Richter RR28 Manual de usuario
MODEL: RR28
User Manual
DAB+ |FM + AM Tuner
DIGITAL RADIO
DIGITAL RADIO DAB+ | FM + AM TUNER
2
Contents
Important safety information.................................................... 3
Specications, Service & Packing List..................................... 4
Precautions.............................................................................. 5
Your Portable DAB+/FM/AM Digital Radio .............................. 6
Basic Operation....................................................................... 7
1. Power Supply ...................................................................... 7
2. Normal Operation ................................................................ 7
3. Listening to DAB.................................................................. 8
4. Manual Scan........................................................................ 8
5. Listening to FM & AM Mode ................................................ 9
6. Preset Memory Settings ...................................................... 9
7. Listening to Headphones................................................... 10
8. Setting Time....................................................................... 10
9. Auto Time Set .................................................................... 10
10. Manual Time Set.............................................................. 10
11. Alarm Settings...................................................................11
Alarm Setup......................................................................11
Snooze Function...............................................................11
Sleep Mode Setting ......................................................... 12
12. Backlight Setting.............................................................. 12
13. Factory Reset .................................................................. 12
Troubleshooting..................................................................... 13
Error Messages ..................................................................... 13
Warranty ........................................................................... 14-15
3
MODEL: RR28
Important Safety Information
• This product is only intended for audio entertainment. Do not use the product for
any other purpose than described in is manual in order to avoid any hazardous
situation. Improper use is dangerous and will void any warranty claim.
• For household use only. Do not use outdoors.
• Danger! Excessive sound pressure from earphones and headphones can cause
hearing loss. If you listen to loud music for a long time, your hearing may be
impaired. Set to a moderate volume.
• Danger of suffocation! Keep all packaging material away from children.
• Only use under normal room temperature and humidity conditions.
• The product is only suitable for use at moderate degrees of latitude. Do not use in
the tropics or in particularly humid climates.
• Outdoor antennas should be located away from power lines.
• Do not move the product from cold into warm places and vice versa. Condensation
can cause damage to the product and electrical parts.
• Do not use attachments or accessories other an recommended by the manufacturer
or sold with this appliance. Install in accordance with is user manual.
• When installing the product, leave sufficient space for ventilation. Do not install in
bookcases, built-in cabinets or the like.
• Do not install near any heat sources such as radiators, heat registers, stoves or
other appliances (including amplifiers) that produce heat.
• Do not apply excessive force to the front or top, as is could ultimately overturn the
product.
• Do not shift or move the product when powered on.
• Do not touch, push or rub the surface of the product with any sharp or hard objects.
• Danger! To reduce the risk of fire or electric shock, do not expose this product to
rain or moisture.
• The product should not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, should be placed on the product.
• No naked flame sources, such as lighted candles, should be placed on the product.
• Before connecting the product to a socket outlet, make sure the voltage indicated
on the product corresponds to your local mains.
• Never pull the adaptor power plug by the supply cord or with wet hands.
• Disconnect the adaptor power plug in case of faults during use, during lightning
storms, before cleaning and when not using the product for a longer period of time.
• Danger! Before cleaning, switch the product off and disconnect the adaptor power
plug from the socket.
• When the product has reached the end of its service life, make it defective by
disconnecting the adaptor power plug from the socket and cut the cord in two.
DIGITAL RADIO DAB+ | FM + AM TUNER
4
Specications
ITEM SPECIFICATIONS
Model: RR28 DABAM
Speaker: 1 x 3”, 8 ohm dynamic speaker
Output: 1.2W RMS
Frequency Ranges: DAB: 174 - 240 MHz, FM: 87.5 - 108 MHz
AM: 522 - 1620 KHz
Mains Power Supply: AC: 230V ~ 50Hz
Battery Power Supply DC: 4.5V Battery (3 x C Batteries (not supplied))
Dimension: 185mm (W) x 50mm (H) x 120mm (D) (excluding
Handle)
Wieght (Net): Approx. 0.56 kg
*Information of this user manual is subject to change without prior notice.
.
Service
This product should be repaired or serviced only by an authorised service
engineer and only genuine spare parts should be used.
Thank you for purchasing this Richter DAB AM Digital Radio.
Please read the instructions and warnings carefully before use to
ensure safe and satisfactory operation of this product.
