Record DFA 127 Guía de configuración
DFA 127 Basic quick set up
This Quick Guide is intended to be used in conjunction with a full installation
manual.
Once you have mechanically fitted your Swing unit follow this guide:
Fitting a pair? –Wire in the CAN Isolator before starting –(25 to 25, 26 to 26 etc..)
1. Using jumper J14 on the STG 127, one operator is set as Master and the other as
Slave. The operator of the active door leaf must always be selected as the Master
2. Select The rotation (Push or pull) on the Switch on the Control unit
A = PULL DIRECTION B = PUSH DIRECTION
3. Select English on the BDE
4. Press blue button for 6 flashes to select the spring type( the spring will go back and
forth –wait for it to stop) –On both operators if a pair
5. Press blue button for 4 flashes to enter programming mode - Master
6. Select configure system, then select Door type
7. Select either UK or UK LOW E depending on your risk assessment (on door safety or
not.
8. Put arm on with the door closed approx. 0 deg only finger tight
9. Press blue button for 3 flashes (–On both operators if a pair) and step back from the
door. The door should start to open slowly.
10.Stop the door-s at approx. 100 deg and the door will then close.
11.Select hold open on the BDED (top left)
12.Slacken the arm and close the door approx. 10 deg, tighten the arm finger tight. –
This Provides pre-tension on the springs.
13.Select manual operation on the BDED Top middle (snowflake) and the door will close.
14.Press the RECORD reset symbol until reset appears and then select reset. The door
will then evaluate the closed position and remember this as “Home”.
15.Tighten the arm (not overtight)
16.Press the blue button and the door should then open and close.
Now It Is time to set up Your Speeds & Basic Parameters
17.On the BDE Press then then
This will get you into the quick menu where you can adjust basic speeds
18.First Thing you will Notice is the Door open angle is not full.
Adjust the Open angle, open speed, close speed and Collision sensitivities according
to site conditions and BS 16005.
Fitting Activations
Wire your activation as per:
Test door in all operating Modes to confirm Activations
are working correctly
Fitting on Door Safety
1. If Fitting RC SWING Fast Install Sensors –PLUG & PLAY –See separate Quick Guide.
2. If Fitting others –Please refer to Diagram below :
If you are using Standard sensors –you need to turn the Test contacts on. (Aux Input –See
manual)
RECORD DFA 127 ABREVIATIONS
ABS - PULSE GENERATOR
AKA - EXTERNAL ACTIVATION
AKG - ACTIVATION COMMON CONTACT
AKI - INTERNAL ACTIVATION
AS - MASTER CIRCUIT
ASK - TERMINALS INSIDE THE HEADER
ATE - DRIVE UNIT
BDE-D - ELECTRONIC PROGRAMME SELECTOR
BDI - 3 POSITION ROCKER SWITCH
BDI-M –CIRCUIT BOARD FOR MECHANICAL PROGRAMME SELECTOR
BKL- PROCESSOR LED
CAN-H SERIAL DATA INTERFACE
CAN-L SERIAL DATA INTERFACE
CPU –MAIN MICRO PROCESSOR
DFA –AUTOMATIC SWING DOOR OPERATOR
EPROM - PROGRAMMABLE MEMORY CHIP
ES - CIRCUIT DIAGRAMME
FV - MANUFACTURING REGULATIONS
GTR - GEARING
HS - MAIN SWITCH 2 POLE
IKG - ENCODER
LED - LIGHT EMITTING DIODE
LD - LIGHT EMITTING DIODE
LS - CABLE PLAN
MF –MULTI FUNCTION SWITCH
MOT- MOTOR
MP - MAIN ASSEMBLY DIAGRAMME
NA - EMERGENCY STOP
NET - POWER SUPPLY UNIT
NS - MAIN POWER SWITCH
NSA - MAINS FAILURE
RAD - RADAR
SI - FUSE
SIO - OPENING FACE ON DOOR SAFETY –Written above Wiring Terminal
SIS - CLOSING FACE ON DOOR SAFETY –Written above Wiring Terminal
SSK - MORNING ENTRY KEY SWITCH
STG - CONTROL UNIT
STP - CONTROL UNIT PCB
TOE - DOOR LOCKING
TOW - DOOR OPENING WIDTH
TOZ - DOOR HOLD OPEN TIME
P - MICROPROCESSOR
VAK - LOCK CONTACT
VL - WIRING LIST
VMA - INSTRUCTIONS FOR WIRING AND ASSEMBLY
VVR –Electric Lock
Quick View of BDE Parameters
Guide to Blue Button – Multiple Use (MF)
No of Flashes
Level
1
Single Impulse –Opens Door
2
Tests the battery unit on STA16 & initialises the PHC for the first learn
3
Learns door parameters (Calibration Run)
4
Programming mode
5
tests the battery on STA 20
6
Spring Calibration run on the DFA 127 –Before connecting Arm
7
Not used
8
Factory standards reset
9
Full Reset -9 flash and then pull the emergency stop OUT then IN
14
Soft reset the same as the Record Logo
BDE – Control Switch
To both Lock and Unlock the Keypad operation:
Hold Open
Manual Operation
No Entry
2-Way Automatic
Locked / Closed
With this symbol
showing it represents
the key lock is ON
To reset the door:
Press and hold the Record logo for 10-13sec. The message “DFA127 Software Version “will flash up, followed by the
option to reset yes / No. Upon selecting Yes the doors will come to the closed position and reset. After 3sec
activate the doors to open so they may go through one learn cycle of open / close (moves slowly) and complete their
reset cycle.
BDI-M Set up
To Get the Door to lock on electric mags when the closed position is selected on the
Key switch you need to change the setting (In control panel Menu) to LOCK-A
Option 1 - MANUAL
Option 2 - LOCK-A
RED 24v Common
RED 24V Common
No Connection
AUTO
No Connection
LOCKED
Red / Green
MANUAL
Red / Green
AUTO
Red / Blue
HOLD
OPEN
Red / Blue
HOLD
OPEN
Terminal Connections on BDI-M
Red 3 - ......
AUTO
Red 3 - ......
LOCKED
Green 3 - 2
MANUAL
Green 3 - 2
AUTO
Blue 3 - 1
HOLD
OPEN
Blue 3 - 1
HOLD
OPEN
No
Reset Operator
Yes
For final exit of the building, place the program
selector into the locked function and when you are
ready to leave press the lock symbol once to give a
single open/close exit.
Once outside, stand clear of the sensors and after
the doors are closed, then set your manual locks.
Remember to unlock manual locks prior to using the
first entry key switch on the outside of the building.
ELECTRIC LOCK
