Ricoh M156 Manual

Rm-MF1/Rm-P1 Training

Slide 1

M156/M157/M176/M177 (Rm-MF1)

M154/M155/M174/M175 (Rm-P1)

Service Training

Version 1.0

These models are similar to the Rn series of printers and copiers.

Rm-MF1/Rm-P1 Training

Slide 2

M156/M157/M176/M177 (Rm-MF1)

M154/M155/M174/M175 (Rm-P1)

Service Training

Product Overview

No additional notes

Rm-MF1/Rm-P1 Training

Slide 3

What Models are in this Series?

Rm-MF1a

Rm-MF1a

M156: SP 311SFN, No AIO refill

M176: SP 310SFN, AIO can be refilled

Rm-MF1aw

M157: SP 311SFNw, Wireless LAN, No AIO refill

M177: SP 310SFNw, Wireless LAN, AIO can be refilled

Type A and B models

M15x is also known as Type A; M17x is also known as

Type B

For Type B there are two sub-types, based on destination:

» For CHN: The AIO has hole through which the AIO can be

refilled with toner. Bags of toner for refilling are also sold.

» For EU/AA/NA: The AIO has no hole. The machine is

designed for refill, but bags of toner for refilling are not sold

No additional notes

Rm-MF1/Rm-P1 Training

Slide 4

What Models are in this Series?

Rm-P1a

Rm-P1a

M154: SP 311DN, No AIO refill

M174: SP 310DN, AIO can be refilled

Rm-P1aw

M155: SP 311DNw, Wireless LAN, No AIO refill

M175: SP 310DNw, Wireless LAN, AIO can be

refilled

The note about Type A and Type B models on the

previous slide also applies here.

No additional notes

Rm-MF1/Rm-P1 Training

Slide 5

Differences from Previous Models

Rm-MF1 vs Rn-MF1/MF2

PCLPCL/PS3PCL/PS3PDL

NoYesYesOptional Tray

Some models (China

only)

NoNoAIO Refill

200k350k200kMachine Life

Some modelsNoNoWireless LAN

50 sheets125 sheets125 sheetsOutput Capacity

All modelsSome modelsSome modelsDuplex

2 boards1 board1 boardPSU and High

Voltage Power Pack

1 board2 boards2 boardsController and

Engine Boards

4 lines2 lines2 linesDisplay Panel

China onlyNoNoHandset

CISCCDCCDScanner

ADFADF/ARDFADFADF

282828PPM (A4)

Rm-MF1Rn-MF2Rn-MF1

No additional notes

Rm-MF1/Rm-P1 Training

Slide 6

Differences from Previous Models

Rm-P1 vs Rn-P1/P2

YesNoYesSOM (Smart

Organizing Monitor)

PCLPCL/PS3PCL/PS3PDL

NoYesYesOptional Tray

Some models (China

only)

NoNoAIO Refill

200k350k200kMachine Life

Some modelsNoNoWireless LAN

125 sheets125 sheets125 sheetsOutput Capacity

All modelsSome modelsSome modelsDuplex

2 boards1 board1 boardPSU and High

Voltage Power Pack

1 board2 boards2 boardsController and

Engine Boards

No2 linesNoDisplay Panel

282828PPM (A4)

Rm-P1Rn-P2Rn-P1

No additional notes

Rm-MF1/Rm-P1 Training

Slide 7

Other Points

Rm-MF1/P1 do not have a USB host or the scan

to USB feature.

No additional notes

Rm-MF1/Rm-P1 Training

Slide 8

M156/M157/M176/M177 (Rm-MF1)

M154/M155/M174/M175 (Rm-P1)

Service Training

Specifications

No additional notes

Rm-MF1/Rm-P1 Training

Slide 9

General Specifications (1)

Printing Speed, A4(LT): 28 ppm (LT: 30 ppm)

First Print Speed: Less than 8 sec (A4, LT SEF)

Duplex Printing: Auto (Standard, approx 50% productivity)

Memory: 128 MB (no optional memory)

Resolution: 1200 x 600 / 600 x 600 dpi

Interfaces

MF1a/P1a: USB2.0, 10BASE-T/100BASE-TX Ethernet

MF1aw/P1aw: USB2.0, 10BASE-T/100BASE-TX Ethernet,

IEEE802.11b/g/n

PDL: PCL5e, PCL6

Network Protocols: TCP/IP, IPP

No additional notes

Rm-MF1/Rm-P1 Training

Slide 10

General Specifications (2)

Input capacity

Standard Tray: 250 sheets (80 g/m2)

Bypass tray: 50 sheets (80 g/m2)

Output capacity (Standard Tray, Face down)

MF1: Up to 50 sheets

P1: Up to 125 sheets (A4/LT or 80 g/m2, 20lb)

Input Paper Size

Standard Tray: A4,B5,A5,B6,A6,Legal,Letter,HLT,Exective,F,Foolscap,Folio,16K

» Custom size: Min. 100mm x 148mm (3.9" x 5.92"), Max. 216mm x 356mm (8.64" x 14.24")

Bypass Tray: A4,B5,A5,B6,A6,Legal,Letter,HLT,Exective,16K,Envelope:

#10,Monarch,C5,C6,DL

» Custom size: Min. 90mm x 140mm (3.6" x 5.92"), Max. 216mm x 356mm (8.64" x 14.24")

Media Type

Standard Tray: Plain Paper, Recycled Paper, Thick Paper, Thin Paper

Bypass Tray: Plain Paper, Recycled Paper, Thick Paper, Thin Paper

Paper Weight

Standard Tray: 52-162g/m2 (14-43lb)

Bypass tray: 52-162g/m2 (14-43lb)

Duplex: 60-105g/m2 (16-28lb)

ADF

Capacity: 35 sheets

Original size

» Min: 139.7mm x 139.7mm (5.5'' x 5.5''), Max: 215.9mm x 355.6mm (8.5'' x 14'')

Original weight: 52-105g/m2 (14-28lb)

No additional notes
