Owner’s Manual Cat. No. 20-520

PRO-90 300-Channel

TrunkTracker Scanner

Please read before using this equipment.

20-520.fm Page 1 Wednesday, August 4, 1999 3:06 PM

FEATURES

Your new RadioShack PRO-90 300-Channel Trunk-

Tracker Scanner is the first of a new generation of scan-

ners designed to track MotorolaType I and Type II

(such as Smartnet, and Privacy Plus) and hybrid an-

alog trunking systems, which are extensively used in

many 800 MHz communication systems.

Trunking communications systems let a large group of 2-

way radio users (or even different groups of 2-way radio

users) efficientlyuse a large range offrequencies. Instead

of selecting a specific frequency for a transmission, the 2-

way radio user simply selects a talk group. The trunking

system automatically transmits the call on the first avail-

able frequency, and also sends a code that uniquely iden-

tifies that 2-way radio user’s transmission on a different

frequency called a data channel.

Since the trunking system might send individual 2-way ra-

dio user’s calls and response transmissions on different

frequencies, it is difficult to listen to trunked communica-

tions using a regular scanner. The PRO-90 lets you select

and monitor the data channel frequency sent with a 2-way

radio user’s transmission, so you can hear the call and re-

sponse for that 2-way radio user and easily “follow” the

conversation.

The scanner also lets you scan conventional transmis-

sions, and is preprogrammed with service-search banks

for convenience. By pressing a single button, you can

quickly search those frequencies most commonly used

by public service and other agencies without tedious and

complicated programming.

This scanner gives you direct access to over 31,000 excit-

ing frequencies, including police and fire departments,

ambulance services, and amateur radio services, and you

can change your selection at any time.

Your scanner also has these special features:

Triple-Conversion Circuitry — virtually eliminates any

interference from IF (intermediate frequency) images, so

you hear only the selected frequency.

RadioShack is a registered trademark used by Tandy Corporation.

HyperSearch and HyperScan are trademarks used by

Tandy Corporation.

Motorola, Smartnet, and Privacy Plus are trademarks of

Motorola, Inc.

20-520.fm Page 2 Wednesday, August 4, 1999 3:06 PM

Ten Channel-Storage Banks — let you store 30 chan-

nels in each bank to group channels so you can more

easily identify calls.

Five Scan Lists — let you store up to 50 IDs in each

tracking bank (up to a total of 500).

Two-Second Scan Delay — delays scanning for about

2 seconds before moving to another channel, so you can

hear more replies that are made on the same channel.

Lock-Out Function — lets you set your scanner to skip

over specified channels or frequencies when scanning

or searching, and skip over IDs when tracking trunked

systems.

Priority Channels — lets you program one channel in

each bank (10 in all) and then have the scanner check it

every 2 seconds so you don't miss transmissions on

those channels.

Five Service-Search Banks — lets you search preset

frequencies in separate police, fire/emergency, aircraft,

marine, and weather banks, to make it easy to locate

specific types of calls.

HyperSearch and HyperScan — lets you set the

scanner to search at up to 300 steps per second and

scan at up to 100 frequencies per second in frequency

bands with 5 kHz steps, to help you quickly find interest-

ing broadcasts. The normal search speed is 100 steps

per second.

Data Signal Skip — lets you set the scanner to skip

non-modulated or data signals during searches. This lets

the scanner avoid non-voice signals, making a search

faster.

Key Lock — lets you lock the scanner's keys to help

prevent accidental changes to the scanner's program-

ming.

Manual Access — lets you directly access any channel.

Liquid-Crystal Display — makes it easy to view and

change programming information.

Display Backlight — makes the scanner easy to read in

low-light situations.

20-520.fm Page 3 Wednesday, August 4, 1999 3:06 PM

Flexible Antenna with BNC Connector — provides ex-

cellent reception and is designed to help prevent anten-

na breakage. Or, you can connect an external antenna.

Memory Backup — keeps the frequencies stored in

memory for an extended time.

Three Power Options — let you power the scanner us-

ing the built-in rechargeable battery pack, external AC

power using the supplied AC adapter/charger, or DC

power using an optional DC cigarette-lighter power ca-

ble.

Key Confirmation Tones — the scanner sounds a tone

when you perform an operation correctly, and an error

tone if you make an error.

