Que Acoustics LLC
Q3E
Sports Bluetooth®Earphones
User Manual
Charging
These earphones contain non-detachable, rechargeable batter-
ies. Que Acoustics LLC is not liable for any damage or hazard
caused due to unauthorized tampering or attempted opening of
the earphones. Any tampering will void the warranty.
Connect the micro USB connector on the charging cable to the
port on the Q3E. Connect the USB connector on the cable to a
phone wall adapter/charger/car charger/computer/power bank
or any device with a USB port. The LED will light up red to indi-
cate charging and will turn blue when the battery is fully charged.
Please charge the earphones fully before using for the first time.
Power On / Power Off
POWER ON: Press the (multi-function-button) for about
2 - 5 seconds until the LED flashes blue with a voice prompt
‘power on’.
POWER OFF: Press for 4 secs or so until the LED flash-
es red with a voice prompt ‘power off’.
LOW BATTERY ALARM: The LED flashes red several times
with a voice prompt ‘Battery Low’.
Pairing
Pairing and connecting with a Bluetooth device:
1. Turn Bluetooth ‘off’ on your device.
2. On Q3E, press and hold the until the LED flashes
rapidly, alternating between red and blue. This indicates that
the Q3E is in pairing mode.
3. On your device, turn Bluetooth ‘on’, and scan for names until
Q3E appears. Click on Q3E to initiate connection with the
earphones. Upon successful pairing the voice prompt will
say ‘connected’ and the blue LED will continue to flash once
every 5 – 10 seconds.
You only need to go through the above sequence once when
you pair the Q3E with your Bluetooth device for the first time.
Next time, as long as your device has Bluetooth turned ‘on’,
simply power on the Q3E and pairing will take place automat-
ically. When successful, the voice prompt will say ‘connected’
and periodically you will see a single flash of the blue LED.
On power up, if the blue LED on the Q3E flashes twice every
5 – 10 seconds, it indicates that the Q3E is not paired with any
device.
Pairing with 2 devices:
Repeat steps 1 to 3 for pairing the Q3E with 1st device.
4. Turn Bluetooth ‘off’ on your 1st device.
5. Repeat steps 1 to 3 to pair Q3E with the 2nd device
6. On the 1st device turn Bluetooth ‘on’ and click on Q3E to
connect to the earphones. The Q3E will maintain the con-
nection with the 2nd device.
7. The Q3E will now be connected to both devices simultane-
ously.
8. You can toggle between the 1st device and the 2nd device
with a short click of the .
Note: If the Q3E has been paired with a device before, simply
power it on by pressing the until the blue LED flash-
es, and the earphones will pair with the device automatically.
(Bluetooth on the device must be turned ‘on’).
Thank you for choosing Q3E
Bluetooth®earphones.
Specifications
• Model No: Q3E
• Bluetooth Version 4.1
• Charging port: Micro USB
• Protocol Support HFP, HSP, A2DP and AVRCP
• Supports simultaneous connection with two
Bluetooth devices
• Operating range: Up to 33 feet (10 meters)
• 90mAh rechargeable batteries
• Talk time: 6 - 7 hours
• Music play time: 5 - 6 hours
• Standby time: 250 hours
• Charging time: 1 - 2 hours
• Phone support: answer calls, reject calls, last number
redial
• iPhone battery indication
• CVC echo and noise cancellation
• Voice prompt support: Power On / Pairing / Connected /
Battery Low / Power Off,etc.
Note: The Q3E earphones are water/sweat resistant.
It is recommended to wipe the ear tips gently with a damp
cloth.
USB PortLED
