Quincy Compressor Climate Control Series Manual de usuario

This manual contains important safety information and must be

carefully read in its entirety and understood prior to installation

by all personnel who install, operate and/or maintain this product.

On-line product registration, parts ordering and warranty information is available at www.quincycompressor.com

THIS PRODUCT CAN EXPOSE YOU TO CHEMICALS INCLUDING LEAD,

WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER

AND BIRTH DEFECTS OR OTHER REPRODUCTIVE HARM. FOR MORE

INFORMATION GO TO WWW.P65WARNINGS.CA.GOV

Manual No. 2022209100

May 2019 Edition

Instruction Manual

Climate Control Series

Climate Control Series Quincy Compressor

2022209100, August 2018 1

† Before 1996, 310QRB (11/2h.p.) was produced.

INTRODUCTION

The Quincy Compressor Climate Control Series consists of splash or pressure

lubricated reciprocating air compressors.This instruction manual provides you

with general and speciﬁc information regarding these compressors. Outlined

below is a Model Designation Code to assist you in determining which unit

you have as well as the speciﬁc basic compressor.

Model Designation Code for Splash Lubricated Unit Models

QC 005 03 D 1 A

Splash Lubricated Horsepower Tank Size Type Phase Design Revision Letter

Basic

Horsepower Compressor Tank Size Type Phase

005 = 1/2h.p. § QTS3QCB 03 = 30 gal. S = simplex 1 = 60 Hz. 1 Phase

007 = 3/4h.p. § QTS3QCB 06 = 60 gal. D = duplex 3 = 60 Hz. 3 Phase

010 = 1 h.p. § QTS3QCB 08 = 80 gal.

015 = 11/2h.p. § QTS3QCB 12 = 120 gal.

020 = 2 h.p. † QTS5QCB 20 = 200 gal.

030 = 3 h.p. † QTS5QCB 24 = 240 gal.

050 = 5 h.p. ‡ QT7QCB BB = base mount

075 = 71/2h.p. **QT10QCB BR = retroﬁt

100 = 10 h.p. QT15QCB EPT4 = Emergency Portable Q911 (twin 4 gal. tanks)

151 = 15 h.p. QT15QCB

§ Before 1994, X3QCB (1/2h.p.), 210QCB (3/4& 1 h.p.) & QT5QCB (11/2h.p.) were produced.

† Before May of 2001, QT5QCB was offered as 2 & 3 h.p. QT5QCB is used on 2 & 3 h.p. retroﬁt package only.

‡ 5 h.p. retroﬁt package also produced with QT7QCB. The package was supplied with QT5QCB prior to Sept. 2000.

** Prior to July 1, 2000, QT15QCB basic compressor was offered as 7 1/2h.p.

Model Designation Code for Pressure Lubricated Unit Models

QR 050 08 S 3 A

Pressure Lubricated Horsepower Tank Size Type Phase Design Revision Letter

Basic

Horsepower Compressor Tank Size Type Phase

010 = 1 h.p. 210QRB 03 = 30 gal. S = simplex 1 = 60 Hz. 1 Phase

015 = 11/2h.p. † 210QRB 06 = 60 gal. D = duplex 3 = 60 Hz. 3 Phase

020 = 2 h.p. 325QRB 08 = 80 gal.

030 = 3 h.p. 325QRB 12 = 120 gal.

050 = 5 h.p. 340QRB 20 = 200 gal.

075 = 71/2h.p. 350QRB 24 = 240 gal.

