Recon MOD Live Manual de usuario
MOD User Guide Draft
Document Type / User Guide
Group / Marketing
Document ID / x
Author / David Lee
Version
#
Implemented
By
Revision
Date
Approved
By
Approval
Date
Reason
0.1 David Lee 2011/ /16 First draft
0.2 David Lee 2011/6/03 Updated with new MOD GUI
0.3 David Lee 2011/6/20 New graphics and functionality (tabs)
0.4 David Lee 2011/7/0 New product shots, changes based on
latest feedback
0. David Lee 2011/8/11 Close to final text. Graphics are not
updated in this version as Kirill will be
doing the graphics in InDesign next
0.6 Minh To 2011/8/26 Add standard regulatory page
0..7 David Lee 2011/8/31 Finishing the manual off for FCC
approval
0.8 Minh To 2011/09/7 Include the correct IC statement in the
Regulatory Compliance page.
Page of 39
Page 3 of 39
TABLE OF CONTENTS
1. MOD at a Glance ........................................................................................................................................................ 4
1.1 Accessories ................................................................................................................................................... 4
1.2 Remote .........................................................................................................................................................
1.3 Status Icons ..................................................................................................................................................
2. Getting Started ........................................................................................................................................................... 6
2.1 What You Need ............................................................................................................................................ 6
2.2 Installing MOD in your Recon Ready Goggle ................................................................................................ 6
2.3 Powering On and Off .................................................................................................................................... 8
2.4 Pairing with a new remote ........................................................................................................................... 9
2. Connecting to the Remote ........................................................................................................................... 9
2.6 Connection Lost: Remote Search Mode ..................................................................................................... 10
2.7 Connection Lost: Remote Power Save Mode ............................................................................................. 10
2.8 Installing ReconHQ Software ...................................................................................................................... 10
2.9 Connecting to PC/Mac................................................................................................................................ 11
2.10 Disconnecting from PC/Mac ....................................................................................................................... 12
3. The basics ................................................................................................................................................................. 13
3.1 Controlling MOD ........................................................................................................................................ 13
3.3 Charge Time ................................................................................................... Error! Bookmark not defined.
3.4 Battery Life ................................................................................................................................................. 14
3. Improving Battery Performance ................................................................................................................. 14
3.6 Pop-Ups ...................................................................................................................................................... 14
3.7 Display Off Mode ........................................................................................................................................ 1
3.8 Memory and Data Storage ......................................................................................................................... 16
3.9 Replacing the Remote Battery ................................................................................................................... 16
4. The Real-time Dashboard ......................................................................................................................................... 17
4.1 Speedometer .............................................................................................................................................. 17
4.2 Chrono/Stopwatch ..................................................................................................................................... 17
4.3 Configurable Feature .................................................................................................................................. 18
. Stats History ............................................................................................................................................................. 19
6. Jump ......................................................................................................................................................................... 22
7. Chrono/Stopwatch Feature ...................................................................................................................................... 23
8. Preferences .............................................................................................................................................................. 2
8.1 Setting the Brightness ................................................................................................................................ 2
8.2 Resetting Stats ............................................................................................................................................ 27
8.3 Setting the Language .................................................................................................................................. 27
8.4 Setting the Units of Measurement ............................................................................................................. 26
8. Setting the Time ......................................................................................................................................... 2
9. Graphical User Interface Overview Map .................................................................................................................. 28
10. Tips and Troubleshooting ......................................................................................................................................... 29
11. Safety, Storage, and Cleaning ................................................................................................................................... 31
11.1 Important Safety Information .................................................................................................................... 32
Comments from Michael ...................................................................................................... Error! Bookmark not defined.
12. Support, Service, and More Information ................................................................................................................. 32
12.1 Firmware Upgrade Information ................................................................................................................. 32
13. Warranty Information .............................................................................................................................................. 33
14. Regulatory Compliance .......................................................................................................................................... 374
1 . Technical Specifications ......................................................................................................................................... 38
Page 4 of 39
. MOD at a Glance
A. Micro-Optics Display
.1 Accessories
B. Recon Ready Remote
C. Goggle mount strap for Remote
D. Wrist/Backpack/Belt Strap for Remote
E. Both NEMA and EU connect AC Adapters
F. Micro USB to USB cable, 1 meter
Page 5 of 39
. Remote
.3 Status Icons
MOD is searching for satellites for a GPS signal
MOD is searching for more satellites for a better GPS signal
MOD has a moderate to strong GPS signal
MOD has full or near-full battery power
MOD has partial battery power
MOD has low-to-no battery power, plug in to computer or AC adapter to
recharge
Wireless remote is connected
flashing
Wireless remote connection lost. Searching for remote.
solid
Wireless remote connection lost. MOD has stopped searching for the remote in
order to save power.