Packing List
1 x PORTABLE RR28 DABAM
Digital Radio
1 x Mains Power Lead
1 x Instruction manual
5
MODEL: RR28
Precautions
1. For AC operation, make sure the voltage is compatible. Always use the
supplied AC power cord; never use other AC power cord.
2. Always disconnect the AC power cord from the AC power source when it
is not in use.
3. Your product requires 3 x C batteries (not provided) for portable
operation.
4. Batteries should be removed and replaced by adults only.
5. Only use recommended batteries or those of the same or equivalent type.
6. Do not mix old and new batteries or batteries of different types.
7. Batteries are to be inserted with the correct polarity.
8. The supply terminals are not to be short-circuited.
9. Remove exhausted batteries from item.
10.Remove batteries if equipment is not used for extended periods of time.
11. Rechargeable batteries are to be removed from the item before being
recharged.
12.Rechargeable batteries are only to be charged under adult supervision.
13.Do not attempt to recharge non-rechargeable batteries.
14.Batteries contain substances that may be harmful to the environment and
human health.
15.Keep out of the reach of children and seek immediate medical help if
swallowed.
This symbol indicates that batteries should not be disposed of in
the normal household waste but taken to appropriate local
recycling facilities, where and when these are available
Never throw batteries in a re or attempt to open outer casing.
DIGITAL RADIO DAB+ | FM + AM TUNER
6
Your Portable DAB+/FM/AM Digital Radio
13
10
9 8 7 6 4 1
11
12
15
17
16
5 3 2
14
1
POWER (ON / OFF) / MODE
2
VOLUME +
3
VOLUME -
4
SELECT
5
NEXT
( )
6
PREVIOUS ()
7
PRESET
8
MENU / INFO
9
SCAN
10
CARRYING HANDLE
11
LCD DISPLAY
12
1-10 PRESET KEY
13
SPEAKER
14
ROD ANTENNA
15
AC IN SOCKET
16
BATTERY COMPARTMENT
17
HEADPHONE JACK
7
MODEL: RR28
Basic Operation
1. POWER SUPPLY
AC Operation
• Insert one end of the supplied AC power cord into the AC IN socket
located at the back of the radio and insert the other end into the wall
outlet and switch on. The radio will automatically go into standby
mode when connecting to AC power.
• To disconnect the radio from the AC supply completely, unplug the
AC power cord plug from the wall outlet and from the back of the
radio.
DC (battery) Operation
• To operate your radio on batteries, the AC adaptor must be
disconnected from the radio and wall socket. If not, the unit will
continue to operate on AC power, instead of DC batteries.
• Insert 3 batteries, type R14, UM2 or C cells (not included) into
battery compartment and then close the compartment cover.
Warning: When planning not to use the radio for prolonged periods of
time (i.e., a vacation) disconnect the plug from the wall outlet.
Note: Check your batteries regularly. Old or discharged batteries
should be replaced. If the unit is not to be used for some time or is
being used exclusively on AC main power supply, remove the batteries
from the battery compartment to avoid leakage.
2. NORMAL OPERATION
• Press and hold the POWER/MODE button to switch the radio on.
When your radio is switched on for the rst time it will automatically
enter the DAB mode and perform a Full Auto Scan.
• To change mode Quick press POWER/MODE button once or more
to select FM, AM, or DAB. The display shows the radio station
details throughout the radio mode.
• To search for other stations continue to press the / button until
you nd the station that you want to listen to then press SELECT
button to conrm the station selection.
• To adjust the volume press either VOL- or VOL+ to decrease or
increase the volume.
DIGITAL RADIO DAB+ | FM + AM TUNER
8
• To switch the radio into standby mode, press and hold POWER/
MODE button to enter Standby.
• When using DC Battery power, to switch off the radio, press and
hold POWER/MODE button to switch the radio off.
Note: (There is no standby mode when using DC Battery power to
save battery life)
3. LISTENING TO DAB RADIO
• Press and hold the POWER/MODE button to switch the radio on.
When your radio is switched on for the rst time it will automatically
enter the DAB mode and perform a Full Auto Scan.
• During the scan, the display will show “Scanning………” together
with a progress bar that indicates the progress and the number of
stations that have been found so far. Once the scan has nished,
the unit will select the rst found station.
