QUICK GUIDE

ESPACE

RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE AU CAPITAL DE 533 941 113 € / 13-15, QUAI LE GALLO

92100 BOULOGNE-BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / TÉL. : 0810 40 50 60

RP 759-2 – 82 01 005 860 – 09/2008 – Edition anglaise

à8201005860ïëòä LW

(www.renault.co.uk )(www.renault.ie )(www.renault.is )

SiteWeb ENG

ENG_UD10475_1

Edito (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

WELCOME TO YOUR ESPACE

Note

Congratulations on your choice: in your Espace, the pleasure of travel reaches new heights as you enjoy its generous space in exceptional comfort.

In order to make your experience of your new vehicle as pleasant as possible, we suggest you use this document to find out about the main functions of your

Espace.

This document does not replace the driver’s handbook.

Please read the complete driver’s handbook for more detailed information on the equipment mentioned in the reference guide for your Espace.

A.S.R. (antipatinage) ................................................................................... (page courante)

ENG_UD10476_1

Sommaire (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

Front and engine compartment

Passenger side

Rear seats

Rear

Accessing the vehicle

Starting/Stopping the engine

Driving position

Dashboard

Instrument panel

Lighting/Wipers

Electronic parking brake

Cruise control/Speed limiter

Heating and air conditioning

system

Multimedia systems

Fuel

Gadgets

ENG_UD10477_1

Avant et compartiment moteur (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

Front and engine compartment

FRONT AND ENGINE COMPARTMENT

Screen washer fluid level

Add some fluid in the reservoir 1if necessary.

Coolant level

The level indicated on tank 2should be between

MINI and MAXI.

If it is necessary to top up this level, it is essential

to do so when the engine is cold.

Engine oil level

To check the oil level, use dipstick 3. The level in-

dicated on the dipstick should be between MINI

and MAXI.

The oil level may also be checked on the instru-

ment panel.

Refer to Section 4 of your driver’s handbook for

details of the precautions to be taken when check-

ing the oil level and topping up the oil.

ENG_UD10478_1

Côté passager (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

Passenger side

Deactivating the front

passenger air bag

If you wish to fit a rear-facing child seat on the

front passenger seat, you must deactivate the air

bag: with the vehicle stationary, turn switch 1to

OFF.

Storage compartments

Upper storage compartments A

Centre storage compartment B

Centre storage compartment C

Passenger storage compartment D

Cup holders E

PASSENGER SIDE

Immediately reposition the switch to ON as soon

as you stop using the child seat.

Sockets for audio

connection

Depending on the version, you have the option

to connect your portable audio devices, USB key,

and MP3 player to your vehicle. Specially designed

sockets are located in the central storage compart-

ment C.

Refer to the instructions for the equipment for de-

tails of the connections.

ENG_UD10479_1

Places arrière (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

Rear seats

REAR SEATS

ISOFIX system

Each rear seat is fitted with the ISOFIX child seat

mounting system.

Depending on the type of child seat used, installa-

tion requires specific precautions.

The two rings 7are located between the seatback

and the seat base of the seat and are identified by

a marking on the seat base. To ensure your child

seat can be easily fitted and locked on rings 7, use

access guides 8on the child seat.

Consult your approved dealer to find out about the

equipment available for your vehicle.

Pull release 5fully, and move the seat forwards,

pulling it off the rails.

To remove the seat from the vehicle, use bar 4lo-

cated behind trim A

To refit a seat

Slide the front of the seat in the correct rails, then

tilt it backwards. It will lock into the rails under its

own weight. Finally, adjust the position of the seat

by moving it forward/back.

Check that there are no objects stored behind

trim A.

The modularity of your vehicles allows numerous

combinations thanks to the sliding seats with auto-

matic locking positions.

To adjust a seat

Move a seat backwards or forwards: lift one of

controls 1or 3or pull strap 5.

Adjust the seatback (or table position): lift con-

trol 2or pull strap 6.

