RCA YBXR1060 Manual de usuario
YBXR1060
Part No. 175D1807P231
Pub. No. 79-9960
Washers
Owner’s Manual
2
Welcome to the RCA family. We’re proud of our quality products and
we are committed to providing dependable service. You’ll see it in this
easy-to-use manual and you’ll hear it in the friendly voices of our
customer service department.
Best of all, you’ll experience
these values each time you do
the laundry. That’s important,
because your new washer will be
part of your family for many years.
And we hope you will be part of
ours for a long time to come.
We thank you for buying RCA. We appreciate your purchase, and hope
you will continue to rely on us whenever you need quality appliances for
your home.
Important!
Staple sales slip or cancelled
check here.
Proof of the original purchase date is needed
to obtain service under the warranty.
Write the model and serial numbers here.
#
#
You can find them in the upper right corner
on the back of your washer.
Congratulations!
You Are Now Part Of The
RCA Family.
RCA & You,
A Service Partnership.
Inside you will find many
helpful hints on how to use and
maintain your washer properly.
Just a little preventive care on
your part can save you a great
deal of time and money over
the life of your washer.
Read this Manual
Ask any RCA appliance owner and they will
tell you we stand behind our products with
unmatched quality service. However, did
you know that most questions result from
simple problems that you can easily
fix yourself in just a few minutes? This
Owner’s Manual can tell you how.
You’ll find many answers to
common problems here.
If you review our chart of
Troubleshooting Tips first,
you may not need to call for
service at all.
Review the Section on
Troubleshooting Tips
If you do need service, you can
relax knowing help is only a
phone call away. A list of toll-free
customer service numbers is
included in the back section.
If You Need Service
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
Safety Information . . . . . .4–7
Operating Instructions
Control Panel . . . . . . . . . . . . . .8
Control Settings . . . . . . . . . . . .8
Washer Features . . . . . . . .9, 10
Loading and Using
the Washer . . . . . . . . . . . .11, 12
Troubleshooting Tips
Before You
Call For Service . . . . . . . . .13–17
Customer Service
Warranty . . . . . . . . . . . . . . . .19
Service Telephone
Numbers . . . . . . . . . .Back Cover
3
Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service
IMPORTANT SAFETY INFORMATION.
READ ALL INSTRUCTIONS BEFORE USING.
4
For your safety, the information in this manual must be
followed to minimize the risk of fire or explosion, electric
shock, or to prevent property damage, personal injury, or
loss of life.
Under certain conditions hydrogen gas may be produced
in a water heater that has not been used for two weeks
or more. Hydrogen gas can be explosive under these
circumstances.
If the hot water has not been used for two weeks or more, prevent
the possibility of damage or injury by turning on all hot water
faucets and allowing them to run for several minutes. Do this
before using any electrical appliance which is connected to the
hot water system. This simple procedure will allow any built-up
hydrogen gas to escape. Since the gas is flammable, do not smoke
or use an open flame or appliance during this process.
WATER HEATER SAFETY
WARNING!
5
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
This washer must be properly installed and located in
accordance with the Installation Instructions before it is
used. If you did not receive an Installation Instructions
sheet, you can receive one by calling us toll-free at the
GE Answer Center
®
, 800.626.2000.
PROPER INSTALLATION
■
Install or store where it will not
be exposed to temperatures
below freezing or exposed to
the weather.
■Properly ground washer to
conform with all governing
codes and ordinances. Follow
details in Installation
Instructions.
■Keep the area underneath
and around your appliances
free of combustible materials
such as lint, paper, rags,
chemicals, etc.
■Close supervision is necessary
if this appliance is used by or
near children. Do not allow
children to play on, with, or
inside this or any other
appliance.
YOUR LAUNDRY AREA
Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service
IMPORTANT SAFETY INSTRUCTIONS.
READ ALL INFORMATION BEFORE USING.
6
Use this appliance only for its intended purpose as
described in this Owner’s Manual.
■ Never reach into washer while
it is moving. Wait until the
machine has completely
stopped before opening
the lid.
■Do not mix chlorine bleach
with ammonia or acids such
as vinegar and/or rust
remover. Mixing different
chemicals can produce a toxic
gas which may cause death.
■ Do not wash or dry articles
that have been cleaned in,
washed in, soaked in, or
spotted with combustible or
explosive substances (such as
wax, oil, paint, gasoline,
degreasers, dry-cleaning
solvents, kerosene, etc.)
which may ignite or explode.