• To search for other stations continue to press the / button
until you nd the station that you want to listen to then press the
SELECT button to conrm the station selection.
To repeat an Auto Scan, switch the radio on, then press and hold the
SCAN button until the display shows “Scanning ………” together with
a progress bar that indicates the progress of the scan and the number
stations that have been found so far.
DAB Auto Scan: A full auto scan will search the entire DAB Band for
all available stations.
4. MANUAL SCAN
As well as Auto Scan, Radio Station Frequencies can be manually
selected. You can manually tune to a particular channel/frequency,
and you will need to know the missing radio station Frequency to
complete a Manual tune.
• With the radio switched on press and hold MENU/INFO button, then
press / until the display shows “Manual tune” and then press
SELECT.
• Press / to select desired channel (5A-13F), press SELECT to
enter the channel.
9
MODEL: RR28
5. LISTENING TO AM / FM MODE
Manual tuning
• When in FM or AM mode Press / once or more until the desired
frequency is found.
Automatic tuning
• Press and hold the SCAN button until the display frequency starts
to run.
• When a station of sufcient strength has been found it will stop
tuning, or you can start automatic tuning by pressing SCAN again.
6. PRESET MEMORY SETTINGS
You can store the frequencies of up to 60 radio stations in the memory,
(20 in DAB+, 20 in FM and 20 in AM). A stored frequency can be
erased from the memory by storing another frequency in its place.
To preset a station in DAB, FM or AM mode.
• Select your desired band, DAB+, FM or AM and tune to your desired
station.
• Press and hold the PRESET button until you see Preset Store in the
display.
• Press / to select the desired memory position/number and press
SELECT to conrm the selected station to that position/number.
You also have 10 Quick Preset buttons: To preset a station to a
quick preset button 1-0, press and hold the desired PRESET button
1-0 until “Preset Store” appears in the display
Preset Recall Settings
• To Recall a preset station press the PRESET button to enter Preset
Recall mode and press / to select the desired saved station and
press the SELECT button to recall / play that station.
• To Recall a Quick preset position 1-0 just quick press the desired
saved number to play the station saved to it.
To improve reception:
• For FM, pull out the telescopic aerial. To improve FM Reception
incline and turn the aerial, reduce its length if the FM-signal is too
strong (close to a transmitter).
• For AM, the set is provided with a built-in aerial, so there is no need
to use the telescopic aerial. Turn or move the radio to nd the best
position or location.
DIGITAL RADIO DAB+ | FM + AM TUNER
10
7. LISTENING TO HEADPHONES
You can connect a set of headphones (not included) to 3.5mm
HEADPHONE output jack. The radios speaker is then muted.
Note: Avoid listening to headphones at high volume levels to prevent
possible hearing damage.
8. SETTING TIME
When used in DAB radio mode the radio scans the DAB radio signal for
the current time which will appear on the display. If no DAB signal is found,
the time cannot be set. It may be necessary to relocate your radio to a
better position giving better reception or set the time manually.
9. AUTO TIME SETTINGS
With the radio switched on Press and hold MENU/INFO button until you
see Full Scan in the display then Press / until the display shows
“System” and press SELECT to conrm, then Press / until the display
shows “Time” and press SELECT to enter Time settings.
• Auto update: Press / until the display shows “Auto update”, then
press SELECT and press / to select update From Radio or No
Update, then press SELECT.
• 12/24 Hour time: Press / until the display shows “Set 12 / 24
hour”, and press SELECT then Press / to Set 12 or 24 hour
selection and press SELECT to conrm.
• Set date format: Press / until the display shows “Set date format”
and press SELECT, then Press / to Set DD-MM-YYYY or
MM-DD-YYYY selection and press SELECT to conrm.
Default is DD-MM-YYYY
10. MANUAL TIME SET
• With the radio switched on Press and hold MENU/INFO button until you
see Full Scan in the display then Press / until the display shows
“System” and press SELECT to conrm,
• then Press / until the display shows “Time” and press SELECT to
enter and the display will show “Set Time / Date”, then press SELECT.
to enter time and date detup.
To set the hours, minutes, and dates, press / while the display is still
ashing, then press SELECT to conrm hours, minutes and dates.
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Radio de Richter