To remove a seat

Lower the headrest and tilt the seatback into the

table position.

ENG_UD10480_1

Arrière (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

Rear

REAR

Tyre pressure kit

Depending on the vehicle, in the event of a punc-

ture, use the tyre inflation kit. The compressor

adapter and the bottle are located in rear storage

compartment 1(for vehicles with a standard chas-

sis) or 2(for vehicles with a long chassis);

Refer to Section 5 of your driver’s handbook.

Parking distance control

On equipped vehicles, the parking distance control

measures the distance between the rear (and, de-

pending on the vehicle, the front) of the vehicle and

any obstacles that are nearby.

When approaching an obstacle during manoeuvres,

the beeps become faster and then sound continu-

ously when 25 cm from the obstacle.

The parking distance control can be deactivated

using the switch located on the dashboard.

Emergency spare wheel

Depending on the vehicle, there is an emergency

spare wheel 3provided in the event of a puncture

underneath the vehicle.

– In the luggage compartment, lift cover 5;

– remove the blanking cover;

– use tool 6to fully unscrew the nut so that the

wheel retaining cable unwinds and the wheel

drops to the ground;

– stand the wheel up outside the vehicle;

– press on lock 4and turn it a quarter of a turn;

– run the retaining cable across the wheel rim and

release the wheel;

– depending on the vehicle, take out the shim from

inside the wheel rim.

ENG_UD10481_1

Accès au véhicule (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

Accessing the vehicle

ACCESSING THE VEHICLE

RENAULT REMOTE CONTROL CARD VERSION

Press:

‡

to unlock;

…

to lock;

to switch the exterior lights on/off remotely

(in order to find your vehicle in a car park for ex-

ample).

RENAULT "HANDS-FREE" CARD VERSION

With the card on your person (you can leave it in

your pocket, bag etc.), in addition to the remote

control RENAULT card functions, the following are

possible:

– automatic unlocking by pulling a door handle;

– automatic locking when leaving the vehicle (a

beep sounds).

Note: if required, you can use the manual mode or

the key 1. Take out key 1by pulling it.

Locking/unlocking the

vehicle

The RENAULT card system replaces the tradi-

tional key. Locking/unlocking the vehicle is simple:

whether from a distance or nearby, a single press

is required.

SPECIAL FEATURES

– The detection zone of the card, necessary for

locking and unlocking the vehicle, depends on

the surrounding environment or the location of

the card;

–

…

when locking the doors (for vehicles fitted

with four one-touch electric windows), if you

press and hold this button for more than 2 sec-

onds, the windows (and, depending on the vehi-

cle, the sunroof) close automatically.

NOTE

In all situations:

– two flashes of the direction indicator lights con-

firm locking ;

– one flash of the direction indicator lights con-

firms unlocking.

Never leave the RENAULT card in the vehicle

After locking/unlocking the vehicle or the lug-

gage compartment only using the buttons on the

RENAULT card, remote locking and unlocking in

hands-free mode are deactivated.

To reactivate the hands-free mode: restart the

vehicle.

ENG_UD10482_1

Démarrage/arrêt du moteur (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

Starting/stopping the engine

STARTING/STOPPING THE ENGINE

Starting the engine

With the remote control RENAULT card in reader 2

or the hands-free RENAULT card in the interior de-

tection zone (excluding certain high locations such

as the sun visor, etc.) apply the following starting

conditions:

MANUAL GEARBOX

With the gear lever in neutral, press engine start

button 1.

AUTOMATIC TRANSMISSION

With the lever in position P, press engine start

button 1.

Note: for vehicles fitted with the hands-free

RENAULT card, the brake pedal must be depressed

to allow the engine to be started.

Stopping the engine

When the vehicle is stationary, press engine start

button 1.

Depending on the case, certain functions (radio,

navigation, wipers etc.) may be switched off at the

latest when the vehicle is locked.