100 = 10 h.p. 390QRB BB = base mount

150 = 15 h.p. 5120QRB

200 = 20 h.p. 5120QRB

Climate Control Series Quincy Compressor

2022209100, August 2018 2

TABLE OF CONTENTS

SECTION 1 SAFETY

• Safety First ........................................................................................................................................... 3

• Summary of Changes ........................................................................................................................... 5

SECTION 2 SYSTEM DYNAMICS

• Principles of Compression Cycles........................................................................................................ 6

• Principles of Lubrication System ........................................................................................................ 6

• Principles of Cooling System ............................................................................................................... 7

• Principles of Dryers & Filters.............................................................................................................. 7

• Principles of Control System ............................................................................................................... 7

SECTION 3 INSTALLATION

• Receiving Delivery................................................................................................................................ 8

• Freight Damage.................................................................................................................................... 8

• Location................................................................................................................................................. 9

• Electrical Supply Requirements........................................................................................................ 10

• Mounting............................................................................................................................................. 11

• System Components........................................................................................................................... 11

• Wiring & Piping Schematics.........................................................................................................12-16

• Induction System................................................................................................................................ 18

• Compressed Air Discharge System ................................................................................................... 19

SECTION 4 START-UP &

OPERATION

• Prestarting Checklist ......................................................................................................................... 23

• Initial Starting & Operating.............................................................................................................. 24

• Daily Starting Checklist .................................................................................................................... 24

SECTION 5 MAINTENANCE

& LUBRICATION

• Stopping for Maintenance.................................................................................................................. 26

• Maintenance Schedule ....................................................................................................................... 26

• Lubrication ......................................................................................................................................... 28

• Lubricant Filter.................................................................................................................................. 29

• Pulley/Sheave Alignment & Belt Tension ......................................................................................... 29

SECTION 6 TROUBLESHOOTING

• Troubleshooting .................................................................................................................................. 31

• Decal Diagram.................................................................................................................................... 35

Climate Control Series Quincy Compressor

2022209100, August 2018 3

SECTION 1 SAFETY

•Safety First

At Quincy Compressor safety is not only a primary concern, but a faithfully

performed practice. Beginning with the design stage, safety is built into every

Quincy compressor. It is the intention of this manual to pass along the “safety

ﬁrst “ concept to you by providing safety precautions throughout its pages.

“WARNING !”, “CAUTION !”, and “DANGER !” are displayed in large

bold capital letters in the left hand column to call attention to areas of vital

concern. They represent different degrees of hazard seriousness, as stated

below. The safety precaution is spelled out in bold upper and lower case letters

in the right hand column.

Immediate hazards which will result in severe personal injury or

death.

Hazards or unsafe practices that could result in personal injury or

death.

Hazards or unsafe practices which could result in minor personal

injury, product or property damage.

Each section of this instruction manual,as well as any instructions supplied

by manufacturers of supporting equipment, should be read and understood

prior to starting the compressor. If there are any questions regarding any part

of the instructions, please call your local Quincy distributor, or the Quincy

Compressor factory before creating a potentially hazardous situation. Life,

limb, or equipment could be saved with a simple phone call.

Compressors are precision high speed mechanical equipment requiring

caution in operation to minimize hazard to property and personnel. There

are many obvious safety rules that must be observed in the operation of this

type of equipment. Listed below are some additional safety precautions that

must be observed.

•Transfer of toxic,dangerous, ﬂammable or explosive substances using Quincy

Compressor products is at the user’s risk.

•All installation, maintenance and repair must be performed by a qualiﬁed

technician and / or electrician.

•Turn off and lockout/tagout (per OSHA regulation 1910.147) the main power

disconnect switch before attempting to work or perform any maintenance.

•Do not attempt to service any part of the unit while it is running.

•Per OSHA regulation 1910.147, relieve the system of all pressure before at-

tempting to service any part of the unit.

•Do not operate the unit with any of its safety guards, shields, or screens

removed.

WARNING !

CAUTION !

DANGER !

Climate Control Series Quincy Compressor

2022209100, August 2018 4

•Allow ample time for the compressor to cool before performing service pro-

cedures. Some surface temperatures exceed 350°F when the compressor is

operating.

•Do not remove or paint over any DANGER!, WARNING!, CAUTION!, or

instructional materials attached to the compressor. Lack of information re-

garding hazardous conditions can cause property damage or personal injury.

•Periodically check all pressure relief valves for proper operation.

•Do not change the pressure setting of the pressure relief valve, restrict the

function of the pressure relief valve, or replace the pressure relief valve with

a plug.