Battery Low Alert — warns you when battery power

gets low.

Battery Save — saves battery power when the scanner

does not detect any transmissions for more than 1

minute when a channel is manually selected.

Your scanner can receive these bands:

Frequency Range Step Transmission

29–29.7 MHz 5 kHz 10-Meter Ham

Band

29.7–50 MHz 5 kHz VHF Lo

50–54 MHz 5 kHz 6-Meter Ham Band

108–136.9875 MHz 12.5 kHz Aircraft

137–144 MHz 5 kHz Military Land

Mobile

144–148 MHz 5 kHz 2-Meter Ham Band

148–174 MHz 5 kHz VHF Hi

406–420 MHz 12.5 kHz Federal Govern-

ment

420–450 MHz 12.5 kHz 70-cm Ham Band

450–470 MHz 12.5 kHz UHF Standard

Band

470–512 MHz 12.5 kHz UHF “T” Band

806–956 MHz 12.5 kHz Public Service

“800” Band, except

cellular band

20-520.fm Page 4 Wednesday, August 4, 1999 3:06 PM

We recommend you record your scanner’s serial num-

ber here. The number is on the bottom panel.

Serial Number: ___________________________

FCC NOTICE

Your scanner might cause radio or TV interference even

when it is operating properly. To determine whether your

scanner is causing the interference, turn off your scanner.

If the interference goes away, your scanner is causing it.

Try the following methods to eliminate the interference:

• Move your scanner away from the receiver

• Connect your scanner to an outlet that is on a differ-

ent electrical circuit from the receiver

• Contact your local RadioShack store for help

Note: Mobile use of this scanner is unlawful or requires

a permit in some areas. Check the laws in your area.

SCANNING LEGALLY

Your scanner covers frequencies used by many different

groups including police and fire departments, ambulance

services, government agencies, private companies, am-

ateur radio services, military operations, pager services,

and wireline (telephone and telegraph) serviceproviders.

It islegal to listen to almost every transmission yourscan-

ner can receive. However, there are some transmissions

you should never intentionally listen to. These include:

• Telephone conversations (either cellular, cordless,

or other private means of telephone signal transmis-

sion)

• Pager transmissions

• Any scrambled or encrypted transmissions

According to the Electronic Communications Privacy Act

(ECPA), you are subject to fines and possible imprison-

ment for intentionally listening to, using, or divulging the

contents of such a transmission unless you have the

consent of a party to the conversation (unless such ac-

tivity is otherwise illegal). We encourage responsible, le-

gal scanner use.

