Red-D-Arc PS-5 Manual
- 1 -
RED-D-ARC
OPERATION & MAINTENANCE MANUAL
Support Roller PS-5
Capacity: 5000 KG
- 2 -
We hereby declare that the following product:
Description : SUPPORT ROLLER
Model : PS-5 (5000kg Capacity)
Serial No. : RDA WS 202109001/02/03/04/05/06
Satisfy the following Specific regulation:
2006/42/EC – Machinery Directive and its amendments
2006/95/EC – Low Voltage Directive and its amendments
2004/108/EC – EMC Directive and its amendments
- 3 -
WARNING
This machine can be injurious to yourself and others. Take precautions when
welding. Ask for your employer ’s safety practices which should be based on
manufacturer’s hazard data.
READ AND UNDERSTAND THE INSTRUCTION & SERVICE MANUAL
BEFORE INSTALLINGAND OPERATING.
PROTECT YOURSELF AND OTHERS!
ELECTRIC SHOCK can kill.
Install and earth the welding unit in accordance with applicable standards.
Do not touch live electrical parts or electrodes with bare skin, wet gloves
or wet clothing.
FUMES AND GASES can be dangerous to health.
Keep your head out of the fumes.
Use ventilation, extraction at the arc, or both, to keep fumes and gases
from your breathing zone and the general area.
ARC RAYS can injure eyes and burn skin.
Protect your eyes and body. Use the correct welding screen and filter lens
and wear protective clothing.
Protect bystanders with suitable screens or curtains.
NOISE can damage hearing.
Protect your ears. Use earmuffs or other hearing protection.
Warn bystanders of the risk.
- 4 -
INSTRUCTION MANUAL
1. SAFETY FUNCTIONS
Users of handling equipment have ultimate responsibility for ensuring that anyone who works
with or near the equipment observes all the relevant safety precautions.
The following recommendations should be observed in addition to the standard regulations that
apply to the work place.
All work must be carried out by trained personnel who are familiar with the operation of the
support roller. Incorrect operation of the equipment may lead to a hazardous situation which can
result in injury to the operator and damage to the equipment.
Staying under the work piece during the working cycle is absolutely forbidden! Staying on top of
the work piece during the working cycle is forbidden without the safety equipment!
1. Anyone who uses the support roller must be familiar with
its operation
the location of brake
its function
relevant safety precautions
To make this easier each screw, roller wheel is marked with a symbol that indicates its function
when activated.
2. The work place must
be suitable for the purpose
be free from loose objects
be clean, because dust and welding flux can make the frictional force of the support roller.
3. Personal safety equipment
always wear recommended personal safety equipment, such as safety glasses, flame-proof
clothing, safety gloves
do not wear loose-fitting items, such as scarves, bracelets, rings etc., which could become
trapped or cause burn.
NOTE! THE FUNCTION IS PHASE SENSITIVE!
CONDUCT DAILY INSPECT ON DEVICE BEFORE START.
WARNING INSTRUCTION ON OPERATOR’S MANUAL TO REMIND OPERATOR DURING
OPERATION.
- 5 -
2. INTRODUCTION
2.1 General
support roller is a basic solution for support of the work pieces. They occupy little space and
feature quick and easy to operate.
All models meet or exceed the EN occupational safety requirements.
1. Turning wheels 3. Traveling wheels.
2. Lifting screw by manual
2.2 Specification
Model
PS-5
Max capacity
kg
5000 kg
Pipe diameter
mm
250-762 mm
Rotation speed
rpm
Idler
Rotation power
kw
Idler
Input voltage
V
/
1
3
2
- 6 -
3. INSTALLATION
IMPORTANT! READ ALL RELEVANT MANUALS AND SAFETY PRECAUTIONS CAREFULLY
BEFORE STARTING TO UNPACK AND INSTALL THE EQUIPMENT!
NOTE! MAKE SURE INSTALLATION IS CARRIED OUT BY SUITABLY TRAINED
PERSONNEL.
The support roller is shipped with fully assembled condition.
The location for installation should be level and able to take the required loading without
subsequent soil settlement.
Recommended lifting method by 2 lifting hooks via lifting lugs provided on both sides of the
support roller, use the 2 lifting lugs nearer to the table only.
Machine is ready for power “ON”.
Adjust the wheels position to meet the large diameter pipe.
3.1 Handling and Storage of the Machine
The machines are packed on a base, suitable for lifting by crane and/or forklift. Lift the
machine from the lifting points (lifting loops) only.
Unload the machine from the packing and check the outer condition. Do not store the
machine outside or in damp places.
- 7 -
4. STARTING-UP INSTRUCTIONS
4.1 Safety Consideration
This machine is to be operated by authorized and trained operator only.
Do not attempt to service the machine in the event of breakdown. Contact your
Service/Maintenance Department.
Do not wear loose clothing, as there are moving parts.
Safety practices on electrical hazards must be observed such as no wet hands, clothing and
properly insulated shoe.
Always keep a copy of the Manual in the Electrical Panel.
4.2 Daily Checks
Ensure that the work piece which was in the range of tank diameter.
Check that the traveling wheels is in good position.
Check that roller wheels free rotation are functioning.
Check the structure is working well and ensure the bolt no lose.
NOTE! PLUG FITS ONLY IN ONE POSITION.
DO NOT CONNECT THE WELDING RETURN CABLE THROUGH THE FRAME OF THE
ROLLER BED –THE BEARINGS AND THE CONTROL MAY BE DAMAGED.
