Ricoh SG 7100DN Manual de usuario

v20140514

DO NOT INSTALL THE RICOH (OEM) INKS THAT WERE PROVIDED WITH THE PRINTER.

DO NOT POWER ON THE PRINTER BEFORE INSTALLING SAWGRASS SUBLIJET-R INK CARTRIDGES.

DURING DOWNTIME, IT IS HIGHLY RECOMMENDED TO LEAVE THE PRINTER POWERED ON TO ALLOW

THE RICOH AUTOMATIC MAINTENANCE UTILITIES TO KEEP THE PRINT HEAD NOZZLES CLEAR.

CAUTION

INsTALLATION GUIDE

PowerDriver V4

Windows 7 & 8

Ricoh SG 7100DN

SECTIONS:

There are two steps required to complete the installation

and conguration process for the SubliJet-R PowerDriver

V4 to work with the Ricoh SG7100DN printer. Complete

both as described below for optimum results.

* Step 1 is included in this document. Steps 2 and 3 are located on the Sublijet-R SG7100DN

PowerDriver V4 Installation and Conguration webpage on sawgrassink.com and can be accessed

by the link provided above.

Steps:

1) Download, install and register the SubliJet-R PowerDriver V4

2) Congure your design software* (i.e. CorelDRAW, PhotoShop, Illustrator, etc.)

3) Using the Sawgrass color palette*

Page 1

Notes:

a) PowerDriver V4 is only compatible with Windows versions 7 and 8.

b) The Ricoh OEM printer driver is now automatically installed.

Ricoh SG 7100DN – Installation Guide

Step 1 of 2: PowerDriver V4 Download & Installation

PAGE 1 of 15 >>

1) Locate the Sawgrass Technologies website by entering sawgrassink.com in the address eld of your

web browser. Once there, hold the mouse arrow over Technical Support in the menu bar. From

the drop down list that appears select SubliJet-R, Ricoh SG 7100DN then Windows 7 and 8 (see

FIGURE 1).

FIGURE 1

2) Click on the Installation & Conguration Instructions button (see FIGURE 2).

FIGURE 2

The following instructions explain how to download, install and register the SubliJet-R SG 7100DN

PowerDriver V4 on a computer running Windows 7. These instructions feature Internet Explorer 10.

Your experience may differ based on the operating system and internet browser being used.

SubliJet-R: Ricoh SG 7100DN – Installation Guide

Step 1 of 2: PowerDriver V4 Download & Installation

PAGE 2 of 15 >>

3) Once on the appropriate Installation and Conguration Instructions webpage for your setup, click on the

link in Step 3, Download and install the Ricoh Driver and Sawgrass PowerDriver V4 (see FIGURE 3).

FIGURE 3

4) On the webpage that appears, click the link for the Ricoh SG 7100DN in the PowerDriver section

(see FIGURE 4).

FIGURE 4

Note: At anytime during the download and installation process, your rewall or virus protection

software may present warnings. Make the appropriate selections necessary to continue.

SubliJet-R: Ricoh SG 7100DN – Installation Guide

Step 1 of 2: PowerDriver V4 Download & Installation

PAGE 3 of 15 >>

5) The following window will appear asking if you want to Run, Save or Cancel. Click Save (see FIGURE 5).

FIGURE 5

6) The le will begin downloading into the Downloads folder on your computer. When complete, the

download message at the bottom of the screen will give you the option to Run, Open or View

downloads. Click Run (see FIGURE 6).

FIGURE 6

Placeholder Images

Do you want to run or save SJR_7100_US_v1.0a27.exe (13.7MB) from sawgrassles.bluekeyinc.com?

The SJR_7100_US_v1.0a27.exe download has completed.

SubliJet-R: Ricoh SG 7100DN – Installation Guide

Step 1 of 2: PowerDriver V4 Download & Installation

PAGE 4 of 15 >>

7) Select the appropriate language and click OK to continue (see FIGURE 7).

FIGURE 7

8) Verify that the PowerDriver is for the correct printer. If so, click Next (see FIGURE 8).

FIGURE 8

SubliJet-R: Ricoh SG 7100DN – Installation Guide

Step 1 of 2: PowerDriver V4 Download & Installation

PAGE 5 of 15 >>

9) If you agree with the terms of the License Agreement, click I Agree (see FIGURE 9).

FIGURE 9

10) Click Install to allow PowerDriver to be installed into the correct destination folder (see FIGURE 10).

FIGURE 10

SubliJet-R: Ricoh SG 7100DN – Installation Guide

Step 1 of 2: PowerDriver V4 Download & Installation

PAGE 6 of 15 >>

11) If the appropriate Ricoh OEM printer driver is not currently installed, it will begin to download. The

following status screen will be displayed during this process (see FIGURE 11).

FIGURE 11

FIGURE 12

12) Once the download has complete the Ricoh OEM driver will be installed.You will need to accept the

Software License Agreement for installation to continue. If you agree with the terms select I accept the

agreement and click Next (see FIGURE 12).

Note: If the appropriate OEM printer driver is already installed and what is displayed in Figure 11 does

not appear, skip to step 22.

SubliJet-R: Ricoh SG 7100DN – Installation Guide

Step 1 of 2: PowerDriver V4 Download & Installation

PAGE 7 of 15 >>

13) Select Add a new printer and click Next (see FIGURE 13).

FIGURE 13

14) Select how the printer is connected to your computer and click Next (see FIGURE 14). For this example

we will select Connect USB cable.

FIGURE 14

SubliJet-R: Ricoh SG 7100DN – Installation Guide

Step 1 of 2: PowerDriver V4 Download & Installation

PAGE 8 of 15 >>

15) The following screen will appear asking you to select your printer (see FIGURE 15). Highlight RICOH

AcioSG7100DN RPCS-R and click Next.

FIGURE 15 B

16) Ensure your printer is powered OFF and click Next to continue (see FIGURE 16).

FIGURE 16