•Do not install a shutoff valve in the compressor discharge line without ﬁrst

installing a pressure relief valve of proper size and design between the shutoff

valve and the compressor.

•All components of the compressed air system must be properly rated for the

application.

•Alterations must not be made to this compressor without Quincy Compres-

sor’s approval.

•Be sure that all tools, shipping and installation debris have been removed

from the compressor and installation site prior to starting the compressor.

•Do not operate the compressor in excess of the ASME pressure vessel rating

for the receiver or the service rating of the compressor, whichever is lower.

•Make a general overall inspection of the unit daily and correct any unsafe

situations. All fasteners and ﬁttings must be kept tight.

•Reckless behavior of any kind involving compressed air is dangerous and

can cause very serious injury to the participants.

•Provisions should be made to have the instruction manual readily available

to the operator and maintenance personnel. If for any reason any part of the

manual becomes illegible or the manual is lost, have it replaced immediately.

The instruction manual should be read periodically to refresh one’s memory.

It may prevent a serious or fatal accident.

•Wear safety glasses and hearing protection during operation, service and

maintenance procedures.

Air used for breathing or food processing must meet OSHA 29 CFR

1910.134 or FDA 21 CFR 178.3570 regulations. Failure to do so may

cause severe injury or death.

Oil and moisture residue must be drained from the air receiver

daily or after each use. Accumulations of oil residue in the receiver

can be ignited by embers of carbon created by the heat of compres-

sion, causing an explosion, damage to property and injury to per-

sonnel.

DANGER !

WARNING !

Climate Control Series Quincy Compressor

2022209100, August 2018 5

The owner, lessor or operator of any compressor unit manufactured by

Quincy Compressor is hereby warned that failure to observe the safety precau-

tions and procedures outlined in this manual may result in serious personal

injury, damage to property, and may void your warranty. Quincy Compressor

must authorize all warranty service. Before contacting your distributor or the

factory, check the maintenance requirements and the troubleshooting guide

for your compressor. Most warranty issues can be resolved by following proper

maintenance procedures.

Quincy Compressor neither states as fact, nor in any way implies that the

above list of safety precautions is an all inclusive list, the observance of which

will prevent all damage to property or injury to personnel.

Every effort has been taken to ensure that complete and correct instructions

have been included in this manual. However, possible product updates and

changes may have occurred since this printing. Quincy Compressor reserves

the right to change speciﬁcations without incurring any obligation for equip-

ment previously or subsequently sold.

Summary of Changes to This Manual

(since previous printing dated January 2013):

· Clariﬁed safety statement relative to properly rated components for the

compressed air system.

· Updated lubricant capacity speciﬁcations for pressure lubricated models

as result of bearing carrier redesign.

· Added Lubricant Filter information.

Climate Control Series Quincy Compressor

2022209100, August 2018 6

SYSTEM DYNAMICS

•Principles of Compression Cycles

Single Stage Compressors

During the downstroke of a single stage compressor, air is drawn through an

intake valve in the head of the compressor and into the cylinder. At the bot-

tom of the stroke, the intake valve closes and air is trapped in the cylinder.

The air is then compressed in the cylinder during the upstroke of the piston.

Total compression, from atmospheric pressure to the ﬁnal discharge pressure,

is accomplished in one stroke of the piston.

Two Stage Compressors

During the downstroke of the piston of a two stage compressor, air is drawn

through an intake valve in the head of the compressor and into the low pres-

sure cylinder. This air is compressed during the upstroke of the piston.

The compressed air is then released through a discharge valve in the head

of the compressor to an intercooler (usually ﬁnned tubing) where the heat

resulting from compression is allowed to dissipate. The cooler compressed air

is then drawn into a second compression cylinder, the high pressure cylinder,

for compression to ﬁnal pressure.

From there the compressed air is released through a discharge valve to an

air receiver tank or directly to a network of compressed air supply lines. In

one revolution of the crankshaft a compression cycle is completed.

•Principles of Lubrication System

Splash Lubricated Models

With each stroke of the compressor, a dipper attached to the bottom of the

connecting rod, dips into a lubricant bath at the bottom of the crankcase. This

dipper causes the lubricant to splash throughout the interior of the crankcase,

lubricating all moving parts.