20-520.fm Page 5 Wednesday, August 4, 1999 3:06 PM

CONTENTS

Preparation ................................................................ 8

Power Sources ..................................................... 8

Using the Rechargeable Battery Pack .......... 8

Using Standard AC Power ............................ 9

Using Vehicle Battery Power ....................... 10

Connecting the Antenna ..................................... 11

Connecting an Optional Antenna ................ 12

Connecting an Earphone/Headphones .............. 13

Listening Safely .......................................... 13

Traffic Safety ............................................... 13

Connecting an Extension Speaker ..................... 14

Attaching the Belt Clip ........................................ 14

Understanding Your Scanner ................................. 15

A Look at the Keypad ......................................... 15

A Look at the Display ......................................... 17

Understanding Banks ......................................... 19

Channel Storage Banks .............................. 19

Service Banks ............................................. 19

Understanding Trunking ..................................... 19

Operation ................................................................. 20

Turning On the Scanner and Setting Squelch .... 20

Storing Known Frequencies into Channels ........ 21

Limit Search ....................................................... 22

Scanning Service Banks .................................... 23

Scanning the Stored Channels .......................... 25

Manually Selecting a Channel ............................ 25

Deleting a Stored Frequency ............................. 25

Special Features ...................................................... 26

Delay .................................................................. 26

Turning Channel-Storage Banks On and Off ..... 27

Locking Out Channels and Frequencies ............ 27

Locking Out Channels ................................ 27

Locking Out Frequencies ............................ 28

Priority ................................................................ 28

Using the Keylock .............................................. 30

Using the Display Backlight ................................ 30

Changing Search Speeds .................................. 30

Battery Save ...................................................... 31

Skipping Data Signals ........................................ 31

20-520.fm Page 6 Wednesday, August 4, 1999 3:06 PM

Trunk Tracking ......................................................... 32

Types of Trunked Systems ................................. 32

Setting the Scanner to the Trunk Tracking Mode 33

Setting Squelch for the Trunk Tracking Mode .... 34

Programming Trunked Frequencies ................... 34

Scanning a Trunked Bank .................................. 36

Monitoring an Active ID ............................... 37

Locking Out IDs ........................................... 38

Unlocking a Single ID .................................. 38

Unlocking All IDs ......................................... 38

Using Trunk Tracking Scan Delay ............... 39

Monitoring IDs ............................................. 39

Channel Activity Indicators ................................. 40

Scan Lists ........................................................... 41

Manually Storing IDs into Scan Lists ........... 41

Storing IDs Into Scan Lists

While Searching .......................................... 42

Automatically Storing an ID

in a Scan List Location ................................ 42

Deleting a Stored ID .................................... 43

Scanning the Scan Lists ..................................... 43

Scanning Type I and Hybrid Trunked Systems ...44

Selecting a Preset Fleet Map ..................... 48

Programming a Fleet Map .......................... 49

Programming a Hybrid System .................. 50

A General Guide to Scanning ................................. 51

Guide to Frequencies ......................................... 51

National Weather Frequencies .................... 51

Canadian Weather Frequencies .................. 51

Birdie Frequencies ...................................... 51

Guide to the Action Bands ................................. 52

Typical Band Usage .................................... 52

Primary Usage ............................................. 52

Band Allocation ................................................. 53

Frequency Conversion ...................................... 57

Troubleshooting ....................................................... 58

Care and Maintenance ............................................. 61

Specifications .......................................................... 62

20-520.fm Page 7 Wednesday, August 4, 1999 3:06 PM

PREPARATION

POWER SOURCES

You can power your scanner from any of three sources:

• Built-in rechargeable battery pack

• Standard AC power using the supplied AC adapter/

charger

• Vehicle battery power using an optional DC ciga-

rette-lighter power cable

Using the Rechargeable Battery Pack

You must charge your scanner’s built-in rechargeable

battery pack before you can use it to power the scanner.

Your scanner has a built-in charging circuit that lets you

charge the rechargeable battery pack while it is in the

scanner.

To charge the battery pack, simply connect the supplied

AC adapter/charger or an optional DC cigarette-lighter

power cable to the scanner’s EXT. PWR jack. See “Using

Standard AC Power” on Page 9 or “Using Vehicle Bat-

tery Power” on Page 10.

It takes about 14–16 hours to recharge a battery pack

that is fully discharged. (You can operate the scanner

while recharging the battery pack, but charging takes

longer).

Notes:

• The scanner automatically stops charging the bat-

tery pack when it is fully charged, even if the sup-

plied AC adapter/charger or a DC cigarette-lighter

power cable is still connected to the scanner.

• A rechargeable battery pack lasts longer and deliv-

ers more power if you occasionally let it fully dis-

charge. To do this, simply use the scanner until the

low battery indicator appears. Then fully charge the

battery pack.

If the battery pack doesn’t power the scanner even after

you charge it, you must replace it. You can order a re-

placement battery pack from your local RadioShack

store.

20-520.fm Page 8 Wednesday, August 4, 1999 3:06 PM

1. Press down on the battery compartment cover and

slide the cover in the direction of the arrow to

remove it.

2. Disconnect the battery pack’s connector from the

scanner’s connector. Then remove the battery pack

from the battery compartment.

3. Attach the new battery pack's connector to the bat-

tery socket inside the battery compartment. Then

put the battery pack into the compartment.

4. Replace the cover.

When the scanner’s battery gets low, blinks and

the scanner beeps about every 15 seconds.

Important: At the end of a rechargeable battery pack's

useful life, it must be recycled or disposed of properly.

Contact your local, county, or state hazardous waste

management authorities for information on recycling or

disposal programs in your area. Some options that might

be available are: municipal curb-side collection, drop-off

boxes at retailers such as your local RadioShack store,

recycling collection centers, and mailback programs.

Using Standard AC Power

To power the scanner from AC power, use the supplied

AC adapter/charger. Plug the adapter/charger's barrel

plug into the scanner's EXT. PWR jack. Then plug the AC

adapter/charger's power module into a standard AC out-

let.

