Qvis APOHDSDI-MB Manual de usuario
APOHDSDI-MB
1080P HD-SDI ANALOGUE CAMERA
User’s Manual
V1.0 11 / 2013
i
ii
Welcome
Thank you for purchasing our 1080P HD-SDI ANALOGUE CAMERA.
This user’s manual is designed to be a reference tool for the installation and
operation of your system.
Here you can find information about the corresponding analogue camera’s
features and functions, as well as a detailed installation method.
Before installation and operation please read the following safeguards
and warnings carefully!
iii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power supply shall conform to the requirement in the SELV (Safety Extra Low Voltage) and
must make sure that the limited power source is rated 12V DC.
Please note: Do not connect two power supplying sources to the device at the same time; it
may result in device damage!
We assume no liability or responsibility for all the fires or electrical shock caused by improper
handling or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation Security
Please ensure that the product does not endure heavy stresses, violent vibration or contact with
water during transportation, storage and installation.
Please use the original packing material (or the material of the same quality) if you need to return it
to vendor.
3．Installation
Do not apply power to the product before completing installation.
Do not put object(s) on the product.
Please install a proper power cut-off device during the installation connection.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers. We are not
liable for any problems caused by unauthorised modifications or attempted repair.
5. Environment
This product should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
Please keep it away from environments that contain electromagnetic radiation or objects that
produce it.
Please keep sound ventilation around the device at all times.
Do not allow the water and other liquid to penetrate into the device if casing has been
compromised. This series product complies with the IP66 standard specified in the Degrees of
Protection Provided by Enclosure.
Ensure lightning surge protection is in place to make sure you fully protect camera circuitry from
electrical overload.
iv
Please make sure the CCD (CMOS) component is away from the radiation of the laser beam
device. Otherwise it may result in CCD (CMOS) optical component damage.
It is recommended that the grounding studs of the product should be grounded, so to further
enhance the reliability of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin any maintenance
work.
Do not touch the CCD (CMOS) optic component. Please use an air jet to clean the dust off the lens
surface. You can use the dry cloth with some alcohol or mild detergent to clear if necessary.
When the camera is not in use please put the dustproof cap to protect the CCD (CMOS)
component.
Do not use volatile solvent such as the benzene, paint thinner or detergent with the ability to
abrade surfaces. It may result in lens damage or adversely affect the device’s performance.
7. Accessories
Always use all the accessories recommended by manufacturer.
Before installation, please open the package and check that all the components are included. Contact
your local retailer/vendor ASAP if something is missing.
8. Box Contents:
Accessory Name
Amount
Camera Unit
1
User’s Manual
1
Installation Accessories Bag
1
CD
1
v
Table of Contents
1General Introduction......................................................................................................1
1.1 Overview...........................................................................................................1
1.2 Features............................................................................................................1
1.3 Specifications....................................................................................................2
1.3.1 Performance...............................................................................................2
2Framework.....................................................................................................................3
2.1 Multiple-function Combination Cable.................................................................3
2.2 Dimension.........................................................................................................4
3Installation .....................................................................................................................5
3.1 Device Installation.............................................................................................5
3.2 Lens Adjustment ...............................................................................................6
4OSD Setup Menu ..........................................................................................................7
5FAQ...............................................................................................................................9
© Copyright Qvis ®. All documentation rights reserved.
1
1General Introduction
1.1 Overview
This type of camera conforms to the HD-SDI specifications. It supports high speed video signal, which
means there is almost no delay in the transmission. The HD-SDI interface uses the coaxial cable to
transmit video signals and uses the BNC port as the cable standard.
The main benefit to this camera is its ability to record in 1080P HD definition, providing excellent quality
video imagery to monitor. It also uses DC 12V for a power supply and you can use an inbuilt OSD button
function to adjust internal camera settings.
1.2 Features
Data
Transmission
Coaxial cable.
Use the BNC port as the cable standard.
Peripheral
Equipment
Support peripheral equipment connections via the RS485 port.
Supports various peripheral device control protocols. .
Power
External power adapter. Supports a DC 12V power supply.
Assistant
Function
Day/Night mode auto switch (ICR switch.)
Supports OSD button function.
Supports 1080P@25fps, 1080P@30fps, 720P@25fps, 720P@30fps,
720P@50fps, 720P@60fps.
Supports WDR (Wide Dynamic Range).
Supports anti-flicker.
Supports HLC (Highlight Compensation).
Backlight compensation: auto screen split to allow backlight
compensation to adjust the brightness.
© Copyright Qvis ®. All documentation rights reserved.
2
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for digital camera performance specification:
Model
Parameter
APOHDSDI-EYE
System
Main
Processor
High performance processor
Video Parameters
Image Sensor
1/3-inch CMOS
Pixel
1920(H)*1080(V)
Day/Night
Support day/night mode switch and IR-CUT at the same time.
Gain Control
Fixed/Auto
White Balance
Manual/Auto/Day/Night
Exposure
Manual/Auto
PAL: It ranges from 1/3 to 1/10000.
NTSC: It ranges from 1/4 to 1/10000.
Video Frame
Rate
Conform to the SDI specifications SMPT274/292 protocol
Video Bit Rate
PAL：1920*1080@25fps, 1280*720@25 fps, 1280*720@50 fps；
NTSC：1920*1080@30fps, 1280*720@30 fps, 1280*720@60 fps
Mirror
Support mirror and flip
Aux Function
Support WDR, HLC, BLC, anti-flicker, low motion blur, low noise, 3D
NR, motion detect, privacy mask
Support parameter setup such as brightness, contrast.
Video
Information
OSD menu
Lens Interface
M12 lens, 6mm (3.6mm optional)
AUX
Interface
Video Output
1-channel HD-SDI output
RS485 Port
May set image and OSD.
General Parameters
Power
Support DC 12V power
Power
Consumption
Max: 6W
IR
20m
Protective
Level
IP66
Working
Temperature
-10°C~+60°C
Working
Humidify
≤95%
Dimensions
(Unit: mm)
70 X 66 X 160
Weight
500g (without packaging)
Installation
Wall-mount, ceiling
© Copyright Qvis ®. All documentation rights reserved.
3
2Framework
2.1 Multiple-function Combination Cable
You can refer to the following figure for multiple-function combination cable information. See
Figure 2-1:
Figure 2-1 Multiple-function combination cable
Please refer to the following sheet for detailed information:
SN
Port Name
Function
Note
1
HD-SDI
SDI output
Send out SDI video stream conforming to the
HD-SDI standard.
2
RS485
RS485 port
RS485 port. Control the 485 configuration tool to
set image.
3
DC 12V
Power input
port
Power port. Input DC 12V.
© Copyright Qvis ®. All documentation rights reserved.
4
2.2 Dimension
Please refer to the following two figures for dimension information. The unit is mm. See Figure 2-2 and
Figure 2-3:
Figure 2-2 Dimension illustration 1
Figure 2-3 Dimension illustration 2
