscilloscope uses a fan to force cooling. Please make sure that the air intake and

exhaust areas are free from obstructions and have free air. When using the

oscilloscope in a bench-top or rack setting, provide at least 10 cm clearance beside,

above and behind the instrument for adequate ventilation.

WARNING

Inadequate ventilation may cause an increase of temperature in the

instrument, which would cause damage to the instrument. So please

keep the instrument well ventilated and inspect the air outlet and the fan

regularly.

RIGOL

VI MSO8000 User Guide

Working Environment

Temperature

Operating: 0℃to +50℃

Non-operating: -30℃to +70℃

Humidity

Operating:

Below +30℃: ≤90%RH (without condensation)

+30℃to +40℃: ≤75%RH (without condensation)

+40℃to +50℃: ≤45%RH (without condensation)

Non-operating:

Below 65℃: ≤90% RH (without condensation)

WARNING

To avoid short circuit inside the instrument or electric shock, never

operate the instrument in a humid environment.

Altitude

Operating: below 3 km

Non-operating: below 15 km

Installation (Overvoltage) Category

This product is powered by mains conforming to installation (overvoltage) category

II.

WARNING

Ensure that no overvoltage (such as that caused by a bolt of lightning)

can reach the product. Otherwise, the operator might be exposed to the

danger of an electric shock.

Installation (Overvoltage) Category Definitions

Installation (overvoltage) category I refers to signal level which is applicable to

equipment measurement terminals connected to the source circuit. Among these

terminals, precautions are done to limit the transient voltage to a low level.

Installation (overvoltage) category II refers to the local power distribution level

which is applicable to equipment connected to the AC line (AC power).

Pollution Degree

Pollution Degree 2

RIGOL

MSO8000 User Guide VII

Pollution Degree Definition

Pollution Degree 1: No pollution or only dry, nonconductive pollution occurs. The

pollution has no effect. For example, a clean room or air-conditioned office

environment.

Pollution Degree 2: Normally only nonconductive pollution occurs. Temporary

conductivity caused by condensation is to be expected. For example, indoor

environment.

Pollution Degree 3: Conductive pollution or dry nonconductive pollution that

becomes conductive due to condensation occurs. To be found in industrial

environment or construction sites (harsh environments). For example, sheltered

outdoor environment.

Pollution Degree 4: The pollution generates persistent conductivity caused by

conductive dust, rain, or snow.

For example, outdoor areas.

Safety Class

Class 1 –Grounded Product

Care and Cleaning

Care

Do not store or leave the instrument where it may be exposed to direct sunlight for

long periods of time.

Cleaning

Clean the instrument regularly according to its operating conditions.

1. Disconnect the instrument from all power sources.

2. Clean the external surfaces of the instrument with a soft cloth dampened with

mild detergent or water. When cleaning the LCD, take care to avoid scarifying it.

CAUTION

To avoid damage to the instrument, do not expose it to caustic liquids.

WARNING

To avoid short-circuit resulting from moisture or personal injuries, ensure

that the instrument is completely dry before connecting it to the power

supply.

RIGOL

VIII MSO8000 User Guide

Environmental Considerations

The following symbol indicates that this product complies with the WEEE Directive

2002/96/EC.

Product End-of-Life Handling

The equipment may contain substances that could be harmful to the environment or

human health. To avoid the release of such substances into the environment and

avoid harm to human health, we recommend you to recycle this product

appropriately to ensure that most materials are reused or recycled properly. Please

contact your local authorities for disposal or recycling information.

You can click on the following link https://int.rigol.com/services/declaration.html to

download the latest version of the RoHS&WEEE certification file.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Equipo de prueba de Rigol

Rigol

Rigol MSO8000 Series Manual de usuario

Rigol

Rigol DS1000CA series Instrucciones de funcionamiento

Rigol

Rigol DS7000 Series Manual de usuario

Rigol

Rigol DHO1202 Manual de usuario

Rigol

Rigol MSO2000A Series Manual de usuario

Rigol

Rigol MSO1000Z series Manual de usuario

Rigol

Rigol DG2052 Manual de usuario

Rigol

Rigol MSQ7054 Manual de usuario

Rigol

Rigol MS05000-4CH Manual de usuario

Rigol

Rigol DS1302CA Manual de usuario

Rigol

Rigol MSO4000 Series Manual de usuario

Rigol

Rigol MSO1000Z series Manual de usuario

Rigol

Rigol DHO924 Manual de usuario

Rigol

Rigol MSO1000Z series Instrucciones de funcionamiento

Rigol

Rigol MSO2000A Series Manual de usuario

Rigol

Rigol DG900 Pro Series Manual de usuario

Rigol

Rigol DG800 Pro Series Instrucciones de funcionamiento

Rigol

Rigol DS1000 Series Instrucciones de funcionamiento

Rigol

Rigol DHO900 Manual de usuario

Rigol

Rigol DS1102E Manual de usuario

Rigol

Rigol DS1000Z Series Manual de usuario

Rigol

Rigol DS4024E Manual de usuario

Rigol

Rigol RP7000 Series Manual de usuario

Rigol

Rigol DS2000A Series Manual de usuario

Manuales populares de Equipo de prueba de otras marcas

SMART

SMART KANAAD SBT XTREME 3G Series Manual de usuario

Agilent Technologies

Agilent Technologies BERT Serial Manual de usuario

Agilent Technologies

Agilent Technologies N3280A Manual de usuario

Vernier

Vernier Go Direct Voltage Manual de usuario

Lifeloc

Lifeloc R.A.D.A.R. Manual de usuario

Fluke

Fluke T5-600 Instrucciones de funcionamiento e instalación

Mercury

Mercury TSL01 Manual de usuario

MAHA

MAHA MBT Series Manual de usuario

Fuji Electric

Fuji Electric P-61 Manual de usuario

ETC

ETC SealerAtor Manual de usuario

Skyfine

Skyfine ETHYWAY V2 Manual de usuario

Appion

Appion G5 Twin Manual de usuario

PCB Piezotronics

PCB Piezotronics 8159-0112A Manual de usuario

BW Technologies

BW Technologies MicroDock II Manual de usuario

Sun Nuclear

Sun Nuclear 1027 Manual de usuario

Biomark

Biomark HPR LITE READER Manual de usuario

Hioki

Hioki 3169-20 Manual de usuario

Ashcroft

Ashcroft ATE-100 Manual de usuario
