Quick Start Guide – Mini OLED Display DSP06-L
What is in the box?
When you purchase a Mini OLED Display (RLVBDSP06-L), you will find the following items when you open the box:
Produ t Code Quantity Des ription
VBDSP06-L 1 Mini OLED Display Unit with Lemo
5-way plug
RLACS287 1 VBOX Lightweight Suction Mount
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
1
Features
• View parameters, such as Live Speed, Max Speed,
Lap Times and Predictive Lap Time
• Internal accelerometer flips the display according to
the mounting direction
• Inverse screen colours or change font options for
varying operation condition
• Shows logging and capacity status of connected
VBOX units
• Easy operation with the 3-button keypad • Recognises data from standard VBOX CAN and
serial output
• Low power consumption • Recognises serial data output from all VBOX units
• Delta V LED indicators • Combo G LED Indicators
Memory Usage
If the SD card you use in the connected data logging unit has less than 10 MB of space available, you will see a
warning symbol flashing periodically indicating the amount of memory available.
O Button Functions
Depending on which mode is currently active on the
screen, the function of the OK button will change. The
splash screen shown when scrolling through the menu
describes the function of the OK button in each mode.
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
2
You can also find the complete list below:
Mode Fun tion
Speed Start and stop logging
Max Speed Reset max speed value
Speed Bar Set centre speed and speed display range
Predi tive Lap Timing Single Press fixes the reference lap according to your
settings in Fixed Lap Mode
Predi tive Lap Timing Pressing for >4 s clears the stored reference lap and all
lap timing data
Lap Timing Set a new start/finish line
Lap Count No action
Lateral G Reset max g reached
Lateral G Bar Set min g and max g (targets)
Longitudinal G Reset max g reached
Longitudinal G Bar Set min g and max g (targets)
Menu Access the Menu
No Media
If you do not have an SD card inserted in your VBOX data logger, the OLED Display will show a "No Media"
message while the vehicle is moving at speeds of 5 mph or less. This makes it easier for you to make sure that you
have an SD card inserted before you start your logging.
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
3
Installing the Mini OLED
Display connection
When setting up the DSP06 Mini OLED display with a VBOX Video HD2 or a Video VBOX Pro
VBOX Video HD2
To connect to a VBOX Video HD2, connect the cable to the ‘CAN / SER’ port.
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
4
VBOX Video HD2 with CAN / Serial splitter cable
To connect the Mini OLED Predictive Lap Timing Display and a CAN VCI at the same time to log external parameters
from either a vehicle CAN Bus or a Racelogic expansion module.
Connect the single end of the splitter cable (RLCAB081) to the ‘SER’ port on the VBOX Video HD2 and connect the
Mini OLED Display to one of the dual ends and your CAN VCI to the other.
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
5
Video VBOX Pro
To connect to a Video VBOX Pro, connect the cable to the ‘SER’ port.
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
6
Display Modes
The DSP06 Mini OLED Display has different display modes that you can access by using the ▲▼ buttons on the unit.
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
7
The data displayed on each screen is always calculated by the unit at all times, even if you choose not to display it. Click
on the name of each mode to find relevant setup information.
Speed Max. Speed
Lap Timing Predi tive Lap Timing
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
8
Lateral G Bar Speed Bar
LED Behaviour
Delta-V LEDs
The two front panel LEDs are used in predictive lap timing mode. They indicate if the current vehicle speed is faster
or slower than the speed was at the same position in the reference file.
The LEDs will show red if the current speed is slower than the reference, or green if the current speed is faster.
The value defined within the ‘Delta-V range’ setting dictates the min. and max speed values to full brightness.
The two LEDs act as a gauge, filling up from the left to right. Once the current speed is slower or faster than the
reference, the left LED will illuminate. Once the current speed is above 50% of the defined positive or negative
range, the LED on the right will also illuminate.
Slower than referen e lap Faster than referen e lap
https://en.racelogic.support//Product_Info/Displays/OLED_Display/VBOX_Mini_OLED_Display_DSP06/
VBOX_Mini_OLED_Display_DSP06-L/Quick_Start_Guide_%E2%80%93_Mini_OLED_Display_DSP06-L
10