ENG_UD10483_1

Poste de conduite : sièges (X81 - J81 - Renault)ENG_RP_759-2_X81_Renault_0

Driving position

DRIVER’S POSITION: SEATS

Electric seat adjustment

TO MOVE THE SEAT FORWARDS OR BACKWARDS

Move switch 4forwards or backwards.

TO RAISE OR LOWER THE SEAT

Move switch 4upwards or downwards.

TO TILT THE SEATBACK

Move switch 6forwards or backwards.

POSITION MEMORY

With the ignition on, press button 5until a beep

sounds.

Heated seats

(depending on vehicle)

With the engine running, press switch 8.

The indicator light in the switch lights up. The

system, which has a thermostat, decides whether

the heating is needed.

Adjusting the lumbar

support on the seat

Move handle 2.

Manual seat adjustment

TO MOVE THE SEAT FORWARDS OR BACKWARDS

Lift lever 3to unlock the seat. Release the handle

at the desired position and make sure that it is

locked.

TO RAISE OR LOWER THE SEAT

Move lever 1as many times as necessary upwards

or downwards.

TO TILT THE SEATBACK

Lift lever 7and tilt the seatback to the desired po-

sition.

Carry out these adjustments when the vehicle

is stationary.

Otros manuales para Espace

Tabla de contenidos

Otros manuales de Automóvil de Renault

Renault

Renault votre Dauphine 2 EDITION Manual de usuario

Renault

Renault Espace Manual de usuario

Renault

Renault Latitude Manual de usuario

Renault

Renault 2013 Clio Cup Manual de usuario

Renault

Renault Kangoo Manual de usuario

Renault

Renault MEGANE Manual de usuario

Renault

Renault KWID Manual de usuario

Renault

Renault LAGUNA Manual de usuario

Renault

Renault ZOE 2020 Manual de usuario

Renault

Renault Espace Manual de usuario

Renault

Renault 2013 Clio Cup Instrucciones de funcionamiento

Renault

Renault KANGOO 2021 Manual de usuario

Renault

Renault KANGOO BE BOP Manual de usuario

Renault

Renault ALASKAN 2020 Manual de usuario

Renault

Renault Latitude Manual de usuario

Renault

Renault KOLEOS Manual de instrucciones

Renault

Renault Laguna Coupe Manual de usuario

Renault

Renault GRAND SCENIC Manual de usuario

Renault

Renault Trafic Manual de usuario

Renault

Renault LAGUNA Manual de usuario

Renault

Renault Duster Manual de usuario

Renault

Renault WIND Manual de usuario

Renault

Renault 2016 MEGANE Manual de usuario

Renault

Renault 2013 Clio Cup Manual de usuario

Manuales populares de Automóvil de otras marcas

Toyota

Toyota 2000 Tundra Manual de usuario

CITROËN

CITROËN DS4 DSign Manual de usuario

Lexus

Lexus 2015 CT 200h Manual de usuario

Cadillac

Cadillac CTS 2008 Manual de usuario

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manual de usuario

Porsche

Porsche Boxster S Manual de usuario

GMC

GMC 2010 Savana 1500 Cargo Manual de usuario

KIAM

KIAM SPORTAGE 2014 Manual de lista de piezas

GMC

GMC 2013 Terrain Instrucciones de montaje

GMC

GMC T-Series 1999 Manual de usuario

Mercury

Mercury 1998 Mystique Manual de usuario

Mercury

Mercury 2007 Mariner Manual de usuario

Mazda

Mazda 2007 Mazdaspeed 3 Guía

Mazda

Mazda 2014 CX-5 Manual de usuario

GMC

GMC Chevrolet Express 2022 Manual de usuario

GMC

GMC 1997 Jimmy Manual de usuario

Chevrolet

Chevrolet 2012 Malibu Manual de usuario

Cadillac

Cadillac 2010 Escalade Manual de usuario
