Reflecta x4-scan Manual de usuario
-0-
EN
Table of Contents
1. Precaution.................................................................2
2. Preparation................................................................5
zStandard Accessories.....................................5
zPart Names.....................................................6
zInstalling the Battery Pack..............................8
zCharging the Battery Pack………………........9
3. Place Film/ Slide Into The Holder............................11
4. Using the reflecta x4-Scan......................................12
5. Playback Mode........................................................18
6. Delete Mode............................................................19
7. To Link the Card to Computer..................................21
8. Edit the Pictures.......................................................24
9. Appendix………………………..……………...………31
zSpecifications................................................31
zIcon & Indicators...........................................32
zSystem Requirements...................................33
-1-
-2-
Welcome
Thank you for purchasing a reflecta x4-Scan.
Please take a moment to read through this manual. Its
contents will send you on an educational journey into your
recorder multiple capabilities.
1. Precaution
Before using reflecta x4-Scan, please ensure that you
read and understand the safety precautions described
below. Always ensure that the reflecta x4-Scan is
operated correctly.
•Never operate reflecta x4-Scan inside of an aircraft
or anywhere else where operation of such devices is
restricted. Improper use creates the risk of serious
accident.
•Do not try to open the case of reflecta x4-Scan or
attempt to modify reflecta x4-Scan in any way.
High-voltage internal components create the risk of
electric shock when exposed. Maintenance and
repairs should be performed only by authorized
service providers.
•Keep reflecta x4-Scan away from water and other
liquids. Do not use reflecta x4-Scan with wet hands.
Never use reflecta x4-Scan in the rain or snow.
Moisture creates the danger of fire and electric
shock.
•Keep reflecta x4-Scan and its accessories out of the
reach of children and animals to prevent accidents
or damage to the reflecta x4-Scan.
If you notice smoke or a strange odor coming from
reflecta x4-Scan, turn the power off immediately. Take
reflecta x4-Scan to the nearest authorized service
center for repair. Never attempt to repair reflecta
x4-Scan on your own.
EN
•Use only the recommended power accessories. Use
of power sources not expressly recommended for
reflecta x4-Scan may lead to overheating, distortion
of the equipment, fire, electrical shock or other
hazards.
•reflecta x4-Scan may become slightly warm during
use. This does not indicate malfunction.
•If the exterior of reflecta x4-Scan needs cleaning,
wipe it with a soft, dry cloth.
-3-
-4-
FCC Notice
This equipment has been tested and found to comply with
the limits for a Class B Digitize device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy. If not installed
and used in accordance with the instruction, it may cause
harmful interference to radio communication. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment on the off,
the user is encouraged to try to correct the interference by
one or more the following suggestion.
zReorient or relocate the receiving antenna.
zIncrease the distance between the equipment and
the receiver.
zConnect the equipment to a different power outlet
other than the one where the receiver is connected.
zConsult an experienced television or radio
technician for help.
CAUTION
To comply with the limits for a Class B Digitize device,
pursuant to Part 15 of the FCC Rules, this device must
only be installed on computer equipment certified to
comply with the Class B limits.
-5-
2. Preparation
EN
Standard Accessories
reflectax4-Scan QOG CD
Slide Holder Negative Holder
Clean brush USB cable
Adaptor Lithium Battery
(Optional)
Part Names
-6-
-7-
EN
Note: We suggest using bundled brush to insert into the reflecta
x4-Scan slot and clean the glass surface periodically to produce
a clear image. Please make sure your film negatives/ mounted
slides and cover trays are clean before inserting into the reflecta
x4-Scan as well. Dust or dirt from the negatives and cover trays
will affect the quality of your scanned images.
Installing the Battery Pack
1. Open the battery compartment cover by lightly
pressing and sliding it back as shown.
2. Insert the supplied battery. Make sure the battery
label is facing upwards and the (+ and -) ends of the
battery match to the polarities indicated in the battery
compartment.
3. Snap the cover back into place.
Battery power status
-8-
Charging the Battery Pack
EN
The battery pack is not charged at the time of purchase
and therefore needs to be charged before use. If the
battery charge becomes low while you are using the
copier, it is recommended to recharge it as soon as
possible.
1. Insert the battery pack into the battery compartment
(see page 8)
2. You may charge the battery in 2 ways:
(a) Plug the USB mini B of the supplied USB cable to
the USB port of the copier, and plug the other USB
end into the USB port of your computer/notebook.
Please charge the battery at least 5.5~6 hours
prior to your first use.
-9-