It is important with this system that the lubricant level be maintained

between the high and low level marks on the dipstick. If the lubricant level

is too high, excessive lubricant carryover could result. If the lubricant level is

too low, or the compressor is not operated within the correct RPM range, the

moving parts will not be adequately lubricated.

Pressure Lubricated Models

Moving parts within the crankcase are lubricated by means of a positive

displacement, gerotor type oil pump. Lubricant is drawn up from the bottom

of the crankcase to the oil pump through an oil sump strainer screen. The

lubricant is then forced under pressure through the oil ﬁlter (if so equipped).

Lubricant travels under pressure through drilled journals in the crankshaft

and connecting rods to lubricate crankshaft bearings, wrist pin bearings and

the cylinder walls.

Climate Control Series Quincy Compressor

2022209100, August 2018 7

•Principles of Cooling System

Fan blades in the compressor sheave force ambient air across ﬁns on the cylin-

der heads (and intercooler ﬁns of two stage compressors). Quincy compressors

should be operated in temperatures under 104°F.

Principles of Dryers & Filters

Moisture occurs naturally in air lines as a result of compression. Moisture

vapor in ambient air is concentrated when pressurized and condenses when

cooled in downstream air piping. Compressed air dryers reduce the moisture

vapor concentration and prevent water formation in compressed air lines.

Dryers are a recommended companion to ﬁlters, aftercoolers, and automatic

drains for improving the productivity of compressed air systems.

Water and moisture vapor removal increases the efﬁciency of air operated

equipment, reduces contamination and rusting, increases the service life of

pneumatic equipment and tools, prevents air line freeze-ups, and reduces

product rejects.

•Principles of Control System

Simplex Units

Simplex Climate Control units are controlled by a pressure switch which

detects the demand for compressed air and allows the motor to start. When

the demand is satisﬁed, the unit stops.

Duplex Units

Duplex Climate Control units are controlled by multiple pressure switches

(one for each compressor). They react to a demand for air the same way as a

simplex unit. In addition to the pressure switches, duplex units can be con-

trolled by an electrical alternating switch that automatically distributes the

workload evenly between the two basic compressors. The following example

best explains the process:

The lead compressor starts and runs to satisfy the air demand. When the

pressure in the system reaches the cut-out pressure of the lead compressor, it

shuts off. The next time air is required, the lag compressor starts up ﬁrst and

becomes the lead compressor.

If the lead compressor can not satisfy the air demand, the lag compressor

will automatically start and assist until the pressure in the system reaches

the cut-out pressure. At the cut-out pressure, both the lead compressor and

lag compressor shut down. The cut-in pressure of the lead pressure switch is

normally set 10 PSIG higher than the lag pressure switch.

Climate Control Series Quincy Compressor

2022209100, August 2018 8

SECTION 3 INSTALLATION

•Receiving Delivery

Immediately upon receipt of compressor equipment and prior to completely

uncrating, the following steps should be taken:

Step 1) Inspect compressor equipment for damage that may have occurred

during shipment. If any damage is found, demand an inspection

from the carrier. Ask the carrier how to ﬁle a claim for shipping

damages. (Refer to SECTION 3, •Freight Damage for complete

details.) Shipping damage is not covered by Quincy Com-

pressor warranty.

Step 2) Insure that adequate lifting equipment is available for moving

the compressor equipment.

Improper lifting can result in component or system damage, or

personal injury. Follow good shop practices and safety procedures

when moving the unit.

Step 3) Read the compressor nameplate to verify the model and size or-

dered.

Step 4) Read the motor nameplate to verify that the volt, phase and hertz

ratings are the same as the electrical power supply connecting to

the motor. NOTE: Do not use a triple voltage (115/208-230)

single-phase motor or (208-230/460) 3-phase motor for 208

volts or lower. Use a 200 volt or 208 volt motor only.

Step 5) Read the pressure relief valve nameplate to be sure it does not

exceed the working pressure shown on the compressor or any other

component in the system.