Do not add these substances
to the wash water. Do not use
or place these substances
around your washer or dryer
during operation.
■ The laundry process can
reduce the flame retardancy
of fabrics. To avoid such a
result, carefully follow the
garment manufacturer’s
wash and care instructions.
■ To minimize the possibility
of electric shock, unplug this
appliance from the power
supply or disconnect the
washer at the household
distribution panel by
removing the fuse or
switching off the circuit
breaker before attempting
any maintenance or cleaning.
NOTE:
Turning the Cycle
Selector knob to an off
position does
NOT
disconnect
the appliance from the
power supply.
■ Never attempt to operate this
appliance if it is damaged,
malfunctioning, partially
disassembled, or has missing
or broken parts, including a
damaged cord or plug.
WHEN USING THE WASHER
WARNING!
7
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
■ Turn off water faucets to
relieve pressure on hoses and
valves and to minimize
leakage if a break or rupture
should occur. Check the
condition of the fill hoses;
they may need replacement
after 5 years.
■ Before discarding a washer,
or removing it from service,
remove the washer lid to
prevent children from
hiding inside.
■ Do not attempt to repair or
replace any part of this
appliance unless specifically
recommended in this
Owner’s Manual, or in
published user-repair
instructions that you
understand and have the skills
to carry out.
■ Do not tamper with controls.
WHEN NOT IN USE
REMEMBER…
Your continued health and safety are important to us.
Please read and follow this Safety Information carefully.
We want you to remain a happy and healthy part of
our family.
SAVE THESE INSTRUCTIONS
Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service
About the washer control panel.
You can locate your model number behind the top edge of the control panel.
8
OFF
PERMANENT PRESS
LOAD SIZE TEMPERATURE
EXTRA
SMALL
EXTRA
LARGE
WASH
RINSE
COLD
COLD
WARM
COLD
MEDIUM
HOT
COLD
KNITS
DELICATES
NORMAL
HEAVY
LIGHT SOIL
OFF
PERMANENT
PRESS
COTTONS
REGULAR
1 2 3
Control Settings
Load Size
The water level should just cover the clothes. Adjust the
load size accordingly. Loosely load clothes no higher than
the top row of holes in the washer tub.
Wash/Rinse Temp
Select the water temperature for the wash and rinse
cycles. Always follow fabric manufacturer’s care label
or instructions when laundering. Follow the water
temperature guide on washer lid.
Wash Cycle
The wash cycle controls the length of the washing process.
The chart below will help you match the wash cycle setting
with your clothing.
COTTONS REGULAR For heavy to lightly soiled cottons, household linens,
work and play clothes.
PERMANENT PRESS For easy care and wrinkle-resistant items.
KNITS Specially designed for normally soiled knits.
DELICATES For lingerie and delicate fabrics with
light to normal soil.
1
2
3
About the washer features.
Customer ServiceTroubleshooting TipsOperating InstructionsSafety Information
9
Do not pour anything into the agitator
if the top is removed.
Agitator Cap or Fabric Softener Dispenser
(depending on model)
The agitator cap
fits into the top of the agitator.
If it accidentally comes off, simply put it back on.
The fabric softener dispenser
automatically releases liquid
fabric softener at the proper time during the cycle.
To use, follow these steps:
Make sure dispenser is securely attached to agitator.
Use only liquid fabric softener. Pour into dispenser,
using amount recommended on package.
Add water to dispenser until it reaches the
maximum fill line.
Do not stop the washer during the first spin. This will cause the
dispenser to empty too soon.
Never pour fabric softener directly on clothes. It may stain them.
3
2
1
Safety InformationOperating InstructionsTroubleshooting TipsCustomer Service
About the washer features.
10
Separate for cleaning.
Cleaning the Fabric Softener Dispenser
Remove the dispenser from the top of the agitator.
Separate the dispenser cup from the cover by
grasping the top and pushing down on the inside of
the cup with your fingers. Dispenser cup will pop
free from the cover.
To clean dispenser, soak both the dispenser cup and
the dispenser cover in the following solution:
■
1 US gallon (3.8 liters) warm water
■
1/4 cup (60 ml) heavy duty liquid detergent
■
1 cup (240 ml) bleach
If necessary, loosen build-up with a clean, soft cloth
after soaking. Do not use a stiff brush; you may
roughen the surface of the dispenser.
Rinse and reassemble dispenser. Place dispenser
back on the agitator.
5
4
3
2
1