20-520.fm Page 9 Wednesday, August 4, 1999 3:06 PM

Warning: Do not use the AC adapter/charger's polarized

plug with an extension cord, receptacle, or other outlet

unless the blades can be fully inserted to prevent blade

exposure.

Caution: Use only the supplied AC adapter/charger. It is

specifically designed for this scanner.

Using Vehicle Battery Power

To power the scanner from your vehicle's cigarette-light-

er socket, you need a DC cigarette-lighter power cable,

such as Cat. No. 270-031.

Cautions:

• The DC cigarette-lighter power cable must be capa-

ble of delivering 12 volts, its center tip must be set to

positive, and its barrel plug must correctly fit the

scanner's EXT. PWR jack. The recommended power

cable meets these specifications. Using a power

cable that does not meet these specifications could

damage the scanner or the power cable.

• To protect your vehicle's electrical system, always

plug the power cable into the scanner before you

plug it into your vehicle's cigarette-lighter socket.

Always unplug the power cable from the vehicle's

cigarette-lighter socket before you unplug it from the

scanner.

• Insert the DC cigarette-lighter power cable's barrel

plug into the EXT. PWR jack, then plug the power

EXT. PWR Jack

cable's other end into your vehicle's cigarette-lighter

socket.

20-520.fm Page 10 Wednesday, August 4, 1999 3:06 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Escáner de Radio Shack

Radio Shack

Radio Shack PRO-2052 Manual de usuario

Radio Shack

Radio Shack PRO-162 Manual de usuario

Radio Shack

Radio Shack PRO-160 Manual de usuario

Radio Shack

Radio Shack 20-427 PRO-2054 Manual de usuario

Radio Shack

Radio Shack 20-405 Manual de usuario

Radio Shack

Radio Shack PRO-2056 Manual de usuario

Radio Shack

Radio Shack PRO-137 Manual de usuario

Radio Shack

Radio Shack PRO-89 Manual de usuario

Radio Shack

Radio Shack PRO-2039 Manual de usuario

Radio Shack

Radio Shack 25-3053 Manual de usuario

Radio Shack

Radio Shack Realistic PRO-34 Manual de usuario

Radio Shack

Radio Shack PRO-82 Manual de usuario

Radio Shack

Radio Shack Race Scanner Manual de usuario

Radio Shack

Radio Shack PRO-96 Manual de usuario

Radio Shack

Radio Shack PRO-2046 Manual de usuario

Radio Shack

Radio Shack Pro 2055 Manual de usuario

Radio Shack

Radio Shack Desktop Scanner Manual de usuario

Radio Shack

Radio Shack PRO-2051 Manual de usuario

Radio Shack

Radio Shack REALISTIC PRO-2042 Manual de usuario

Radio Shack

Radio Shack PRO-433 Manual de usuario

Radio Shack

Radio Shack RPO-137 Manual de usuario

Radio Shack

Radio Shack 25-3097 Manual de usuario

Radio Shack

Radio Shack PRO-197 Manual de usuario

Radio Shack

Radio Shack Pro-2032 Manual de usuario

Manuales populares de Escáner de otras marcas

Plustek

Plustek Scanner Manual de usuario

Z/I Imaging

Z/I Imaging PhotoScan 2001 Manual de usuario

Renkforce

Renkforce DS100-5M Manual de usuario

Image Access

Image Access WideTEK A2 Manual de usuario

Canon

Canon imageFORMULA CR-120N Manual de usuario

Fujitsu

Fujitsu FI-4860C2 Manual de usuario

GeoSlam

GeoSlam ZEB Horizon Instrucciones de instalación

Kodak

Kodak i5800 Scanner Manual de usuario

Kodak

Kodak i7300 Manual de usuario

Revopoint

Revopoint POP Manual de usuario

Fujitsu

Fujitsu fi-4860C Manual de usuario

Eddyfi Technologies

Eddyfi Technologies Floormap X Manual de usuario

Faselase

Faselase F6 Manual de usuario

Fujitsu

Fujitsu CardMinder Manual de usuario

Uniden

Uniden BC340CRS Manual de usuario

Infinite Peripherals

Infinite Peripherals INFINEA TAB M Manual de usuario

Mustek

Mustek PageExpress 4800 Pro Manual de usuario

Optex

Optex 750830 Manual de usuario
