Reliable 500VB Manual de usuario
PROFESSIONAL IRONING TABLES
LES PLANCHES À REPASSER
DE PLANCHADO PROFESIONALES
INSTRUCTION MANUAL
GUIDE D’UTILISATION
MANUAL DE INSTRUCCIONES
500VB/550VB
ENGLISH 01
FRANÇAIS 10
ESPAÑOL 19
01
THE 500VB & 550VB
PROFESSIONAL IRONING TABLES
INSTRUCTION MANUAL
ENGLISH
02
RELIABLE. RIGHT THERE WITH YOU.
At Reliable, we do what we love, and take pride in doing it right.
You want what’s best for the people, places and things that matter
in your life – from where you live to what you wear. So do we. From
the start, we approach every product with a craftsman’s attention
to detail and passion for making it right. Quality, functionality,
design and customer service play an equally important part in
delivering what’s right for you. With its powerful vacuum and up-air
(500VB only) features, they will allow you to obtain the benefits of
professional pressing in a compact and convenient format.
For your safety and to fully enjoy the advantages of this product,
please take a few minutes to read all of the important safeguards
and care instructions. Keep this manual handy and review the
product warranty for your reference.
03
HOW TO ASSEMBLE AND USE
READ ALL INSTRUCTIONS BEFORE USE
1. Unfolding: Hold the ironing board in a vertical position with the tip downwards;
press the handle (5) placed underneath the board and lift up the working sur-
face by pulling with the foot outwards until the desired height is reached.
2. Unfold the boiler support (3) and place the steam generator on the shelf.
3. Insert the electrical plug into an electrical outlet.
4. Place the pedal (1) near the working area.
5. Push the on/off switch (2) on the “I” position.
6. For the 500VB model, the “I” position is for vacuum, “O” is neutral, and “II” is
for the up-air (blowing) function.
7. Wait for a few minutes until the working surface is warmed up.
8. Start ironing.
9. To activate the vacuum or up-air function, simply press on the foot pedal (1).
10. You can use the vacuum or the blowing function at the same time as you are
ironing, or you can use it after the ironing (for very light fabrics this may be
the preferred way).
11. At the end of the ironing we suggest you leave the on/off switch (2) on for a
few minutes to ensure the inside of the table is dry and free of condensation.
12. Folding: turn the on/off switch (2) off, remove the plug from the outlet. Take
the boiler and the iron off of the boiler support (3), fold the boiler support (3),
and make sure there is no garment on the working surface and/or on the catch
tray (4).
13. As soon as the working surface is cool, position the ironing board vertically
with the tip downwards, press the handle (5) placed under the working surface
and at the same time pull the legs (6) inward.
FOR HOUSEHOLD AND LIGHT COMMERCIAL USE ONLY. SAVE THESE INSTRUCTIONS
IN A SAFE PLACE FOR FUTURE REFERENCE.
ATTENTION
IMPORTANT: When you want to dispose of the appliance, NEVER throw it in the gar-
bage. Instead, go to your closest recycling station or waste collection centre
for treatment.
04
FEATURES
• Powerful vacuum (550VB) and vacuum / up-air (500VB model)
• Sturdy tube frame construction
• Built-in heating element
• Large pressing surface
• Useable from either side of table
• Folds up quickly for easy storage and transportation
MAINTENANCE
We suggest checking the ironing board cover (7) periodically and, if it is necessary,
replacing it with an original one (part #500VBCR).
TECHNICAL DATA
Voltage: 120V 60 Hz
Working power: 650 W
Power of heating element: 600
Working surface: cm 125
WARRANTY CONDITIONS
Reliable Corporation accepts no liability for faults in your iron in the event of non-
compliance with the specifications of the warranty conditions or failure to follow
the operating or maintenance directions included in instruction book.
The warranty card may be found separately.
We remind you that the damage caused by the effects of scale is not covered by
the warranty.
05
DESCRIPTION OF THE 500VB
1. Pedal
2. On/off switch
3. Boiler support
4. Catch tray
5. Handle
6. Legs
7. Working surface cover
8. Motor
9. Blowing/vacuum switch
06
500VB
PARTS DRAWING 500VB
07
DESCRIPTION OF THE 550VB
1. Pedal
2. On/off switch
3. Boiler support
4. Catch tray
5. Handle
6. Legs
7. Working surface cover
8. Motor
