quick start guide

English

Français

Deutsch

Español

Rega Research. Made in England

English

Please follow this quick set up guide to ensure

optimum performance and perfect operation.

Failure to do so may invalidate your warranty.

For more information on this product

please visit www.rega.co.uk

Thank you for purchasing this

Rega product.

8

3

5

2

674Platter

2Drive belt & pulley

3Tonearm

5Plinth

6Power input

7Phono output

8On/Off switch

(underneath plinth)

4Balance weight

Unpacking the Planar 2

Always keep the turntable flat.

Follow the packing guide printed inside the front of the

box.

Save the packaging in case you need to transport your

turntable in the future.

Ensure the drive belt is in place and remove the

transport hub card from beneath the sub platter.

Carefully place the glass platter on the hub and fit the

turntable mat.

Place the turntable on a rigid level surface.*

2

*The Rega

turntable wall

bracket is the

ideal solution.

Cartridge alignment protractor

The Planar 2 comes with the Rega Carbon cartridge

aligned ready for play. If you need to replace or upgrade

the cartridge please use the cartridge alignment

protractor provided along with the cartridge

manufacturers guidelines.**

Manual speed change

You can change playing speed by simply removing the

glass platter and moving the drive belt between either the

33 ⅓rpm or 45rpm wheels of the drive pulley as shown.

Any questions or doubts, please contact your nearest official Rega dealer.

The tonearm external phono leads must be connected to

a suitable phono stage.

Connect as follows: Red=right channel. Black=left channel.

If your amplifier does not have an integrated phono stage

you will require an external stage.*

Connection to the amplifier

To set up the RB220 tonearm, screw on the balance

weight (A) along its shaft (B) until the stylus is floating

1mm clear of a record on the platter. Tracking force can

now be applied, half a turn of the weight (180 degrees) = 1

gram of force. Turn the weight to the suggested force of

your cartridge manufacturer’s guidelines. The suggested

force for the supplied Carbon cartridge is 2 grams (360

degrees). Use the plastic plugs on the weight as a guide.

Bias adjustment is automatic on the RB220 tonearm.

Setting up the RB220 tonearm

*Rega

Phono stages

are sold

separately.

**Upgrade

with the Rega

performance

pack.

3