Step 6) Read and understand the safety precautions contained

within this manual. The successful and efﬁcient operation of

compressor equipment depends largely upon the amount of care

taken to install and maintain the equipment. Quincy Compressor

strongly recommends that any or all person(s) in charge of install-

ing, maintaining, or servicing one of our compressors read and

understand the entire contents of this manual in order to perform

such duties safely and efﬁciently.

•Freight Damage

It is extremely important that you examine every carton and crate as soon as

you receive it. If there is any obvious damage to the shipping container, have

the delivering carrier sign the freight bill, noting the apparent damage, and

request a damage report.

If concealed damage is discovered at a later date, the carrier must

be notiﬁed within 15 days of initial receipt of freight. Concealed ship-

ping damage is not covered by Quincy Compressor. Contact the carrier as

soon as possible, giving them an opportunity to inspect the shipment at the

premises where the delivery was made. Do not move the damaged freight from

CAUTION !

Tabla de contenidos

Otros manuales de Compresor de aire de Quincy Compressor

Quincy Compressor

Quincy Compressor QSI 50 Manual de usuario

Quincy Compressor

Quincy Compressor QSB Series Manual de usuario

Quincy Compressor

Quincy Compressor QR-25 Series Manual de usuario

Quincy Compressor

Quincy Compressor QSI Series Manual de usuario

Quincy Compressor

Quincy Compressor QT Series Manual de usuario

Quincy Compressor

Quincy Compressor QED 650 Manual de usuario

Quincy Compressor

Quincy Compressor QGS 10 Manual de usuario

Quincy Compressor

Quincy Compressor QSI 50 Manual de usuario

Quincy Compressor

Quincy Compressor QSD 65040-AB Manual de usuario

Quincy Compressor

Quincy Compressor QSI-220i Manual de usuario

Quincy Compressor

Quincy Compressor QGS 90 Manual de usuario

Quincy Compressor

Quincy Compressor Industrial Series Manual de usuario

Quincy Compressor

Quincy Compressor QSI Series Manual de usuario

Quincy Compressor

Quincy Compressor HP 15 Manual de instrucciones

Quincy Compressor

Quincy Compressor QGD 40 Manual de usuario

Quincy Compressor

Quincy Compressor QMA Series Manual de usuario

Quincy Compressor

Quincy Compressor QOF 2 Manual de usuario

Quincy Compressor

Quincy Compressor QR-25 Series Manual de usuario

Quincy Compressor

Quincy Compressor Q12120P Manual de lista de piezas

Quincy Compressor

Quincy Compressor QED 650 Instrucciones de uso

Quincy Compressor

Quincy Compressor QGS 40 Manual de usuario

Quincy Compressor

Quincy Compressor QR-25 Series Manual de usuario

Quincy Compressor

Quincy Compressor QOFT 20 Manual de usuario

Quincy Compressor

Quincy Compressor QOF 20 Manual de usuario

Manuales populares de Compresor de aire de otras marcas

Sparmax

Sparmax DC-25XR Manual de usuario

KAESER

KAESER M122 Manual de usuario

GMC

GMC GAC1500 Manual de usuario

Briggs & Stratton

Briggs & Stratton Air Compressor Manual de usuario

Fini

Fini F3GST2TK Manual de usuario

Industrial Air

Industrial Air CP1580325 Manual de programación

Campbell Hausfeld

Campbell Hausfeld RP3300 Guía de inicio rápido

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Manual de usuario

Hitachi

Hitachi EC99S Manual del operador

Parkside

Parkside PKO 270 A1 Manual de usuario

Sullair

Sullair 185 Manual de usuario

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Manual de usuario

Ferm

Ferm CRM1046 Manual de usuario

BE AC153 Manual de usuario

RIDGID

RIDGID OF25150A Manual de usuario

Johnson Controls

Johnson Controls QUANTUM LX Manual

Sears

Sears Craftsman 919.167463 Manual de usuario

Ring Automotive

Ring Automotive RAC700 Manual de usuario
