Owner’s ManualFront/Rear Laser

X•K•Ka Superwide Radar Detector

with VG-2 Guard

Please read before using this equipment.

Cat. No. 22-1676

22-1676.fm Page 1 Friday, August 6, 1999 10:38 AM

FEATURES

Your RadioShack Front/Rear Laser X•K•Ka Superwide

Radar Detector receives all X-, K-, and Ka-band traffic

radar signals and also detects both the instant-on and

laser systems many police departments now use to

measure vehicle speed. Plus, it can alert you to road

hazards signaled by either a Safety Warning System or

Safety Alert Signal. When it detects a signal, your easy-

to-mount detector alerts you with a light and a tone,

which increase in speed as the signal gets stronger.

The detector’s built-in laser sensors detect traffic laser

signals coming from in front of and behind your vehicle.

Your detector also has FAST®(False Alert Suppression

Technology) circuitry that helps prevent false alarms

caused by signals from other radar detectors, without

reducing your detector’s sensitivity to traffic radar signals.

Your detector’s many useful features include:

VG-2 Protection — makes your detector invisible to

the VG-2 radar-detector detector when its senses VG-2

is being used.

1997 Tandy Corporation.

RadioShack is a registered trademark used by Tandy Corporation.

Safety Alert is a trademark of Cobra Electronics.

FAST is a registered trademark used by Tandy Corporation.

InstaClear is a registered trademark used by Ford Motor Company.

ElectriClear is a registered trademark used by Libbey, Owens, Ford,

and Delco-Remy.

22-1676.fm Page 2 Friday, August 6, 1999 10:38 AM

Safety Alert Signal Detection — warns you when the

detector detects signals broadcast by safety alert trans-

mitters. Some public safety and government agencies

install these transmitters in some emergency vehicles

and near some known road hazards and construction

areas, to provide advance warning of potentially haz-

ardous situations.

Safety Warning System — alerts you to the presence

of potential road hazards and emergency vehicles sig-

nalled by a safety radar transmission.

X-, K-, Ka-Band, and Laser Signal Detection —

warns you when the detector detects signals from traf-

fic radar or laser devices. Different tones sound and dif-

ferent indicators flash to let you know the type of signal

received.

City/Highway Modes — let you reduce the detector’s

sensitivity to weak X-, K-, and Ka-band signals, without

affecting the detector’s sensitivity to laser signals while

you are in the city.

Note: Some areas have laws regulating the use of

radar detectors. Check with your local law enforcement

agency about the laws in your area.

22-1676.fm Page 3 Friday, August 6, 1999 10:38 AM

We recommend you record your detector’s serial num-

ber here. The number is on the detector’s bottom

panel.

Serial Number:_______________________________

22-1676.fm Page 4 Friday, August 6, 1999 10:38 AM

Your detector includes the following items:

• Hook-and-loop tape

• Bracket holder

• Sun visor clip

• Windshield bracket and holder

• Power cord

• Power cord clips (6)

22-1676.fm Page 5 Friday, August 6, 1999 10:38 AM

CONTENTS

A Look at the Detector ............................................ 7

Safet

Alert and Safet

Warnin

stem ............ 10

Installation .............................................................. 11

Selecting a Mounting Location ...........................11

Hook-and-Loop Mounting .................................. 12

Visor Mounting .................................................. 13

Removing the Sun Visor Clip ...................... 15

Windshield Mounting ........................................ 16

Connecting Power ............................................ 17

Mounting the Power Cord Clips .................. 19

Operation ............................................................... 20

Turning the Detector On and Off ...................... 20

Adjusting the Volume ........................................ 20

Operating Settings ............................................ 21

Selecting the City and Highway Modes ....... 21

Muting the Audio Alert ................................. 22

Turning Off the Display ................................ 23

Receiving and Identifying Radar, Laser,

Safety Alert, Safety Warning System,

and VG-2 Signals ............................................. 23

Troubleshootin

.................................................... 25

Care and Maintenance .......................................... 28

Replacing the Fuse ........................................... 29

22-1676.fm Page 6 Friday, August 6, 1999 10:38 AM

A LOOK AT THE DETECTOR

Front Laser Detection Lenses — receive incoming

laser signals directed at the front of your vehicle.

DC 12V Jack — the power cord plugs in here.

DARK Button — turns off all your detector’s indicators,

except the P (Power) indicator.

22-1676.fm Page 7 Friday, August 6, 1999 10:38 AM

MUTE Button — silences the alert sound.

CITY

(

Cit

/Hi

hwa

Button — switches between the

city and highway modes.

nal Stren

th Indicator — two LEDs show an accu-

rate visual indication of the strength of the radar signals

received.

(

Stationar

Road Hazard Situation

)

Indicator —

blinks when the detector detects the signal related to a

stationary road hazard, either from the safety warning

system or from a safety alert transmitter.

(

Emer

enc

/Slow Movin

Vehicles

)

Indicator —

blinks when the detector detects the signal related to

emergency/slow moving vehicles, either from the

safety warning system or from a safety alert transmitter.

(

Rail Road

)

Indicator — both LEDs under S and M

blink at the same time when the detector detects the

signal related to a railroad, either from the safety warn-

ing system or from a safety alert transmitter.

C/SA

(

Cit

/Safet

Alert

)

Indicator — lights when the

detector is in the city mode and blinks when the detec-

tor detects a safety alert signal.

K/Ka

(

K- and Ka-Band Radar

)

Indicator — blinks when

the detector detects either a K- or Ka-band radar signal.

22-1676.fm Page 8 Friday, August 6, 1999 10:38 AM

X (X-Band Radar) Indicator — blinks when the detector

detects an X-band radar signal.

L (Laser) Indicator — both LEDs under X and K/Ka

light when the detector detects a traffic laser signal.

VG-2 Indicator — lights when a VG-2 signal is

detected.

P (Power) Indicator — lights when you connect the

detector to power and turn it on.

LASER (Rear Laser Detection Lens) — receives laser

signals directed at the rear of your vehicle.

VOLUME/OFF Control — turns the detector on and off

and lets you adjust the volume.

22-1676.fm Page 9 Friday, August 6, 1999 10:38 AM

SAFETY ALERT AND SAFETY

WARNING SYSTEM

These systems are low-powered transmitters used by

some emergency services and road crews to alert driv-

ers to hazardous conditions. The Safety Alert system

can indicate stationary, moving, or railroad hazards.

Radar detectors that are Safety Alert compatible, such

as this one, indicate the presence of a Safety Alert sig-

nal.

The Safety Warning System is like Safety Alert, but it

operates at a higher power level and can alert you to

many different emergency or hazardous conditions in

the area. Your detector’s three safety indications show

three major categories of Safety Warning System mes-

sages.

While neither system is currently in wide use, they have

the potential to dramatically decrease the potential for

traffic accidents by increasing drivers’ awareness of

local road hazards. Having this radar/laser detector will

ensure that you are ready to use these systems as they

come into use.