Page 6 of 39
3. Getting Started
3.1 What You Need
MOD can be used after charging right out of the package, but to enjoy the full MOD experience you’ll need the following:
•Recon Ready Goggle http://www.ReconReady.com
•A PC or Mac with a USB port and one of the following operating systems:
oWindows PC: Intel Pentium 4 or higher, Windows XP, Vista, 7 or higher
oMac: Intel Core Duo or higher, Mac OS X v10.6 or later
•Recon Instruments HQ Software, available at www.reconinstruments.com/support
•An Internet Connection
3. Installing MOD in your Recon Ready Goggle
MOD is compatible with all Recon Ready products. For a list of Recon Ready products visit http://www.ReconReady.com
1) Remove lens from the Recon-Ready goggle frame (see Recon Ready goggle’s manual for instructions)
) Push protective badge into Recon-Ready goggles frame and remove
Page 7 of 39
3) From the front of the goggles insert and secure Micro Optics Display into the left side then insert and secure battery
into the right side.
4)If the cable is too long or too short, adjust the length so it fits snugly into the groove inside the top of the frame.
5) Replace lens back into the goggles (see Recon-Ready© goggles manual for instructions)
6) Remove temporary USB cover and fully charge battery with the USB charger until red light on the goggle turns off.
Page 8 of 39
7) Power on then pair MOD with remote by pressing any button on the remote.
3.3 Powering On and Off
To Power on, hold the POWER button for about 2 seconds. You will know the unit is on when the POWER button glows
blue.
To power off MOD hold the POWER button for about 2 seconds.
Page 9 of 39
3.4 Pairing with a new remote
Note: The remote and MOD and remote that come packaged together are already paired. To begin using the remote with
your MOD see section “3. Connecting to the Remote”.
To pair MOD with a new remote different than the one your MOD was packaged, with follow these instructions:
1. Press and hold the left and right buttons on the remote until you see the LED flash blue and orange. The remote is
now ready to be paired with a new device.
2. Power on MOD and press any button on the new remote within 10 seconds.
3. If the new remote is detected, the following screen will appear listing the remotes that are currently in range.
The remotes are listed by their MAC address. The MAC address of your remote is written on the back.
4. Use the power button to move the cursor to the remote you want to pair with. Then wait 10 seconds and the
remote will pair.
You will be taken to the dashboard, and the remote icon in the status bar will turn solid blue:
3.5 Connecting to the Remote
Whenever you power on MOD, it will begin searching for a wireless remote. On start-up you will see this screen
Page 10 of 39
Press any button on the remote to connect it to MOD. When the remote is connected you will see the remote icon in the
status bar turn solid blue:
3.6 Connection Lost: Remote Search Mode
If the remote connection is lost, MOD will begin searching for the remote. This is indicated by the remote icon flashing red:
Press any button on the remote to reconnect it.
3.7 Connection Lost: Remote Power Save Mode
If you do not reconnect the remote within 4 minutes, MOD will stop searching for the remote in order to save power. This is
indicated by the remote icon in the status bar turning solid red: .
To begin searching again press but do not hold the power button. MOD will return to Remote Search Mode for 4 minutes.
Press any button on the remote to reconnect it.
For more detailed information on controlling MOD using the remote see ‘Controlling MOD’ (p___)
3.8 Installing ReconHQ Software
Recon HQ is a free application for your PC or Mac that allows you to view and organize your achievements and statistics
from the mountain or backcountry on your computer. Collect real-time information from your Recon Instruments hardware
to track your trips or entire seasons. Playback those amazing runs or secret trails in real-time with all of your statistics
overlaid on Google maps. Cut highlights of your favourite moments, post to HQ Online and share with Facebook, Twitter
and more.
To download ReconHQ go to http://reconinstruments.com/download-latest-recon-hq-software
System Requirements
